C&T Solution CT-XHW0X User Manual

Intel 4 generation core processor i7/i5/i3/celeron industrial mini-itx motherboard
Hide thumbs
Table of Contents

Advertisement

Quick Links

CT-XHW0X
th
Intel® 4
Generation Core™ Processor i7/i5/i3/Celeron
Industrial Mini-ITX Motherboard
User's Manual
Version 2.0
C&T Solution Inc.
17F -2, No.700, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan
TEL: 886-2-77317888
http://www.candtsolution.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CT-XHW0X and is the answer not in the manual?

Questions and answers

Related Manuals for C&T Solution CT-XHW0X

Summary of Contents for C&T Solution CT-XHW0X

  • Page 1 CT-XHW0X Intel® 4 Generation Core™ Processor i7/i5/i3/Celeron Industrial Mini-ITX Motherboard User’s Manual Version 2.0 C&T Solution Inc. 17F -2, No.700, Zhongzheng Rd., Zhonghe Dist., New Taipei City 235, Taiwan TEL: 886-2-77317888 http://www.candtsolution.com...

  • Page 2: Table Of Contents

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Table of Contents Preface ....................５ Disclaimer ................. ５ Copyright Notice ............... ５ Trademarks Acknowledgment ..........５ Introduction ..................... ７ Product Description ..............７ Specifications ................８ Block Diagram ............... １０...
  • Page 3 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB RJ-45 LAN & USB 3.0 Connectors: CN14/CN15.... ２８ 3.4.5 Front Audio Jack: CN29 ..........２９ 3.4.6 Jumper Setting ..............２９ Clear CMOS: JP1 ............２９ 3.5.1 Backlight Power: JP6 ............. ２９...
  • Page 4 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB F81866 Hardware Monitor ..........５１ 5.2.9 Serial Port Console Redirection ........５３ 5.2.10 Chipset .................. ５６ PCH-IO Configuration ............ ５７ 5.3.1 System Agent (SA) Configuration ........６２ 5.3.2 Boot ..................６７...

  • Page 5: Preface

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB I. Preface 1.1 Disclaimer All specifications and information in this User’s Manual are believed to be accurate and up to date. C&T Solution Inc. does not guarantee that the contents herein are complete, true, accurate or non-misleading. The information in this document is subject to change without notice and does not represent a commitment on the part of C&T Solution Inc.
  • Page 6 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB All other products and trademarks mentioned in this manual are trademarks of their respective owners. ６...

  • Page 7: Introduction

    Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB II. Introduction 2.1 Product Description The CT-XHW0X is a single board computer in the Mini-IXT form factor. Its LGA1150 socket is for Intel® 4 Generation Core i7/i5/i3/Celeron processor, which is with the new 22 nm process technology. The two 240-pin DIMM sockets are for dual channel DDR3/DDR3L 1333/1600MHz memory with maximum capacity up to 32GB.

  • Page 8: Specifications

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 2.2 Specifications   Intel® 4 Generation Core i7/ i5/ i3/Celeron processor  LGA1150 socket  Chipset  Intel® Q87/H81 PCH  System Memory  Two 240-pin DDR3/DDR3L DIMM sockets ...
  • Page 9 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB  4 x SATA3 ports (2 x SATA3 for H81 SKU)  6 x USB2.0 ports  3 x RS-232 ports  1 x 8-bit GPIO  1 x front panel audio ...

  • Page 10: Block Diagram

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 2.3 Block Diagram Channel A DDR3 PCIE 3.0 x 16 PEG x 16 1333/1600MHz 240pin DDR3/L DIMM DDI1 HDMI LGA1150 DDI2 Channel B DDR3 1333/1600MHz 240pin DDR3/L DIMM DDI3 SWITCH...

