LIMITED WARRANTY
DB DRIVE warrants any products purchased in the U.S.A. from
an authorized DB DRIVE dealer. All products are warranted to be free
from defects in material and workmanship under normal use and
service for a period of (1) year when the unit is installed by an autho-
rized DB DRIVE dealer. Non-authorized dealer installed products carry
a one (1) year parts and labor limited warranty. This warranty applies to
the original purchase only.
DB DRIVE will either repair or replace (as its option) any unit
that has been found to be defective and under warranty provided the
defect occurs within:
One (1) year if purchased through an authorized DB DRIVE dealer.
This limited warranty does not extend to units that have been
subjected to misuse, abuse, neglect, or accident. Products that in DB
DRIVE's judgment shows evidence of having been altered, modified, or
serviced without DB DRIVE's authorization, will be ineligible under this
warranty.
To obtain warranty service please contact your retailer or see
our web site at wwwdbdrive.net for more details.
DB Research L.L.P.
302 Hanmore Industrial Parkway // Harlingen, TX 78550
ph: 877.787.0101 // fx: 956.421.4513 // www.dbdrive.net
®
SPA90.2
SPA90.4
SPA1000D SPA1300D
SPA1600D SPA1900D
AMPLIFIERS
Instruction Manual
• Instalation Instructions / Owners Manual •
Due to continuous improvement of the product the Specifications are subject to change without notice.
SPA150.4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DB Drive Speed Series Amplifier SPA SPA1000D
Summary of Contents for DB Drive Speed Series Amplifier SPA SPA1000D
-
Page 1: Limited Warranty
LIMITED WARRANTY DB DRIVE warrants any products purchased in the U.S.A. from an authorized DB DRIVE dealer. All products are warranted to be free from defects in material and workmanship under normal use and service for a period of (1) year when the unit is installed by an autho- rized DB DRIVE dealer. -
Page 2: Safety Precautions
Congratulations on your purchase of a DB Drive state-of-the-art power amplifier. Your selection of a DB Drive car audio product indicates a true appreciation of fine musical reproduction. Whether adding to an existing system or including your DB Drive amplifier in a new system, you are certain to notice immediate performance benefits. -
Page 3: Features And Benefits
EATURES AND BENEFITS DC Offset Protection This circuit protects the output of the amplifier against DC voltage. If for some reason DC voltage is detected at the output stage, the amplifier will shut down protecting the speakers from direct current. Short Circuit Protection The circuit protects the amplifier from damage due to a short found in the speakers or wiring. -
Page 4: Mounting Location
OUNTING LOCATION Before you start the installation, it will be necessary to find a mounting location for the ampli- fier. Find a location in which the amplifier will receive adequate ventilation in order to dissipate the heat it develops during operation. Two popular mounting locations are in the trunk or under the seat. -
Page 5: Signal Connections
IGNAL CONNECTIONS Connect the RCA output of the head unit (AM/FM cassette player, CD, or DAT) to the RCA input terminals of the amplifier. To make these connections, we recommend high quality RCA cables, which are available at your local car audio retailer. Run signal wires away from electrical wires to avoid possibil- ity of induced noise from the car’s electrical system (i.e. - Page 6 PEAKER CONNECTIONS (SPA90.2 , SPA90.4 , SPA150.4) Make the speaker connections using speaker wire that is at least 16 gauge or heavier. As with any audio component, proper phasing of the amplifier and speakers is essential for strong bass response. When connecting, make sure that positive (+) from the amplifier is connected to the positive (+) of the speaker, and the same for negative (-).
-
Page 7: Adjustments And Settings
DJUSTMENTS AND SETTINGS The “Speed Series” amplifiers are equipped with built-in variable crossover networks allow- ing you to select the crossover mode (i.e. Low-Pass/Full/High-Pass or On/Off) and the desired crossover point. For example if you wish to drive a pair of subwoofers, you can select the “Low Pass”... -
Page 8: Specifications
ROUBLE SHOOTING THE SYSTEM We have put together this trouble-shooting guide if you experience problems after installing the amplifier. Please keep in mind that the majority of problems incurred are caused by improper installation and not the equipment itself. In addition, there are many components in the system that could cause various signal problems such as inducted electrical noise and engine noise. -
Page 9: Garantia Limitada
Un (1) años si fue instalado por un técnico autorizado por DB DRIVE , Un (1) año si fue instalado por persona/s no autorizada por DB DRIVE. -
Page 10: Medidas De Seguridad
NTRODUCCIÓN Felicitaciones por su compra del amplificador de potencia SERIE SPEED más moderno en el Mercado. El haber elegido un producto de audio DB DRIVE para su automóvil muestra una verdadera apreciación en reproducción de música de alta calidad. Cualquiera que fuera la razón , mejorar el sitema actual o la adquisición de un sistema completamente nuevo , el amplificador de DB DRIVE le brindará... - Page 11 ARACTERISTICAS Y BENEFICIOS Protección DC Offset Este circuito protege la salida del amplificador contra un voltage DC. Si por alguna razón se detectara un voltage DC en la salida, el amplificador se apagaría de inmediato para proteger a las bocinas de una corriente directa. Protección contra un Corto Circuito.
-
Page 12: Lugar De Montaje
UGAR DE MONTAJE Antes de comenzar con la instalación es necesario encontrar el lugar de montje para el amplificador. Busque un lugar en el cual el amplificador recibirá una ventilación adecuada así podrá disipar el calor que se genera mientras está operando. Dos de los lugares sugeri- dos son la cajuela o debajo del asiento. - Page 13 ONEXIÓNES DE SENALES Conecte la salida del RCA de la unidad de cabecera (AM/FM cassette player, DC or DAT) a la entrada RCA de las terminales del amplificador. Para hacer estas conexiónes, recomendamos cables RCA de alta calidad, los cuales se pueden adquirir en cualquier negocio de venta de audio para autos.
- Page 14 ONEXIÓNES DE BOCINAS (SPA90.2 , SPA90.4 , SPA150.4) Para las conexiónes de bocinas, utilice alambrado para bocinas por lo meno calibre 16 o más pesados. Así como para cualquier componente de audio, para obtener una fuerte salida de bajo es esencial utilzar una correcta fase de amplificador y bocinas.
- Page 15 JUSTES DE INICIO Los amplificadores de “Serie SPEED: están equipados con un network de crossover incor- porados, lo que le permite seleccionar el modo de crossover (ej. Low-Pass/Full/High-Pass or Full) y el punto de crossover que desea. Por ejemplo, si usted desea correr un par de subwoofers, puede seleccionar “Low Pass”...
- Page 16 EPARACIÓN DEL SISTEMA Hemos preparado esta guía de revision o chequeo en caso de que se encuentre con algun tipo de problemas después de la instalación del amplificador. Tenga presente que la mayoría de los problemas son causados por una instalación incorrecta y no necesari- amente por el equipo mismo.
