MAG-280 四合一蒸氣烤焗微波爐 4 - i n - 1 S t e a m & G r i l l M i c r o w a v e O v e n 在 使 用 之 前 請 詳 細 閱 讀 「 使 用 說 明 書 」及「 保 用 條 例 」 , 並 妥 為 保 存 。...
Page 2
請即進行保用登記﹗ 有關保用條款細則,請看本說明書最後一頁。 Please register your warranty information now ! For Warranty Terms & Conditions, please refer to the last page of these operating instructions.
技術規格 C O N V EC TI O V EN EO N -C 30 4S M 型號 MAG-280 電壓 220 - 240V, 50 Hz 額定功率 2,200 W 輸入功率 1,700 W (烘焗) 1,700 W (燒烤) 1,400 W (微波) 550 W (蒸煮) 微波輸出功率...
Page 26
Table Of Contents Product Features Notice Before Use Product Structure - Body - Accessories - Compliant Containers - Control Panel Installation Instructions Operating Instructions - Before You Start - Assemble the Water Tank - Auto Menu Cooking - Quick Heating (Microwave) - Manual Cooking - Preheating / Extend - Lock (Child Lock Function)
Product Features Features Healthy Cooking Cooking with steam can preserve nutrients and reduce fat and salt from the food. Auto Cooking Optimized cooking conditions are provided in three options: Steam, Convection and Microwave Oven. Easy Cooking Convenient to operate and easy to clean with touch control panel and auto cooking menu.
Notice Before Use Safety Cautions • For safety purpose, you should read the instructions carefully before using the appliance for the first time. Save the instructions for future reference. • The appliance is designed for domestic use and may only be installed and operated in accordance with these instructions for use.
Page 29
Notice Before Use Before use and when Assembling Warnings The plug should be connected to only a rated Use a grounded wall outlet if using a socket voltage wall outlet. extension. • Otherwise, it may • Using a non-grounded socket may create an electric cause an electric shock or physical shock and product...
Page 30
Notice Before Use When using the product Warnings Do not overcook the food. Do not let children operate or hang. • Otherwise, it can • Children should cause a fire. be supervised to ensure that they do not play with the appliance.
Page 31
Notice Before Use When using the product Warnings Do not leave the oven or fall asleep while Empty the oven when not using it. cooking. • Otherwise, it • Otherwise, it may cause may happen excessive to cause a heat inside, fire or product leading to a damage...
Page 32
Notice Before Use Before use and when assembling Cautions Do not place the oven beneath a plastic object Do not place the oven in highly moist or under the shelf. environment. • • Otherwise, it Otherwise, it may cause may cause a overheating, fire or electric leading to a fire...
Page 33
Notice Before Use When using the product Cautions Do not wrap the product in a cloth. Do not touch the product by hand while cooking or right after the cooking because it can be • The cloth may be stuck in the door, extremely hot.
Page 34
Notice Before Use When using the product Cautions After heating food, the food can be extremely hot. When removing the vinyl cover, care must be taken. • The contents of feeding bottles and • As soon as you remove the vinyl cover, you baby food jars shall be stirred or shaken may be exposed to the high-temperature and the temperature checked before...
Product Structure CO NV EC TIO N OV EO N- C3 04 Body 1.Control Panel 6.Door Handle Used for selecting a requested cooking 7.Steam Inlet & Outlet function. This will input or emit steam during steam 2.Water Tank cooking. Water is necessary for steam cooking. 8.Baking Tray Support (first) 3.Drip Tray The steam tray is usually used here.
Accessories How to use the Accessories Function How to Use Accessories • Put the tray inside of the guide. • Select Level 1 or 2 depending on the dish. (Refer to ‘Cooking Guide’ for the proper position of the container.) Baking Tray •...
Control Panel Control panel 1. Power/Cancel: Stop operating the product or switch it to sleep mode. 2. Lock: Set or release the child lock mode by holding this button for 3~4 seconds. 3. Steam: Add steam during cooking. 4. Microwave: Select one of the four power levels. 5.
Installation Instructions • Leave some space between the product and the wall or other appliances. • Install it on a flat and stable surface with good air ventilation. • Do not place it on a glass or other low heat-resistant materials like vinyl and fabrics.
Assemble the Water Tank • Some dishes cannot be cooked without water. Check the water tank and fill it up. This is how to assemble the Water Tank. (Read carefully before use) Pull out the water tank and empty the tray at the bottom of the product.
Auto Menu Cooking • Auto menu cooking is a very convenient feature that enables you to take advantage of a preprogrammed menu with proper cooking time and temperature. Simply select a menu number and start cooking. 1. Press “-” to enter Auto 2.
Manual Cooking 1. Press “+” to enter Manual 2. Select a cooking method 3. Press Select to confirm mode. using “+”, “-” buttons. the cooking method 4. Adjust the cooking 5. Press Select to confirm 6. Adjust the cooking time temperature using “+”, the cooking temperature.
Preheating / Extend • The preheating function is only applicable to manual cooking mode. Preheating • It sets the temperature of oven to the desired value before cooking. • ‘Preheat’ mark will flicker during preheating. • When the oven reaches the desired temperature, the buzzer will alarm and ‘End’ mark will be displayed.
Deodorization Select auto menu ‘46’ to deodorize the oven. Steam • The steam function activates steam in the middle of cooking. Activate steam Deactivate steam Press ‘Steam’ key ‘Steam’ will be displayed. Press ‘Steam’ key Notes • Be sure to fill water into water tank before using steam function. •...
Power / Cancel / Auto Sleep Power Power/Cancel • Hold‘Power’key for over 3 seconds. The oven goes into sleep mode. LCD display will disappear. • Hold‘Power’key for over 3 seconds again to activate the oven. Cancel Power/Cancel • If wrong operation or mistakes occur, simply press ‘Cancel’key to return.
Care & Maintenance • The oven should be cleaned regularly and any food deposits removed. • Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. Exterior Door Glass Clean the exterior of...
Troubleshooting • If you encounter the following common troubles, please solve according to the following instructions. If the problem cannot be solved or a cause cannot be found, please contact our customer services centre. • Note: For safety purpose, do not dismantle the product for repair by yourself. Trouble Suggested Actions Display is off and the keys do not activate.
Technical Specifications C O N V EC TI O V EN EO N -C 30 4S M Model MAG-280 Voltage 220 - 240V, 50 Hz Rated Power 2,200 W Input Power 1,700 W (Oven) 1,700 W (Grill) 1,400 W (Microwave)
- 產品經非認可之技術人員改裝或加裝任何配件; - serial number is modified, damaged or removed from the product. - 機身編號被擅自塗改、破壞或刪除。 4. German Pool will, in its discretion, repair or replace any 4. 總代理有權選擇維修或更換配件或其損壞部份。 defective part. 5. 產品一經被轉讓,其保用即被視作無效。 5. This warranty will be void if there is any transfer of ownership from the original purchaser.