  • Page 11: Sku

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 2.4 SKU Product Processor Features Number CT-XHW01 Intel 4 2xDDR3, DP, HDMI, VGA, DVI-D, LVDS, PCIex16, LGA1150 2xGbE, 4xUSB3.0, 12xUSB2.0, 4xSATA, 4xCOM, mini-PCIe, Audio, PS/2 KB/MS. GPIO, iAMT9.0 CT-XHW03 Intel 4...

  • Page 12: Mechanical Specification

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB III. Mechanical Specification Module Dimensions The PCB size of CT-XHW0X is 170mm x 170mm, the standard mini-ITX size. １２...

  • Page 13: Layout

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Layout DIMM_2 DIMM_1 LGA115 MINI_ PCIE LVDS USB_3 USB_2 ATX_ CN33 FAN1 USB_1 COM2 CN25 CN30 FAN2 COM3 CN17 FRONT_ COM4 AUDIO CN26 CN16 CN14 CN15 CN29 １３...

  • Page 14: Connectors

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.2.1 Connectors Connector Description ATX_POWER ATX Power Connector ATX_CPU CPU Power Connector SATA Port 1 Connecter SATA Port 2 Connecter SATA Port 3 Connecter (Reserved on H81 SKU) SATA Port 4 Connecter (Reserved on H81 SKU) COM 1 (RS-232/422/485) &...

  • Page 15: Internal Connectors

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.2.2 Jumper Jumper Description Clear CMOS Backlight Power Selection Panel Power Selection Internal Connectors 3.3.1 ATX Power Connector: ATX_POWER Connector Type: 2x12-pin standard ATX power connector Signal Signal +3.3V +3.3V +3.3V...

  • Page 16: Sata Iii Connectors: Cn1, Cn2, Cn3 & Cn4

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.3.3 SATA III Connectors: CN1, CN2, CN3 & CN4 Connector Type: 7-pin SATA connector Signal SATA_TX+ SATA_TX- SATA_RX- SATA_RX+ 3.3.4 GPIO Connector: CN17 Connector Type: 2x5-pin pitch 2.0mm wafer connector...

  • Page 17: Jtag Connector: Cn30

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.3.7 JTAG Connector: CN30 Connector Type: 2x5 pin pitch 1.27mm Signal Signal +3.3V 3.3.8 LPC Port: CN33 Connector Type: 2x5 pin pitch 1.27mm Signal Signal 3.3V LPC_AD3 N.C. LPC_AD2 RESET_DBG...

  • Page 18: Memory Sockets: Dimm_1/Dimm_2

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.3.11 Front Panel Audio Connector: Front_Audio Connector Type: 2x5-pin pitch 2.54mm pin header connector Signal Signal MIC-IN-L AGND MIC-IN-R PRESENCE# LINE-IN-R MIC-IN Detect SENSE_SEND LINE-IN-L LINE-IN Detect 3.3.12 Memory Sockets: DIMM_1/DIMM_2 Connector Type: 240-pin DDR3/DDR3L DIMM socket 3.3.12.1 DIMM_1...
  • Page 19 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Pin Signal Front Pin Signal Front Pin Signal Back Pin Signal Back M_DQS_A_DN2 M_DQS_A _DN4 M_DQS_A_DP2 M_DQS_A _DP4 M_DATA_A22 M_DATA_A38 M_DATA_A18 M_DATA_A34 M_DATA_A23 M_DATA_A39 M_DATA_A19 M_DATA_A35 M_DATA_A28 M_DATA_A44 M_DATA_A24 M_DATA_A40...

  • Page 20: Intel 4Th Gen Core Processor I7/I5/I3/Celeron Industrial Mini-Itx Mb

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Pin Signal Front Pin Signal Front Pin Signal Back Pin Signal Back M_MAA_A4 SPD_A2 DDR_15V DDR_15V DDRVTT M_MAA_A3 DDRVTT 3.3.12.2 DIMM_2 Pin Signal Front Pin Signal Front Pin Signal Back...
  • Page 21 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Pin Signal Front Pin Signal Front Pin Signal Back Pin Signal Back M_DATA_B25 M_DATA_B41 M_DQS_B_DN3 M_DQS_B_DN5 M_DQS_B_DP3 M_DQS_B_DP5 M_DATA_B30 M_DATA_B46 M_DATA_B26 M_DATA_B42 M_DATA_B31 M_DATA_B47 M_DATA_B27 M_DATA_B43 M_DATA_B_CB4 M_DATA_B52 M_DATA_B_CB0 M_DATA_B48...

