Icam502 - extronics iCAM501U Operating Manual

iCAM502

4.2
Certification Number
ATEX Certification
IECEx Certification
FM Certification
th
(Units dated after 18 July 2013)
Compliance
Dimensions
IP Rating
Operating Temperature
Weight
Housing
Relative humidity
Power
Memory
Lens
Focal Distance
View Finder
Power Modes
Battery Life
Connectivity
OS Support
Flash
Audio recording format
Image format
Time and Date
Operating Manual
ITS09ATEX26868X, IECEx ITS 09.0027X
II 1 G Ex ia IIB T4/T3 Ga, II 2 G Ex ia IIC T4/T3 Gb, -20°C ≤Ta≤ +60°C
I M1 Ex ia I Ma 0°C ≤Ta≤ +60°C
II 1 G Ex ia IIB T4/T3 Ga, II 2 G Ex ia IIC T4/T3 Gb, -20°C ≤Ta≤ +60°C
Ex ia I Ma 0°C ≤Ta≤ +60°C
Intrinsically Safe for Class 1, Division 1, Groups A,B,C,D T4/T3C -20°C≤Ta≤55/50°C
(USA and Canada)
EMC: EN 55022 1998 class B, EN 55024 1999
LV: EN 60950 2002
FCC: FCC: Class A device, compliance through verification route
132mm x 32mm x 22mm (5.20" x 1.26" x 0.87")
IP65
Group II -20ºC to +60ºC / Group I 0°C to +60°C
Approx. 200g including batteries
Injection moulded anti-static plastic housing, supplied with antistatic silicone rubber
boot for additional shock protection
95% RH non condensing
2 x Alkaline AA batteries, refer to ATEX Certificate for details on range of approved
batteries. Batteries may not be carried or changed in Group I hazardous areas.
On board 1Gbyte NAND Flash (holds approx. 5,000 JPEG images without any audio
recording and additional 960Kbytes per min for audio)
3.1 Mega-Pixel (2048 x 1536 resolution)
Autofocus lens, effective focal length 3.39mm, F2.8, 68
5cm to infinity
Two element optical view finder
Operate and auto power-down (after 3 mins)
Up to 600 shots without flash and up to 100 shots with flash taken one after the other. 170
shots as per the CIPA DC-002 standard (mixed mode shots with and without flash)
Note it is very difficult to be precise about exact numbers as there are many factors that can
influence this such as the ambient temperature, how long the camera is powered up,
number of voice recordings made and the number and length of time it is connected to a PC
for transferring picture and voice data.
USB 1.1 via mini-USB socket for use in the safe area only. Certified for direct connection to
a PC without requiring an external protection barrier
PTP imaging device in Windows XP/Vista/7 and most versions of Linux.
USB firmware upgrade utility for Windows XP/Vista/7 only.
4 LED flash giving 131 lux.seconds of energy at 67ms exposure
wav
jpeg
Time and date stamping of stored images and filenames
Time and date set via Picture Transfer Protocol (PTP) automatically
33
o
diagonal field of view
