- Page 1 USER’S MANUAL CT-PBT01 Series PICO-ITX SBC...
-
Page 2: Table Of Contents
CT-PBT01 | User’s Manual Table of Contents Safety Information ………….……………………….……………………………………………. 03 About This Guide ……….…………………………….……………………………..……………. 04 Packing List ……………….…………………………….……………………………………………. 05 Ordering Information …………………………………………………………………………….. 05 Revision History ….…….…………………………….……………………………………………. 05 Chapter 1 Product Introductions ……………………………………………………...… 06 Hardware Specification …………………………………..………….………..……..….…….. 07 Block Diagram ….…………………………………….…..………….………..…...………… 08 Board Dimensions ………………………………..……..………………………….………..……... -
Page 3: Safety Information
Preface CT-PBT01 | User’s Manual Safety Information Electrical Safety To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. -
Page 4: About This Guide
Preface CT-PBT01 | User’s Manual About this guide This user guide contains the information you need when installing and configuring the motherboard. How this guide is organized This manual contains the following parts: Chapter 1: Product introduction This chapter describes the features of the motherboard and the new technology it supports. This chapter also lists the hardware setup procedures that you have to perform when installing system components. -
Page 5: Packing List
Preface CT-PBT01 | User’s Manual Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: Item Description Q’ty CT-PBT01 PICO-ITX SBC Heat Sink Audio Cable 20cm COM Cable 2*10P-2*DB9 22cm Power Cable 10cm SATA Cable 30cm SATA Power Cable USB Cable... -
Page 6: Chapter 1 Product Introductions
Chapter 1 Product Introductions... -
Page 7: Hardware Specification
Chapter 1: Product Introductions CT-PBT01 | User’s Manual 1.1 Hardware Specification System Internal I/O • CPU: Intel® Celeron® Processor J1900 • Display: (2.0GHz/4C/10W) - 1x LVDS - 1x LVDS backlight • System Chipset: SoC integrated • COM: 1x RS-232/422/485, 1x RS-232 •... -
Page 8: Block Diagram
Chapter 1: Product Introductions CT-PBT01 | User’s Manual 1.2 Block Diagram DDR3L SODIMM Dual Channel DDRIII 1066/1333 MHz GIGA LAN SATA SATA Port 0 PCI-Express x1 I120AT Mini-PCIE PCI-Express x1 DDI0 HDMI Bay Trail-D Mini-PCIE / mSATA PCI-Express x1 18bit CH7511B DDI0 LVDS... -
Page 9: Board Dimensions
Chapter 1: Product Introductions CT-PBT01 | User’s Manual 1.3 Board Dimensions Unit: mm Board dimension layout (Top side) Board dimension layout (Bottom side) Board dimension layout (coastline) - Page 10 Chapter 1: Product Introductions CT-PBT01 | User’s Manual Unit: mm Board dimension layout (Top side) Board dimension layout (Bottom side) Board dimension layout (coastline with heatsink)
-
Page 11: Connectors
Chapter 1: Product Introductions CT-PBT01 | User’s Manual 1.4 Connectors Top View (CN15) (CN9) (CN18) (CN33) (CN30) mSATA GPIO USB2.0 SMBUS SATA/IVN PWR (CN20) (CN16) mPCIe (CN27) LIN/MIC (CN13) (J1) PWR SW m-Jump (CN14) (BH1) SATA CMOS Battery (CN24) (CN19) (CN1) USB2.0/3.0 PWR-IN... - Page 12 Chapter 1: Product Introductions CT-PBT01 | User’s Manual PWR_IN 【CN1】 Definition VGA 【CN11】 Definition Definition VGA_RED VCC5_DVI1 VGA_GREEN VGA_BLUE VGA_SDA VGA_HSYNC VSYNC VGA_SCL USB2.0/3.0 【CN19】 Definition Definition USB_SSRX- CND_E USB_SSRX+ CND_E CND_E USB_SSTX- CND_E USB_SSTX+...
- Page 13 Chapter 1: Product Introductions CT-PBT01 | User’s Manual LAN 【CN24】 Definition LAN1+ LAN1- LAN2+ LAN2- 1.5V 1.5V LAN3+ LAN3- LAN4+ LAN4- LANLED1 PULL-H LANLED2 LANLED3 SATA 【CN14】 Definition SATA_TX+ SATA_TX- SATA_RX- SATA_RX+...
