Picture 5-34

5.2.4.3 Sub stream

Go to [Main menu Network Sub Stream] to enter into the interface shown as Picture 5-35
Picture 5-35

5.2.4.4 Email set

Click [Main Menu Network Email] option to enter into the email set interface shown as Picture 5-36
Picture 5-36
Picture 5-37
Friendly Reminder: The router's port forwarding
interface may be different, however, when entering into
virtual server, user will always need forward port (range:
1025~65535) of router to IP address of DVR allocated
or automatically captured, and select [All] or [Both] in
corresponding protocol column and save the above
setting.
Above steps may differ from the router device
depending on the manufacturer.
Video: allow you open or close the sub stream output. If
you select "Enable" system will select sub-stream preview
and guarantee image quality once network is unstable.
Frame rate: allow you set net transmittal frame rate. User
could select the relative value by pull-down menu.
Bit rate: allow you set net transmittal bit rate. User could
select the relative value by pull-down menu.
Audio: When tick-selecting the option, system will record
video and audio simultaneously.
SSL: is a security link transport protocol. You can
encrypt your communication info (including your email)
using SSL to prevent hackers from monitoring your
email or communication info and even your password.
Please set SSL to "On" via Gmail.com server, and set
to "Off" via other mail server.
SMTP Port: indicate one kind of mail transmittal
port opened by Simple Message Transfer Protocol
(SMTP). The port number for most mails is 25
except such as Gmail server (Port No.: 465).
SMTP server: indicates server address you used.
Sender address:
address. The email address should be consistent
with the server you use. That is to say, when you
use email address – aaa@gmail.com, the
according server should be smtp.gmail.com.
Receiver address: indicates receiver's email
address. The email address is used to receive
image transmitted from DVR alarm. Please clear
the images you have received as soon as possible
to avoid overloading your email account.
18
indicates sender's
User Manual
email
