- Page 1 EUPHORIA EUPHORIA E U P H O R I A EUPHORIA A M P L I F I E R M O D E L S T265 : T465 : T490 : T4125 : M350 : M500 : M1000 : M2000 USER MANUAL Installation Instructions / Owners Manual Due to continous improvement of the product the...
-
Page 2: Safety Precautions
INTRODUCTION SAFETY PRECAUTIONS KEEP YOUR SALES RECEIPT RECOMMENDATION... -
Page 3: Features And Benefits
FEATURES AND BENEFITS Multi-Link The Euphoria M500, M1000 and M2000 have an internal linking circuit that allows you to link two like model amplifiers so that you can double your output power to a single load. When linking two like amplifiers they are split up into master and slave units. The master amplifier becomes the main control for all input signals and gain controls. -
Page 4: Mounting Location
MOUNTING LOCATION POWER CONNECTIONS Ground Remote +12V Fuse Speaker Output Power Output... -
Page 5: Signal Connections
SIGNAL CONNECTIONS SPEAKER CONNECTIONS X-Over Controls OUTPUT INPUT Bass Boost Subsonic Lowpass Gain Remote 18dB 10Hz 40Hz 40Hz 300Hz M350 CLASS A/B MONOBLOCK Speaker Output Ground Remote +12V Fuse Power Output M350 - 2 ohm stable M500 - 1 ohm stable M1000 - 1 ohm stable M2000 - 1 ohm stable INPUT... -
Page 6: Multi - Channel
SPEAKER CONNECTIONS Multi-Link Multi - Channel M500 M1000 M2000 The Euphoria M500, M1000 and M2000 have an internal linking circuit that allows you to link two like model amplifiers so that you can double your output power to a single load. When linking two like amplifiers they are split up into master and slave units. -
Page 7: Adjustments And Settings
ADJUSTMENTS AND SETTINGS ADJUSTMENTS AND SETTINGS ( T265, F465, F490, F4125 ) ( M350 , M500, M100 M2000 ) Built-in Crossover T265 , F465, F490 and F4125 The M350 , M500, M1000 and M2000 are equipped with a variable 24db slope Euphoria network that allows you to select the crossover mode (Highpass—Full Range) and desired feature a variable Bass Boost EQ is set at 45Hz. -
Page 8: Troubleshooting The System
TROUBLE SHOOTING THE SYSTEM SPECIFICATIONS T265 F465 F490 F4125 Peak @ 14.4V : 2 ohms 2 x 85W 4 x 85W 4 x 125W 4 x 195W 4 ohms 2 x 65W 4 x 65W 4 x 90W 4 x 125W 4 ohms bridged 1 x 250W 2 x 250 W...
