MPCLS1513B Model: PCLS1513GC Brave EZ Split 15 Horizontal Log Splitter Model PCLS1513 Patented Owner / Operator and Safety Manual... - Page 2 ENGINE SPLITTING OIL FILL WEDGE HITCH COUPLER CYLINDER RETRACTABLE FRONT LEG EZlS-04...
- Page 3 Keep this manual for future reference. NOTE: Brave reserves the right to make technical changes for product improvement. This manual may contain illustrations and photographs, for demonstration purposes, which slightly deviate from the actual product design.
-
Page 4: Table Of Contents
Warranty Card............41 Brave... -
Page 5: Introduction
Congratulations on your purchase of a new Brave log splitter. The Brave EZ Split 15 log splitter is powerful, portable, easy to operate and stores in a minimum of space. It is the perfect log splitter for homeowners with fireplaces and wood stoves and is towable to work sites behind a car, van, SUV, or pick-up truck. -
Page 6: Safety
If any doubt or question arises about the correct or safe method of performing any steps found in this or other Brave’ manuals, contact your Brave’ dealer or call the Sales and Service representatives at our main headquarters. Proper care is your responsibility. -
Page 7: Personal Protection
Safety DO NOT proceed if any doubt arises about the correct or safe method of performing anything found in this or other Brave manuals. Seek out expert assistance from a qualified person before continuing. CALIFORNIA PROPOSITION 65: Engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm. -
Page 8: Worksite Safety
Do not allow any person to operate the log splitter until after they have read and understand the safe operating instructions contained in this manual. Only allow adults to operate your log splitter. No one under the age of 18 should be allowed to operate the log splitter. Brave 800-350-8739... - Page 9 NEVER attempt to load your log splitter while the ram is in motion. Only use your hand to operate the control lever. NEVER use your foot, knee, a rope, or any other extension device. 800-350-8739 Brave...
-
Page 10: Log Splitting Safety
(if any). If a spark arrester is used, it should be maintained in effective working order by the owner and/or operator. Brave 800-350-8739... -
Page 11: Maintenance And Repair
Such ALTERATIONS may cause the log splitter to become UNSAFE and WILL VOID THE WARRANTY. ALWAYS clean the unit after each use. If possible, store the unit inside or cover it completely if stored outside. 800-350-8739 Brave... -
Page 12: Assembly Instructions
Use band cutters to carefully cut and remove banding from around the crate. Discard the banding. b. Use a claw hammer to remove the top and sides of the shipping crate. 2. Remove the parts carton from the shipping pallet. Brave 800-350-8739... - Page 13 (not shown) securing the rear of the log splitter to the shipping pallet. Discard the banding. 5. Use two 9/16 inch wrenches to unbolt the tire assembly axles. Note: Save the bolt (2) and nut (3) for reuse during tire assembly installation. 800-350-8739 Brave...
- Page 14 EZ Split 15 frame. 9. Carefully roll the log splitter off of the shipping pallet. Remove lock pin (A), lower front leg (B) and insert the lock pin to secure the front leg in the down position, as shown. Brave 800-350-8739...
- Page 15 3/8-16 x 1” long hex bolts (10) and 3/8-16” locknuts (11) (not shown). Tighten the nuts securely using two 9/16 inch wrenches. 13. Connect high pressure hose (C) to the control valve fitting (D). Securely tighten the hose fitting with 10” Crescent wrench. 800-350-8739 Brave...
- Page 16 (J) through the bottom hole on the valve. b. With handle (I) angled back, insert the forked end over pin (H). c. Align the hole in the handle with the top hole in the valve and insert clevis pin and hairpin clip (J). Brave 800-350-8739...
-
Page 17: Start-Up Procedure
NOTE: Various engines used on the EZ Split 15 may have the oil fill at different locations. For more information on oil fill locations, refer to the engine manual. 800-350-8739 Brave... - Page 18 Allow enough time for excess oil to drain from oil level hole. Re-install fill cap and oil level screw making sure O-rings are in place. 9. Check all fittings and hoses for leaks and tighten as needed. Your EZ Split 15 log splitter is now ready to use. Brave 800-350-8739...
