Do not forget to change also the code on the remote control.
For this, you have to change the position of a switch in the remote control.
You have to select the same position in the receiver than in the remote
control.
Info bar delay
Here you can select how long the information of the OSD will be displayed
on the screen.
Selection: 1 to 10 sec.
Please change it with the buttons
Number of Sequential Channel
Selecting Yes in this option, the positions of the channels will be occupied continuously and sequentially. Although you
move the position of one channel, you will shift the positions to avoid leaving empty channels.
Selecting No, you can leave empty channels if we shift the position of one channel.
6.7.

Version

Here you get information about the hard and software from your receiver.
Manufacturer Manufacturer of the receiver.
Model Exact article name.
Hardware Revisions number from main PCB
Loader Version for boot loader
Software Version for installed software
FP Not available in this model
Guarantee Beginning of the warranty time
CRC Checksum of the EEprom
6.8.

Factory Default

With this option you can restore the receiver totally to the status when
the receiver was used the first time.
Caution: Make this only if you are 100% sure, this step can
is irreversible.
6.9.

Software Upgrade

With this menu you can transfer data and install new software.
With the buttons
possibilities.
Serial port (Download)
Air (now)
Air (programmed)
Technical changes and mistakes reserve
User's manual · MAX IP90
.
you can choose between the following
Start data download via RS-232 connection.
Starts data download via OTA immediately
Starts data download via OTA at a programmed time
21
- -