  • Page 22: Pci Express X16 Connector: Pcie_X16

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.3.13 PCI Express x16 Connector: PCIE_x16 Pin Signal Pin Signal Pin Signal Pin Signal + 12V B42 PETn6 A42 GND N.C. + 12V B43 GND + 12V A43 PERp6 N.C.

  • Page 23: Mini Pcie Connector: Cn37

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Pin Signal Pin Signal Pin Signal Pin Signal B35 GND B76 GND A35 PERp4 A76 PERp14 B36 GND B77 GND A36 PERn4 A77 PERn14 B37 PETp5 B78 PETp15 A37 GND...

  • Page 24: Lvds Connector: Lvds

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.3.15 LVDS Connector: LVDS Connector Type: 2x15pin pitch1.25mm LVDS connector Signal Signal LVDS_B3- LVDS_B3+ LVDS_B_CLK- LVDS_B_CLK+ LVDS_B2- LVDS_B2+ LVDS_B1- LVDS_B1+ LVDS_B0- LVDS_B0+ LVDS_I2C_DAT LVDS_I2C_CK LVDS_A3+ LVDS_A3- LVDS_A_CLK+ LVDS_A_CLK- LVDS_A2+ LVDS_A2-...

  • Page 25: External Connectors

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB External Connectors CN25 CN16 CN14 CN15 CN29 (CN15: USB2.0 for H81) 3.4.1 Keyboard & Mouse Connectors: CN26 Signal Signal KB_DATA MS_DATA KB_CLK MS_CLK 3.4.2 USB 2.0 Connectors: CN16 Signal Signal...

  • Page 26: Com1 & Dvi-I Connectors：cn7

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Signal Signal DPC_TX3- DNG_DET N15231297 DP_AUX_P DP_AUX_N DP2_HDP_F +3.3V 3.4.3.2 HDMI (Bottom) Signal Signal HDMI_TX2_DP_B HDMI_TX2_DN_B HDMI_TX1_DP_B HDMI_TX1_DN_B HDMI_TX0_DP_B HDMI_TX0_DN_B HDMI_CLK_DP_B HDMI_CLK_DN_B HDMI_SCLDDC_B HDMI_SDADDC_B HDMI_PLUG_B20 3.4.4 COM1 & DVI-I Connectors：CN7 3.4.4.1 COM1 (Top);...
  • Page 27 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.4.4.1.2 RS-422 Signal Signal TXD-, Transmit Data RXD+, Receive Data TXD+, Transmit Data RXD-, Receive Data 3.4.4.1.3 RS-485 Connector Signal Signal TXD-, Transmit Data RXD+, Receive Data TXD+, Transmit Data RXD-, Receive Data 3.4.4.2 DVI-I (Bottom)

  • Page 28: Lan & Usb 3.0 Connectors: Cn14/Cn15

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.4.5 RJ-45 LAN & USB 3.0 Connectors: CN14/CN15 3.4.5.1 RJ-45 (Top) Signal MDI0+ MDI0- MDI1+ MDI2+ MDI2- MDI1- MDI3+ MDI3- LED A Status LED B Status Yellow Active Speed 10...

  • Page 29: Jumper Setting

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 3.4.6 Front Audio Jack: CN29 Signal A (Green) Line-Out B (Pink) Mic-In Jumper Setting 3.5.1 Clear CMOS: JP1 Function Setting Jumper Normal (Default) 1-2 closed Clear CMOS 2-3 closed 3.5.2...

