Brave VH0934 Owner / Operator Use And Care Manual

Brave 34 ton vertical / horizontal log splitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

B B r r a a v v e e 3 3 4 4 T T o o n n
Vertical / Horizontal
Log Splitter
M M o o d d e e l l V V H H 0 0 9 9 3 3 4 4
Owner / Operator
and Safety Manual

Advertisement

Table of Contents
loading

Related Manuals for Brave VH0934

Summary of Contents for Brave VH0934

  • Page 1 B B r r a a v v e e 3 3 4 4 T T o o n n Vertical / Horizontal Log Splitter M M o o d d e e l l V V H H 0 0 9 9 3 3 4 4 Owner / Operator and Safety Manual...
  • Page 3 ❏ ❏ Make sure the trailer hitch of the towing vehicle is equipped with a 2 inch ball. NOTE: Brave Products reserves the right to make technical changes for product improvement. This manual may contain illustrations and photographs, for demonstration purposes, which slightly deviate from the actual product design.

  • Page 4: Table Of Contents

    Log Cradle, Log Dislodger, and Safety Flag ......43 Brave Products, Inc.
  • Page 5 DO NOT proceed if any doubt arises about the correct or safe method of per- forming anything found in this or other Brave Products’ manuals. Seek out expert assistance from a qualified person before continuing.

  • Page 6: Introduction

    With 34 tons of splitting force, a 15 second cycle time, and an 11 HP engine, the VH0934 will handle most of your log split- ting needs. An attractive, powder-coated finish provides the finest protection available and Brave’s rigid, quality-control and component testing help ensure years of productive,...

  • Page 7: Worksite Safety

    ALWAYS disconnect the spark plug wire when the log splitter is not in operation. ✘ Do not allow any person to operate the log splitter until they have read and understood the safe operating instructions contained in this manual. 815-672-8861 Brave Products, Inc.

  • Page 8: Log Splitting Safety

    ✔ ALWAYS inspect your log splitter before each use. Make sure all nuts, bolts, screws, hydraulic fittings, hose clamps, etc. are securely tightened. Brave Products, Inc. 815-672-8861...

  • Page 9: Towing

    NEVER tow your log splitter when there is fuel in the engine’s tank. ✘ NEVER allow anyone to sit or ride on your log splitter. ✘ NEVER carry any cargo or wood on your log splitter. 815-672-8861 Brave Products, Inc.

  • Page 10: Refueling

    (if any). If a spark arrester is used, it should be maintained in effective working order by the owner and/or operator. Brave Products, Inc. 815-672-8861...

  • Page 11: Assembly Instructions

    • Two 3/4” open end wrenches • Funnel • Pliers • Band Cutters Shipping List The following chart contains the list of parts that should be shipped as part of the VH0934 Log Splitter. Description Description Base Unit (engine) Rail to Base Assembly Rail Unit (hydraulic cylinder) Bolt (1/2-13 x 1-1/2”)

  • Page 12: Unpacking The Crate

    “Shipping List” section pro- vides a complete list of all the parts shipped with your log splitter. If any parts are missing call Brave Products at (815) 672-8861. NOTE: The contents of the cardboard box contains the hitch assembly, two safety...

  • Page 13: Assembly Procedure

    1/2-13 x 3-1/2 inch long hex head bolts, lockwashers, and nuts. Tighten the nuts securely. Roll the tongue/base unit off the pallet and lower the front leg and lock it into position. 815-672-8861 Brave Products, Inc.
  • Page 14 6. Bolt the base unit to the rail assembly using two 1/2-13 x 1-1/2 inch long hex head bolts, lockwashers, and nuts, as shown. Tighten the nuts securely. Brave Products, Inc. 815-672-8861...
  • Page 15 1/2 x 3-1/2 inch bolt (A). Install and tight- en the locknut. Insert the end of quick link into front tube of the rail assembly and insert a 1/2 x 3 -1/2 inch bolt (B) through link and hitch. Install and tighten the locknut. 815-672-8861 Brave Products, Inc.
  • Page 16 Securely tighten the hose fitting. NOTE: The high-pressure hose is self-seal- ing and does not require any type of sealing material. Tighten the fitting with a 10 inch crescent wrench. Brave Products, Inc. 815-672-8861...
  • Page 17 18. The log splitter is now completely assem- bled. Follow the “Start-Up Procedure,” in the following section, which adds oil to the engine and hydraulic tank before trying to start the engine. 815-672-8861 Brave Products, Inc.

  • Page 18: Start-Up Procedure

    Pull the engine starter cord (about 15 times) with the other hand, until the cylinder piston moves forward. (Keep everything away from the splitting wedge during this step.) NOTE: Extending the cylinder draws the hydraulic fluid through the system and expels any trapped air in the cylinder. Brave Products, Inc. 815-672-8861...
  • Page 19 Cycle the log splitter several times. 10. Again, check the fluid level in the hydraulic tank and add oil as needed. Replace and tighten the fill cap. 11. Your log splitter is now ready to use. 815-672-8861 Brave Products, Inc.

  • Page 20: Towing

    3. Raise the front leg to the towing position by pulling the spring pin. If not already secure, make sure the hitch coupler is properly and securely attached to the tow ball. Brave Products, Inc. 815-672-8861...
  • Page 21 Failure to securely attach the log splitter can cause loss of control of the vehicle or the log splitter being separated from the towing vehicle, resulting in serious injury or death. 815-672-8861 Brave Products, Inc.

