- Page 1 QolorPoint™ Battery Powered LED Uplighter User’s Manual Rev A.3 © 2015 City Theatrical, Inc. QolorPoint battery powered LED uplighter is covered by U.S. Patent # 7,432,803 and other patents pending.
-
Page 2: Table Of Contents
5792M SHoW DMX Neo Radio CE Declaration of Conformity ..................4 System Compliance Information ........................6 Safety Notices ..............................6 Introduction ..............................7 QolorPoint Wireless Uplighter features ........................7 Product Contents ................................8 Charging................................. 8 User Interface..............................9 Power .................................... 9 External Power (Optional Accessory) ........................... -
Page 3: Product Modification
Product Modification This City Theatrical product has been designed and manufactured to meet the strict requirements of U.S., EU and International safety regulations. Any unauthorized modifications to the product including replacement of parts with non-standard parts could compromise safety and result in the product being non-compliant with relevant standards. -
Page 4: 5792M Show Dmx Neo Radio Ce Declaration Of Conformity
City Theatrical Inc. vakuuttaa täten että dieses produkt tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja sitä koskevien näiden direktiivien muiden ehtojen mukainen. City Theatrical Inc. déclare que le produit est conforme aux conditions essentielles et aux dispositions relatives à la directive 1999/5/EC. - Page 5 Page 5 of 18...
-
Page 6: System Compliance Information
The consumer must contact their local authority or retailer for information concerning disposal of their products. City Theatrical provides a take-back facility for batteries used within City Theatrical products, although the expense for transport remains the liability of the consumer. Please contact City Theatrical directly if this service is required. -
Page 7: Introduction
-By designating one fixture as a Master and using its built in SHoW DMX Max wireless DMX Transceiver to broadcast to a group of QolorPoint fixtures set in Slave Mode. -By broadcasting to a group of QolorPoint fixtures by using an external lighting console and a SHoW DMX Neo wireless DMX Transceiver. -
Page 8: Product Contents
Four or five Channel DMX operation • Intuitive LCD menu • Operating temperature range -4°F to113°F(-20°C to +45°C) Product Contents Charging case of six units • 6x QolorPoint Wireless LED fixtures • 6x Stainless steel shroud • 1x Charging case • 1x Powercon Cable •... -
Page 9: User Interface
SET SHOW ID, FUNCTION, DOWN, UP, ENTER, and POWER. External Power (Optional Accessory) An optional QolorPoint AC power supply adapter CAT# 7024 is available as an accessory to drive the QolorPoint from mains voltage 100-250VAC 50/60Hz. • Connect this to the charging/power port in the front of the unit. -
Page 10: Function Modes
Function Modes There are four modes of Operation, accessed through the FUNCTION menu; Custom This mode allows the fixture to output a static Red, Green, Blue or White color, or any Color combination thereof; each color may be set to any value 0 to 255. Any SHoW DMX signal, if present, is ignored. -
Page 11: Static Mode Operation
Tip: Mix red & green with White for warm shades of white. Static Mode Operation Static operation When in STATIC mode the display indicates the current selected color. To change the current selected color press The last character of the currently selected color is underlined. Use the keys to select a color from the built-in library of 70 pre-programmed colors, including 60 popular LEE Filter Colors... -
Page 12: Dmx Mode Operation
Alternatively when in MASTER mode the unit can be linked to many Slave units which will then duplicate everything output from the Master. If not using a QolorPoint as a Master unit then a compatible SHoW DMX transmitter attached to a DMX controller is necessary, available separately. -
Page 13: Built-In Effects
Built-In Effects The QolorPoint is now equipped to generate a number of special effects as a stand-alone unit when DMX is placed in Slave Mode or will output these to a number of connected slave units when DMX is in Master Mode. -
Page 14: Show Dmx Show Id Settings
SHoW DMX transmitter connected to its DMX output, the SHoW ID LED color has to be the same. This allows a group of QolorPoint fixtures to be controlled from the lighting desk or Master unit using the built-in color cycles or set up individually selected colors across many units at once from just one Master unit. -
Page 15: Additional Settings
Custom Color modes only. DMX mode remains unchanged as the unit remains under external control. PWM Frequency Control For HD TV work QolorPoint is equipped with an option to adjust the PWM frequency of the LEDs to prevent ‘beating’ with the TV scan frequency. -
Page 16: Keypad Lock
Press to save changes and the screen will revert to showing the ‘Function’ mode. Keypad Lock The keypad may be locked to prevent tampering or inadvertent adjustment of the unit. To Lock: Hold down the while switching ON the unit to Lock. To Unlock: First switch OFF the unit. -
Page 17: Dimensions
Dimensions Page 17 of 18... -
Page 18: Warranty
If your dealer is not equipped to perform the repair of your City Theatrical product, it can be returned directly to City Theatrical, with carriage being paid at your own expense. You will need to ship this product in either its original packaging or packaging affording an equal degree of protection.