  • Page 30: Features & Interfaces

    Direct Media Interface (DMI), Digital Display Interface (DDI) and PCI Express. 4.2 BIOS The AMI uEFI BIOS, 8MB SPI Flash Rom is used in the CT-XHW0X module. 4.3 System Memory The Integrated Memory Controller (IMC) of the processor supports DDR3/DDR3L protocols with two independent, 64-bit wide channels.

  • Page 31: Usb

    DisplayPort, HDMI, LVDS or DVI, and one dedicated Intel FDI Port for legacy VGA support on the PCH. The 3 displays configuration of the CT-XHW0X is one DP, one HDMI and one of the three: LVDS, DVI or VGA.

  • Page 32: Pci Express

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Signal Description Serial ATA or SAS transmits differential pairs. SATA_TX+ SATA_TX- Serial ATA or SAS receives differential pairs. SATA_RX+ SATA_RX- 4.8 PCI Express The processor contains one PCI Express controller that supports one external x16 PCI Express Graphics port.

  • Page 33: Lpc

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Signal Description Gigabit Ethernet Controller 0: Media Dependent MDI[0:3]+ Interface Differential Pairs 0, 1, 2, 3. The MDI MDI[0:3]- can operate in 1000, 100 and 10 Mbit/sec modes. Some pairs are unused in some modes,...

  • Page 34: Gpio Configuration

    GPIO index/data port. The index port is the base address +0 and the data port is the base address +1. To access the GPIO register, write index to the index port, and then read/write from/to data port. The configuration on CT-XHW0X is described as below. Index Port 0xA00...

  • Page 35: Watchdog Timer

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Bit X = 1 means Output Mode 4.13.1.2.2 GPIO Output Data Select  GPIO Output Data Register (Index port=0xA00, Data port=0xA01, Offset=0x89) Bit 7 Bit 6 Bit 5 Bit 4...

  • Page 36: System Bios

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB V. SYSTEM BIOS The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset.
  • Page 37 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB System Date: MM/DD/YYYY System Time: HH:MM:SS Use Tab to switch between Date and Time elements. ３７...

  • Page 38: Advanced

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2 Advanced ３８...

  • Page 39: Acpi Settings

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.1 ACPI Settings System ACPI Parameter Setting. ３９...

  • Page 40: Cpu Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.2 CPU Configuration Enables or disables BIOS ACPI Auto Configuration. ４０...
  • Page 41 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB Limit CPUID Maximum: Disabled for Windows XP. Execute Disable Bit: XP can prevent certain classes of malicious buffer overflow attacks when combined with a supporting OS (Windows Server 2003 SP1, Windows XP SP2, SusE Linux 9.2, RedHat Enterprise 3 Update 3.)

  • Page 42: Sata Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.3 SATA Configuration The BIOS automatically detects the presence of SATA device and the hardware installed in the SATA ports will be showed in the configuration. Each port can be enabled or disabled individually.
  • Page 43 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB SATA Mode Selection: Select the IDE, AHCI or RAID mode for SATA controller operations. Hot Plug: Designates this port as Hot Pluggable. SATA Device Type: Identify the SATA port is connected to Solid State Drive or Hard Disk Drive.
  • Page 44 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.3.1 Software Feature Mask Configuration ４４...

  • Page 45: Pch-Fw Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.4 PCH-FW Configuration Firmware Update Configuration: Enable/Disable Me FW Image Re-Flash function. ４５...

  • Page 46: Amt Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.5 AMT Configuration Enable or disable Intel® Active Management Technology BIOS Extension. Note: iAMT H/W is always enabled. This option just controls the BIOS extension execution. If enabled, this requires additional firmware in the SPI device ４６...

  • Page 47: Usb Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.6 USB Configuration Legacy USB Support: AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. EHCI Hand-off: This is a workaround for OSes without EHCI hand-off support.

  • Page 48: Smart Settings

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.7 SMART Settings ４８...

