Basic Display Screens

Wake-up Screen

This is the first screen that is displayed when you "wake up" your pump.
It shows the time of day, a battery life indicator, if you have an extended
bolus or temp basal currently active, current basal rate amount and how
much insulin remains in your cartridge. You access the Main Menu from
here or you can take a shortcut to the Status menu. After a set amount of
time with no button presses, the pump will "go to sleep" to conserve
battery life. When the pump is in sleep mode, the screen display is blank.
Press any button to wake up your pump.

Main Menu Screen

This screen shows all Main Menu options.

Bolus

This selection takes you to the Normal Bolus screen. If you have
activated Advanced Bolus features, the Bolus Menu will be displayed.
Here you can select bolus options, program and activate your bolus dose.
Consult your healthcare team for your personal settings for calculations of
food and correction boluses.

Suspend/Resume

The Suspend function stops all insulin deliveries and Resume restarts basal delivery.

History

This option allows you to review History of boluses, total daily dose (TDD), alarms, primes,
suspend and basal information.

Basal

The basal menu allows you to access and program your 24 hour basal rate. This continuous
rate maintains your blood sugar between meals. This rate will be calculated by your healthcare
team. The default basal menu will display one basal program and the Temp Basal option. You
can activate additional basal program options with the Setup Advanced menu.

Setup

This menu allows you to personalize the settings and features of your IR 1200, as well as add
advanced features to the menu. Your healthcare team will advise you on which features are
best suited for your plan of treatment, as well as train you to achieve the best results.

Prime/Rewind

This function enables you to properly align the cartridge and piston rod as well as prime your
infusion set tubing before connecting to the pump.

Status

This feature allows you to quickly see your current/most recent settings and pump deliveries.
Page 21
