Network Configuration
The receiver will require the introduction of the needed parameters to be able to
get connected to a network, as well as to be visible to other equipments so that
receive streaming of video and audio.
You should introduce the following parameters:
IP Address
Subnet Mask
IP LAN Soft:
MAC
You can move through the menus with the buttons
With the Red button you delete the last character.
Press OK to save the changes.
Search IP Channels
The receiver will carry out a search for channels broadcasted by other equipment
connected to the network.
You can receive transmissions of other equipment in mode Unicast and
Multicast.
- Unicast is when the information is sent from a unique sender to a
unique receiver.
- Multicast in when the information is sent through a network to multiple
destinations simultaneously. The equipment that work in multicast mode
send the information into an IP range between 224.0.0.0 and
239.255.255.255.
In Search Type select Auto to search for all the channels which are broadcasted
by other equipment in your network in multicast mode. If you select the Host
option, it will look for transmissions of the equipment present in the list Network
Management that you select.
In the field Multiplex you should select the hosts from the list Network
Management in which you with to search for channels.
Pressing the Blue button or
the hosts.
You can move the cursor with
With the Green button you select the hosts.
Press Exit to go back to the search menu.
If you press the Green button, it will carry out a search of the video IP channels.
Press Exit to exit.
The Fast install guide is now finished.
Technical changes and mistakes reserve
User's manual · MAX IP90
Number of 32 bits expressed in 4 numbers between 0
and 255 which identifies the receiver inside its network.
Every device in the network should have a different IP
Address and it is highly recommended that all of them
are in the same subnetwork and with IP addresses into
the following range:
10.x.x.x
172.16.0.0 – 172.31.255.255
192.168.x.x
Number in IP format that, combined with the IP address, identifies where the equipment is.
IP address of the PC where the application for exchanging video streamings between the
PC and the receiver is installed.
If you want, you can download the application IP LAN Soft from the Website:
www.ftemaximal.com
Device address at hardware level. It is unique in each device and it comes from the factory.
a new window will appear, where you can select
and
.
9
- -
.