  • Page 22: Operation

    If any doubt or question arises about the correct or safe method of per- forming anything found in this or other Brave Products’ manuals, con- tact your Brave Products’ dealer or call the Sales and Service representatives at our main headquarters. Proper care is your responsibility.

  • Page 23: Operation - Horizontal Position

    (end plate), opposite the splitting wedge. CAUTION Do not place your hands on the ends of the log when loading the log splitter. This is a very UNSAFE method and could result in injury to your hands. 815-672-8861 Brave Products, Inc.
  • Page 24 Do not operate the log splitter by reaching across the rail. Do not reach or step across the rail while the log splitter is running. This is a very UNSAFE method which could cause per- sonal injury or even death. Brave Products, Inc. 815-672-8861...
  • Page 25 (stop the wedge from retracting) and carefully remove the log from the wedge. Allowing the log to remain attached to the wedge when it is fully retracted could lead to possible injury and/or damage to the log splitter. 815-672-8861 Brave Products, Inc.

  • Page 26: Operation - Vertical Position

    Block the wheels and stand the rail assembly up into a vertical position. c. Turn the knob handle until the pin slides into the slot. This allows the plunger to snap into place, securing the rail assembly in a vertical position. Brave Products, Inc. 815-672-8861...
  • Page 27 (towards the log). If the log moves, before it is contacted by the splitting wedge, release the control lever and then reposition the log. Operate the log splitter only when standing in the safe operating area, as shown in the picture. 815-672-8861 Brave Products, Inc.
  • Page 28 (stop the wedge from retracting) and carefully remove the log from the wedge. Allowing the log to remain attached to the wedge when it is fully retracted could lead to possible injury and/or damage to the log splitter. Brave Products, Inc. 815-672-8861...

  • Page 29: Inspection And Maintenance

    Always replace frayed, kinked, or cracked hoses and/or other damaged hydraulic com- ponents with Brave Products authorized parts and components specified in the “Parts” section of this manual. Replacement parts from secondary suppliers (not original Brave replacement parts) can lead to product damage and/or personal injury and will void the warranty.

  • Page 30: Hydraulic Oil Change

    Hydraulic Oil Change Brave Products recommends an oil and filter change every 100 hours of operation. Refer to the “Specifications” section, in this manual, for the type and quantity of oil. Important Notice Never run the log splitter unless the hydraulic oil tank is full.
  • Page 31 Start the engine and cycle the cylinder several times. c. Retract the cylinder and shut off the engine. d. Recheck the hydraulic tank to make sure oil is filled within one inch from the top of the tank. 815-672-8861 Brave Products, Inc.

  • Page 32: Specifications

    Transmission Fluid ..........Dextron Ill Important Notice DO NOT mix tractor hydraulic oil with transmission fluid. Use one or the other. Brave Products, Inc. 815-672-8861...

  • Page 33: Troubleshooting

    The following section will detail procedures for checking your log splitter, should you encounter a malfunction. Brave Products, Inc. recommends that you do not attempt to make repairs to the log splitter. In the long run, it is better to take your log splitter to a servicing lawn and garden dealer for repairs.

  • Page 34: Decals

    Decals WARNING Make sure all decals are attached to the log splitter and/or engine and are legible at all times. Brave Products, Inc. 815-672-8861...
  • Page 35 Description Qty. BR002652 Decal, Notice 2 (NS) BR002625 Decal, 34 Ton Logo BR002302 Decal, Operator Safety BR002621 Decal, Flag BR002521 Decal, Serial Number BR002653 Decal, Maximum Speed BR002559 Decal, Proper Machine Loading NS - not shown 815-672-8861 Brave Products, Inc.

  • Page 36: Parts

    Parts Brave Products, Inc. 815-672-8861...
  • Page 37 815-672-8861 Brave Products, Inc.
  • Page 38 Brave Products, Inc. 815-672-8861...
  • Page 39 815-672-8861 Brave Products, Inc.
  • Page 40 Brave Products, Inc. 815-672-8861...
  • Page 41 815-672-8861 Brave Products, Inc.

  • Page 42: Warranty

    Warranty For one year from the date of purchase, Brave Products Inc. will replace for the original purchaser, or repair free of charge, all parts of the Brave Products’ Hydraulic Log Splitter returned to our factory PREPAID and found upon inspection by us to be faulty, due to defects in materials or workmanship.

  • Page 45: Optional Attachments

    Safety Flag Kit (Part No. BR012104) ✔ Improves visibility of log splitter when backing up or towing. ✔ Heavy-duty tapered fiberglass pole won't bend over at towing speeds. ✔ Installs in minutes, no drilling required. ✔ Mounting instructions included. Brave Products, Inc. 815-672-8861...
  • Page 46 Notes Brave Products, Inc. 815-672-8861...

  • Page 48: Brave Products, Inc

    Brave Products, Inc. 410 W. Broadway Ave. Streator, Illinois 61364-0577 Phone: 815-672-8861 Fax: 815-672-9073 E-mail: sales@braveproducts.com Web Site: www.braveproducts.com VH0934 12/08...
