Instruction Manual
Instant Water Heater
For proper operation and maintenance
please read carefully and preserve the Instruction Manual
Page:
Thanks for your choice of our products.
We will provide satisfactory service to you everlastingly.
Your safety is very important !
This manual provides many important safety points. Please read it carefully and follow the instruction rules.
It is dangerous and may cause injury if you don't follow safety instructions.
Consumers' Responsibilities
This manual helps you to acquaint with the installation, operation, and maintenance of your electric water
heater. It provides the key safety information.
We urge you to read all of the instructions thoroughly before installation or operation. We highly recommend
to keep this manual for future reference.
The manufacturer will not be liable for any damages caused by failure installation and operating.
If you lack of the necessary skills for proper installation or have difficulty following the instructions, you should
not proceed but have a qualified technician to install it.
1
Advertisement
Table of Contents
Related Manuals for Gleamous GL5
Summary of Contents for Gleamous GL5
-
Page 1: Instruction Manual
Instruction Manual Instant Water Heater For proper operation and maintenance please read carefully and preserve the Instruction Manual Page: Thanks for your choice of our products. We will provide satisfactory service to you everlastingly. Your safety is very important ! This manual provides many important safety points. -
Page 2: Main Features
The water heater is not intended by the body, sensory or mental impairment, or lack of experience and knowledge of the people(including children) use, unless the person responsible for their safety use of water heater in supervision and guidance. Don’t allow the children play the unit. A label with basic parameters is stick on the machine which helps you to know more about your water heater. -
Page 3: Installation Manual
Installation Manual Opening the Packing Materials Attention: Do not remove any of the permanent instructions and labels, no matter inside or outside. Dismantle the exterior packing and place installation components aside. • Inspect all parts prior to installation and start-up. Make sure there is no visible damage. •... -
Page 4: Electrical Requirements
The water heater must be installed indoors, it should be located in an area not subject to freezing temperatures. The material of water heater cover is ABS, so require there is no heat source or combusibles (Cabinet, curtain, carton ect.) near water heater. Water outlet must be connected to normal water faucet or connecting point. - Page 5 G. We highly recommend connecting a leakage protection device to the water heater. Heater Fixing...
-
Page 6: Electrical Connection
The unit should be wall-mounted installed. Determine the right position of installation for the unit; According to Figure 6 and Figure 5（a） to drill 3 holes on the wall. Drive the expansion bolts in the hole (1),(2) & (3) fix the screws into the expansion bolts, make sure it’s fully fasttened and the screws head away from the wall surface have 6mm~8mm distance. -
Page 7: Schematic Wiring Diagram
When installing the electrical wiring to the water heater, please make sure: Shut off the power to the water heater. Schematic Wiring Diagram Methods of Operation Before operating the water heater, perform the following: Make sure the water heater has been properly installed. Completely fill the tank with water. -
Page 8: Water Temperature Regulation
the inlet valve and allow the tank to completely fill with water. To purge excess air. Then close the faucet and check all connections for leaks. Apply power to the water heater only after the tank is completely filled with water. The water flow rate for operation is at least 2 L/Min. -
Page 9: Maintenance Instruction
Maintenance instruction Clean the appliance with a damp cloth. It is ok to clean the cover with mild detergent, but DO NOT use turpentine, alcohol, petrol or any other corrosive solutions. Clean the hand-shower regularly. Clean the filter regularly: Disconnect the shower head from the hose. Remove the filter mesh washer and flush it with water to remove any trapped sediments. - Page 10 The speed of sliding touch is Sliding touch fail Slow down the speed of sliding touch too fast Malfunction code “E1” Current leakage Contact the service centre for repair Water Flow switch is open or Malfunction code “E2” short circuit Contact the service centre for repair The temp.