- Page 14 Chapter 1: Product Introductions CT-PBT01 | User’s Manual mSATA 【CN15】 Definition Definition Definition WAKE# Reserved Reserved +3.3V Reserved USB_D2+ Reserved Reserved PERST# Reserved MSATA_RXN0 Reserved +1.5V +3.3Vaux Reserved CLKREQ#3 MSATA_RXP0 Reserved Reserved Reserved Reserved Reserved +1.5V Reserved REFCLK2- Reserved Reserved SMB_CLK +1.5V REFCLK2+...
- Page 15 Chapter 1: Product Introductions CT-PBT01 | User’s Manual USB2.0 【CN18】 Definition Definition +5V_SB USB3- +5V_SB USB2+ USB3+ USB2- SMBUS 【CN33】 Definition SMBDATA SMBCLK +3.3V SATA/INV PWR 【CN30】 Definition +12V_LED INV_ON L_BKLT_CTRL VCCM5...
- Page 16 Chapter 1: Product Introductions CT-PBT01 | User’s Manual mPCIe 【CN16】 Definition Definition Definition WAKE# Reserved Reserved +3.3V Reserved USB_D+ Reserved Reserved PERST# Reserved PERn0 Reserved +1.5V +3.3Vaux LED_WWAN# CLKREQ# PERp0 Reserved UIM_PWR LED_WLAN# Reserved UIM_DATA +1.5V LED_WPAN# REFCLK- Reserved UIM_CLK SMB_CLK +1.5V REFCLK+...
- Page 17 Chapter 1: Product Introductions CT-PBT01 | User’s Manual LVDS 【CN31】 Definition Definition LVDS_D2+ LVDS_D1- LVDS_CLK- LVDS_D1+ LVDS_CLK+ LVDS_D0- LVDS_D3- LVDS_D0+ LVDS_D3+ VCCM LVDS_D2- VCCM COM1/COM2 【CN20】 Definition Definition DCD1 DCD2 DSR1 DSR2 RXD1 RXD2 RTS1 RTS2 TXD1 TXD2 CTS1 CTS2 DTR1 DTR2 LINE/MIC【CN27】...
- Page 18 Chapter 1: Product Introductions CT-PBT01 | User’s Manual DIMM 【CN6】 Definition Definition Definition Definition DQ23 CK0# DQS5 V REFDQ DQ19 CK1# DQ42 DQ28 A10/AP DQ46 DQ24 DQ43 DQ29 DQ47 DQ25 RAS# DQ48 DQS3 DQ52 DQ49 DQS0 DQS3 CAS# DQ53 ODT0 DQ27 DQS6# DQ30...
-
Page 19: Chapter 2 Bios Setup
Chapter 2 BIOS Setup... - Page 20 Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.1 BIOS Setup AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, users can modify BIOS settings and control various system features. This chapter describes the basic navigation of the CT-PBT01 BIOS setup screens.
-
Page 21: Entering Setup
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2 Entering Setup Turn on the computer and check for the -patch" code. If there is a number assigned to the patch code, it means that the BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file. -
Page 22: Advanced Bios Features Setup
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2 Advanced BIOS Features Setup Select the Advanced tab from the CT-PBT01 setup screen to enter the Advanced BIOS Setup screen. Users can select any item in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. -
Page 23: Acpi Settings Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.1 ACPI Settings Configuration Enable ACPI Auto Configuration Enable or disable BIOS ACPI auto configuration. Enable Hibernation Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This option may be not effective with some OS. -
Page 24: Super I/O Monitor
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.2 Super I/O Monitor Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA) Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB) -
Page 25: H/W Monitor
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.3 H/W Monitor PC Health Status This page displays all the information about system Temperature/Voltage. -
Page 26: Serial Port Console Redirection
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.4 Serial Port Console Redirection Console Redirection This item allows users to enable or disable console redirection for Microsoft Windows Emergency Management Services (EMS). Console Redirection This item allows users to configure console redirection detail settings. -
Page 27: Cpu Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.5 CPU Configuration Intel Virtualization Technology This item allows you to enable or disable the Intel Virtualization Technology. -
Page 28: Sata Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.6 SATA Configuration SATA Speed Support SATA Speed Supports Gen1 or Gen2 SATA Mode Select IDE / AHCI P0: SATA Port 0 Enable / Disable Serial ATA Port 0 ... -
Page 29: Os Selection
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.7 OS Selection OS Selection OS Selection Supports Windows 8.x / 10.x... -
Page 30: Network Stack Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.8 Network Stack Configuration Network Stack Enable or disable Network Stack Configuration. -
