Fast Installation Guide - FTE Maximal MAX IP90 User Manual

1.4.

Fast installation guide

Please, follow the instructions for a faster and simpler installation of the receiver.
Step 1: Connections
Connect the ETHERNET input of the receiver to the network.
Connecting TV set, LCD or video beamer:
Scart This is the connector which will be normally used to connect the TV.
For this purpose, you will need a Scart – Scart connector.
You can obtain further information in chapter 0.2 Receiver back panel.
When you set up the system for the first time, the current date will be stored in Menu > System Settings > Version
as beginning date for the warranty period.
Step 2: Main settings on receiver
When you start the first time the receiver or when you execute a "factory default" process, you will see this
installation guide in English language.
The selection of the menu options will be done with the arrow buttons
OK of the remote control.
Please, choose the code for your remote control in the first window.
Fte Maximal gives you the possibility of using a IP, a DVB-T and a DVB-S
receivers at the same time.
For this purpose, your new receiver is selected by factory with code 3.
You have the possibility to change the code of it, to do that you have to change the
position of a switch in the remote control.
You have to select the same position in the receiver than in the remote control.
If you have problems with remote control devices, you can change the transmission
code if you go to Menu > System Settings > OSD Settings
after finishing the quick installation guide.
Menu Language:
Here you have to select the language for the Receiver menu and information.
Select the language with the arrow buttons
Time Zone:
In order to the receiver is able to display the correct time and adjust the timer
recordings correctly, it is needed to fix the time zone to the place you live.
Select here the time delay according to your position comparing to Greenwich Time.
In UK: Summer time: +1 hours
Winter time:
Select with the arrow buttons
Date and Time
It is recommended to setup the clock before starting to enjoy the receiver.
Select with the entry you want to change.
The entry will be modified by the buttons
When you have finished, press OK.
Technical changes and mistakes reserve
User's manual · MAX IP90
and press the
GMT hour
and press the OK button.
.
OK button.
8
- -
, and the button
MAX IP90 Version en_1.0 FTE Maximal
