Page 1: Instruction Manual
INSTRUCTION MANUAL Portable LCD TV(7 ) TV-4455TFT DEAR CUSTOMER In order to achieve the best performance of your product, please read this instruction manual carefully before using, and keep it for future reference. If you need extra support, please write to info@premiermundo.com... - Page 2 This sign means that there are important instructions of operation and handling in the manual that comes with this Device. PREMIER CUSTOMER SERVICE 0800 ELECTRIC (353-2874) Venezuela: 01-900-331-PEJC (7352)
- Page 3 1. Precautions 1. Storage Do not store this device in the environment with extreme temperature; the appropriate storage temperature is -20~60 , and the operating temperature is -5~40 ; Do not use this device in the bathtub, washbasin, kitchen, washtub and other place with water or moist basement, swimming pool or similar places;...
-
Page 4: Packing List
4. Notice for battery charging/discharging To protect the battery, do charge if the electricity is full; frequent overcharging will damage the battery; It is normal that the battery become hot during charging; if the battery temperature exceeds 60 , it may be abnormal; please cut off the power supply and contact qualified personnel;... - Page 5 Appearance 1. Remote-control receive window 2. Power indicator/ Red:standby / Green:Power-on 3. Power indicator 4. MENU: Menu button 5. EXIT:Return button 6. CH / :Channel Select(Downward/Upwand)button 7. OK/MUSIC: Confirm button/Music Background button 8. VOL / : Volume(down/Left up/Right)ward button 9. TFT-LCD screen 10.
-
Page 6: Description Of Panel Buttons
Description of Panel Buttons Warning: 1. POWER/MODE: in standby state, press it to turn on the device; in power on state, press it to switch among TV, CARD and AV, press and hold for three seconds to enter standby state; 2. -
Page 7: Basic Operation Methods
MENU: menu key; in CARD state, switch the main interface between USB and CARD; MUTE: mute key; INFO: press this key to show the character or usage state of current program; SLEEP: sleep time setting; for schedule power off in 120min; MODE: press it to switch among TV, CARD and AV state;... -
Page 8: Menu Operation
2. AV converter cable connection: AV converter cable (1)AV-IN: connect the external video cable to the yellow terminal port of the AV converter cable, connect the cable of left audio track to the white terminal port of the AV converter cable, connect the cable of right audio track to the red terminal port of the AV converter cable, and then connect the AV converter cable to... - Page 9 3.CLOCK The options on the screen include clock, power on time, power off time, alert time, appointment time and appointment program: Press to select an option, and press to set. Note: Other items can be set after the clock is set. The time for all option settings is up to 24 hours.
- Page 10 5.1. Press to select option PROGRAM : press to set the channel number. 5.2. Press to select option MEMORY : Press to select ON or OFF; in normal watching, set to ON and this channel is shown when switching the channel; set to OFF and this channel isn't shown when switching the channel.
- Page 11 6.3. Press to select option ANTENNA : Press to select AIR, CATV-STD, CATV-HRC or CATV-IRC. 6.4. Press to select option AUTO SCAN : press to scan automatically. Normal watching operation: 1. Open function setting option and set the OSD language. 2.
-
Page 12: Card Mode Operation
9. CARD mode operation 1. Proper operation of memory device This device supports various kinds of USB, Multimedia Card (MMC), SD, and Memory Stick (MS) on the market. 1) The capacity of USB and CARD storage device is 4GB (larger capacity may be not supported). - Page 13 3) Playing movie Press the direction key to select MOVIE option, press OK to open the storage device, press the UP/DOWN key to select a desired file and press OK to play. 4) Lantern slide Press the direction key to select SLIDE option, press OK to open the storage device, press the UP/DOWN key to select a desired file and press OK to play.
-
Page 14: Troubleshooting Methods
10. Troubleshooting methods If the device has any failure, please follow the method below to check. If the problem still can't be resolved, please contact the After-service Department of our company. No picture, no sound: power adapter or vehicle adapter isn't connected properly; unapproved power adapter is used;... -
Page 15: Technical Parameters
11. Technical parameters Model: JV-VC768A Product name: LCD Color TV Receiver Display component: Color TFT-LCD Receiving frequency range: full frequency scan: 48.25MHz-863.25MHz Fixed channel search: AIR: 55.25MHz-801.25MHz CATV: 55.25MHz-799.25MHz Screen size: 7 inches Resolution: 480 (H) 234 (V) Speaker: 27mm 2 Output power: 0.5W Connections: Antenna connect port, AV IN/OUT port, headphone port, power input port... - Page 16 WARNING This manual is for reference only. The content is subject to change without prior notice. If there are any unknown errors or omissions, JEJA reserves the right of interpretation. There is no component can be repaired in the device. Do not attempt to open the TV.