Page 31: Csm Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.9 CSM Configuration CSM Support Enable or disable CSM Support. Boot option filter This option controls Legacy / UEFI ROMs priority. PXE Function Enable or disable PXE Function. Storage Controls the execution of UEFI and Legacy Storage OpROM ... -
Page 32: Usb Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.10 USB Configuration Legacy USB Support Enables support for legacy USB. Auto option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. ... -
Page 33: Intel I210 Gigabit Network Connection
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.2.11 Intel I210 Gigabit Network Connection Link Status Connected or Disconnected the Gigabit Network. -
Page 34: Chipset Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.3 Chipset Configuration North Bridge Details for North Bridge items South Bridge Details for South Bridge items... -
Page 35: North Bridge
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.3.1 North Bridge Intel IGD Configuration Configure Intel IGD settings. -
Page 36: Intel Igd Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.3.2 Intel IGD Configuration IGD Turbo Enable Enable / Disable IGD Turbo. GFX Boost Enable / Disable GFX boost. PAVC Select different mode for protected audio video control. DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) graphics memory size used by the Internal graphics device. -
Page 37: South Bridge
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.3.3 South Bridge Azalia HD Audio Azalia HD audio options USB Configuration USB configuration settings Restore AC Power Loss Select AC power state when the power is re-applied after a power failure. -
Page 38: Azalia Hd Audio
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.3.4 Azalia HD Audio Audio Controller Control Detection of the Azalia device. Disabled = Azalia will be unconditionally disabled. Enabled = Azalia will be unconditionally Enabled. Auto = Azalia will be enabled if present disabled otherwise. -
Page 39: Usb Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.3.5 USB Configuration XHCI Mode Mode of operation of xHCI controller. USB 2.0(EHCI) Support Control the USB EHCI (USB 2.0) functions. One EHCI controller must always be enabled. -
Page 40: Pci Express Configuration
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.3.6 PCI Express Configuration PCI Express Port 1 (mPCIE1) Enable or Disable the PCI Express Port 1 in the chipset. Speed Configure PCIe port speed. PCI Express Port 2 (mPCIE2/mSATA) Enable or Disable the PCI Express Port 2 in the chipset. -
Page 41: Security
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.4 Security Select Security Setup from the CT-PBT01 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>. -
Page 42: Boot
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.5 Boot Setup Prompt Timeout Number of seconds that the firmware will wait before initiating the original default boot selection. A value of 0 indicates that the default boot selection is to be initiated immediately on boot. A value of 65535(0xFFFF) indicates that firmware will wait for user input before booting. -
Page 43: Save & Exit
Chapter 2: BIOS Setup CT-PBT01 | User’s Manual 2.2.6 Save & Exit Save Changes and Exit This item allows you to exit system setup after saving the changes. Discard Changes and Reset This item allows you to rest system setup without saving any changes. ... -
Page 44: Appendix Wdt & Gpio
Appendix WDT & GPIO This appendix provides the sample codes of WDT (Watch Dog Timer) and GPIO (General Purpose Input/ Output). -
Page 45: Watchdog Timer
Appendix – WDT & GPIO CT-PBT01 | User’s Manual Watchdog Timer WDT Setting // IO Address 0xA47 is WDT Enable. // IO Address 0xA65 is WDT time mode select. WDT_TIME_OUT Watch-dog Timeout Bit[0] Reserved Default = 0x00 on VCC Bit[1] Reserved POR, VTR POR, and (R/W) Bits[6:2] Reserved, = 00000... -
Page 46: Gpio
Appendix – WDT & GPIO CT-PBT01 | User’s Manual GPIO GPIO Setting GPIO7 I/O 0xA4Bh Bit7 Default output GPIO6 I/O 0xA4Bh Bit6 Default output GPIO5 I/O 0xA4Bh Bit5 Default output GPIO4 I/O 0xA4Bh Bit4 Default output GPIO3 I/O 0xA4Bh Bit3 Default input GPIO2 I/O 0xA4Bh Bit2... - Page 47 Appendix – WDT & GPIO CT-PBT01 | User’s Manual GP10 General Purpose I/O bit 1.0 Bit[0] In/Out : =1 Input, =0 Output Default – 0x01 on VTR Bit[1] Polarity : =1 Invert, =0 No Invert (R/W) Bit[2] Alternate Function Select 1= RXD3 SCH3114, SCH3116 0= GP10...
- Page 48 Copyright © Premio Inc. All Rights Reserved www.premioinc.com...