  • Page 49: F81866 Super Io Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.8 F81866 Super IO Configuration ４９...
  • Page 50 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.8.1 Serial Port 0 Configuration ５０...

  • Page 51: F81866 Hardware Monitor

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.9 F81866 Hardware Monitor ５１...
  • Page 52 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.9.1 Smart Fan Mode Configuration ５２...

  • Page 53: Serial Port Console Redirection

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.10 Serial Port Console Redirection ５３...
  • Page 54 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.10.1 COM0 Console Redirection Settings ５４...
  • Page 55 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.2.10.2 EMS Console Redirection Settings ５５...

  • Page 56: Chipset

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3 Chipset ５６...

  • Page 57: Pch-Io Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.1 PCH-IO Configuration ５７...
  • Page 58 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.1.1 PCI Express Configuration Each PCI Express Port from 1 to 8 can be setup except Port 2, which is assigned to Lan. ５８...
  • Page 59 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.1.1.1 PCI Express Root Port 3.3.12.4 Each PCI Express Root Port can be enabled or disabled individually. ASPM: Set the ASPM level Force L0s – Force all links to L0s State AUTO –...
  • Page 60 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.1.2 USB Configuration ６０...
  • Page 61 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.1.3 PCH Azalia Configuration ６１...

  • Page 62: System Agent (Sa) Configuration

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.2 System Agent (SA) Configuration ６２...
  • Page 63 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.2.1 Graphic Configuration ６３...
  • Page 64 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.2.1.1 LCD Control ６４...
  • Page 65 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.2.2 NB PCIe Configuration ６５...
  • Page 66 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.3.2.3 Memory Configuration ６６...

  • Page 67: Boot

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.4 Boot Boot Configuration: Number of seconds to wait for setup activation key. 65535 (0xFFFF) means indefinite waiting. Bootup NumLock State: Select the keyboard NumLock state. Fast Boot: Enables or disables boot with initialization of a minimal set of devices required to launch active boot option.

  • Page 68: Csm16 Parameters

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.4.1 CSM16 Parameters OpROM execution, boot options filter, etc. GateA20 Active:
 [Upon Request] – GA20 can be disabled using BIOS services. [Always] – do not allow disabling GA20; this option is useful wen any RT code is executed above 1MB.

  • Page 69: Csm Parameters

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.4.2 CSM Parameters OpROM execution, boot options filter, etc. Launch CSM: This option controls if CSM will be launched always or never. Boot option filer: This option controls what devices system can boot to [UEFI and Legacy], [Legacy only] or [UEFI only].
...

  • Page 70: Security

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.5 Security Administrator’s and User’s passwords could be set. If ONLY the Administrator’s password is set, then this only limits access to Setup and is only asked for when entering Setup. If ONLY the User’s password is set, then this is a power on password and must be entered to boot or enter Setup.

  • Page 71: Secure Boot

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.5.1 Secure Boot ７１...

  • Page 72: Save And Exit

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 5.6 Save and Exit Save Changes and Exit: Exit system setup after saving the changes. Discard Changes and Exit: Exit system setup without saving any changes. Save Changes and Reset: Reset the system after saving the changes.

  • Page 73: Address Map

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB VI. Address Map 6.1 I/O Port Address Map The assignment of the I/O port addresses for the XHW0X under Windows® 7 Ultimate/64bit are shown below. ７３...
  • Page 74 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB ７４...

  • Page 75: Interrupt Controller (Irq) Map

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 6.2 Interrupt Controller (IRQ) Map The interrupt controller map for the CT-HXW01 under Windows® 7 Ultimate/64bit are as shown below. ７５...
  • Page 76 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB ７６...
  • Page 77 CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB ７７...

  • Page 78: Memory Map

    CT-XHW0X Intel 4th Gen Core Processor i7/i5/i3/Celeron Industrial Mini-ITX MB 6.3 Memory Map The memory map of DRAM for the CT-HXW01 under Windows® 7 Ultimate/64bit are shown below. ７８...
