- Page 1 4W MOBILE CB TRANSCEIVER TCB-1100 I N S T R U C T I O N M A N U A L www.ttikorea.co.kr...
- Page 2 All our products are built to offer excellent value by combining advanced features, great design and manufacturing quality. To ensure you are familiar with the operation and features of your radio, and in order to obtain the best performance, please read this manual carefully before operation. English TCB-1100...
-
Page 3: Table Of Contents
7. How to operated the Transceiver ......14 8. Band Selection ............14 9. Trouble Shooting ............. 15 10. CE Declaration ........... 16 11. Safety Requirement ........... 16 12. Specifications ........... 17 13. Restrictions on the use ........18 14. Frequency Table English 3 TCB-1100... -
Page 4: Introduction
The transceiver should normally be mount- ed horizontally, but may be mounted vertically. The bracket supplied can be fitted above or below the case allowing the TCB-1100 to be cradled by the bracket or suspended from it. - Page 5 This transceiver is also designed to have the DIN size to be directly installed into the audio compartment of your vehicle. For this purpose, use the TTI supplied installation supporting DIN plates. All other connections and installations are same as the above “Normal Installation Using Mounting Bracket.” English 5 TCB-1100...
- Page 6 Installing an Antenna It is very important to select a good quality high efficiency 27MHz antenna. A poor quality antenna or one not designed for the 27MHz band will give very poor performance and could cause damage to the transceiver. English TCB-1100...
-
Page 7: Transceiver Controls And Functions
Front Speaker Channel Selector LCD Display Volume/Power Knob Microphone Jack Mode/LCR/Memory Squelch/DSS Knob Button Emergency Channel Backlight/Lock Button / Menu Button Compander/Tone Button Scan/ Scan Memory Dual Watch/Vox Button Button Antenna Connector S-Meter EXT Jack Power 13.2V DC English 7 TCB-1100... -
Page 8: Front Speaker
6) Mode & LCR & Memory Button Mode & LCR button Mode and LCR : When the transceiver is used in UK,UE,EC,D or D2 frequency band modes this button activates Last Channel Recall function. In all other modes (where national regulations English TCB-1100... -
Page 9: Mode & Lcr & Memory Button
The dual watch icon “DW” stops blinking and the dual watch starts between the selected(secondary) channel primary channel. If you like to change the selected (secodndary) English 9 TCB-1100... -
Page 10: Scan&Scan Memory Button
For user convenience, all the channels are memorized in the list upon shipment from the factory, and “M” is displayed with the memorized channels. To erase the displayed channels from the scan memory list, press and hold the button. English TCB-1100... -
Page 11: Emergency Channel(9/19) & Menu Button
), Off( Call Tone 01-05 and Off( Time-out Timer 1-99 sec., Off( Scan Receive Timer Continue( ), 1-99sec. Scan Delay Timer 1-99 sec, Off( (after receiving signal) High( ), Low( Backlight Dimmer and off Off( Channel Memory 01-40 English 11 TCB-1100... -
Page 12: Squelch & Dss Knob
15) EXT Jack EXT Jack Connecting a loud speaker (This is not supplied) to this port makes the built-in speaker turned off. 16) Power 13.2V DC Power 13.2V DC Connect the power supply cable to this port. English TCB-1100... -
Page 13: Lcd Display
Momentarily press the button to make mute the speaker of the transceiver. PTT Button : While pressing this button, you can transmit. 6 Pin Microphone Connector : Connect this to the microphone jack on the front panel of the transceiver. English 13 TCB-1100... -
Page 14: How To Operated The Transceiver
Italy 40 Ch AM / FM 4W Italy 34 Ch AM / FM 4W Germany 80 Ch FM 4W, 12 Ch AM W Germany 40 Ch FM 4W, 12 Ch AM W Europe 40 Ch FM 4W, 40 Ch AM W English TCB-1100... -
Page 15: Trouble Shooting
Trouble Shooting 9. Trouble Shooting If you experience problems with your TCB-1100 transceiver, first check the power supply source. Poor connection of the power supply source can cause problems such as no transmission, no reception or poor reception, and weak or no sound. Ensure that the microphone and an- tenna are also well connected. -
Page 16: Specifications
Less then 8% @ 1KHz Image Rejection 60 dB Adjacent Channel Rejection 60 dB Conducted Spurious Less than -57dBm Frequency Respons e 300 to 2500Hz Built-in Speaker 8 Ohms, round Adjustable; Threshold less than 1 microvolt Squelch DSS; Less than 2 microvolt English TCB-1100... -
Page 17: Restrictions On The Use
Art. 57 - Law 11/1998 dated 24th April SWEDEN 40Ch -4W FM- Free Use 40Ch -1W AM- Individual License is required 40Ch -4W FM- Individual License is required UK-RA-MPT 1382/MPT1320;UK-R&TTE - S.I.L. 2000:730 POLAND 40Ch -4W FM/AM- Free Use English 17 TCB-1100... - Page 18 Terminal Equipment Directive, 1999/5/EC, and that any ap- plicable Essential Test Suite measurements have been performed. Kind of Equipment : MOBILE CB TRANSCEIVER Type-Designation : TCB-1100 Version (where applicable): This compliance is based on conformity with the following harmonized standards, specifications or documents: ETSI EN 301 489-13 V1.2.1...
