User's manual · MAX IP90
6.5.

TV Settings

Here you can adapt your receiver to your TV set and you can select
the screen format.
TV-System
Select here which TV system your TV set support.
Selection: NTSC, PAL, Secam and AUTO
Please change with the buttons .
TV-Format
Select here which TV format your TV set has available.
Selection: 4:3, 16:9 and AUTO, please change it with the buttons .
RF Mode
If you connect your TV or Video set with one IEC coaxial connection at the
output TO TV, you will need to select which system is supported by this device.
Options: PAL M, B/G, I, D/K or NTSC , please change them with the buttons .
RF Channel
Here you can select which channel the modulator has to use.
This is only needed if you connect your receiver with the IEC coaxial connection at the
output TO TV to your TV set.
Selection: Channel 21 to 69 , please change with the buttons .
Picture Format
This option is only available when you have not selected TV format in mode AUTO.
Options: Pan&Scan or Letter Box , please change with the buttons .
In this option you can choose how the pictures in films with a big format will be adapted to your TV set.
If you select Pan&Scan you will see one part of the film and at the left and right sides it will be cut
In Letter Box, the picture will become smaller and you will see on top and bottom two black bars.
TV output
This option allows choosing how the receiver will send the colours to the TV set.
Selection: CVBS , RGB, SVIDEO or YUV , please change with the buttons .
Loop VCR
Here you select the priority of an external video signal.
If you have selected Slave, the receiver shows every time the signal coming from the VCR Scart connector, when there
is signal available. It also can be a signal from DVD player or recorder.
If you have select Master , the signal from receiver has priority and you will see only the signal from connector VCR
scart when the receiver is in Standby mode.
Selection: Master or Slave , please change with the buttons .
LPC Mode
Not available in this model.
Sleep
If you want shut down the receiver automatically, you can choose here the time for the sleep timer.
Selection: 15, 30, 45, 60, 75, 90, 105, 120 or Sleep Off
Please change it with the buttons .
6.6.

OSD Settings

Remote control
Here you can change the transmission code for the remote control if you
have problems with other devices.
Please change it with the buttons .
For saving the changes, please press OK .
20
- -
Technical changes and mistakes reserve MAX IP90 Version en_1.0 FTE Maximal