-
Page 19: Towing
(7) to the tow vehicle. Important Notice Do not back up with the log splitter attached. The short tongue length can cause it to jackknife quickly, resulting in damage to the log splitter and/or tow vehicle. 800-350-8739 Brave... -
Page 20: Operation
If any doubt or question arises about the correct or safe method of performing anything found in this or other Brave Products’ manuals, contact your Brave’ dealer or call the Sales and Service representatives at our main headquarters. Proper care is your responsibility. - Page 21 WARNING Do not reach or step across the rail while the log splitter is running. This is a very UNSAFE method which could cause personal injury or even death. 800-350-8739 Brave...
- Page 22 If you must, hold the log on top and in the middle. Remove your hand immediately when the pusher plate engages the log. Never use your knee or any extension device to operate the valve control handle. Brave 800-350-8739...
- Page 23 Allowing the log to remain attached to the pusher plate when it is fully retracted could lead to possible injury and/or damage to the log splitter. 800-350-8739 Brave...
-
Page 24: General Maintenance Check (Before Operating)
Be sure the EZ Split 15 is on a flat, level surface before checking the oil level. 1. Place a clean container under oil level hole to catch any overflow of oil. Do not allow excess oil to spill onto the ground. Brave 800-350-8739... -
Page 25: Inspection And Maintenance
Escaping fluid under pressure can have sufficient force to penetrate skin, causing serious injury or even death. If fluid is injected into your skin, it must be treated immediately by a doctor familiar with this type of injury. 800-350-8739 Brave... -
Page 26: Oil Pump Installation
Always replace frayed, kinked, or cracked hoses and/or other damaged hydraulic components with Brave’ authorized parts and components specified in the “Parts” section of this manual. Replacement parts from secondary suppliers (not original Brave replacement parts) can lead to product damage and/or personal injury, and WILL VOID THE WARRANTY. -
Page 27: Hydraulic Oil Change
(O). Tighten bolts (M) and nuts (N) securely and connect the spark plug wire. Hydraulic Oil Change Brave recommends an oil change every 100 hours of operation. Refer to the “Specifications” section in this manual for the type and quantity of oil. Important Notice Never run the log splitter unless the hydraulic oil tank is full. - Page 28 (I) forward and pull on engine’s pull start cord (T) to extend the cylinder until oil from the return line stops flowing. This step drains the head end of the cylinder. NOTE: Do not re-attach low-pressure hose (F) at this time. Brave 800-350-8739...
- Page 29 (E). c. Extend the cylinder. Hold valve handle (I) forward and pull on engine’s pull start cord (T) until the cylinder is completely extended. This step refills the piston end of the hydraulic cylinder. 800-350-8739 Brave...
-
Page 30: Tire Pressure
O-rings are in place. Tire Pressure Check the EZ Split 15 tire pressure on a regular basis and before towing. Set the air pressure in both tires to the tire manufacturers’ specifications, molded into the sidewall of each tire. Brave 800-350-8739... -
Page 31: Specifications
DO NOT mix different types of hydraulic oils and transmission fluids (e.g., synthetic with non-synthetic). Hydraulic oil is NOT compatible with transmission fluid, and different TYPES of hydraulic oils and transmission fluids MAY NOT BE compatible with each other. 800-350-8739 Brave... -
Page 32: Troubleshooting
The following section details procedures for checking your log splitter, should you encounter a malfunction. Brave recommends that you do not attempt to make repairs to the log splitter. In the long run, it is better to take your log splitter to a servicing lawn and garden dealer for repairs. -
Page 33: Decals
Make sure all decals are attached to the log splitter and/or engine and are AR N I legible at all times. If you are missing a decal or one is not legible, call Brave at 800-350-8739 for a replacement. Item Part No. - Page 34 Decals 1 2 3 Brave 800-350-8739...
- Page 35 Decals 5 CONTROL VALVE Reverse Neutral Forwar 800-350-8739 Brave...
- Page 36 Decals 6 7 8 CONTROL VALVE 9 Reverse Neutral Forward 10 Brave 800-350-8739...
-
Page 37: Optional Attachment
Optional Attachment Safety Flag Kit (BR012105) ✔ Improves visibility of logsplitter when towing. ✔ Heavy-duty tapered fiberglass pole won't bend over at towing speeds. ✔ Installs in minutes, no drilling required. ✔ Mounting instructions included. 800-350-8739 Brave... -
Page 38: Parts
Parts Brave 800-350-8739... - Page 39 Bolt, 3/8-16 x 1 PCLS1513GC Item Part No. Description Unit 82429 inch long BR008540 Hitch Coupler PCLS1513GC PCLS1513GC 82027 Locknut, 3/8-16 PCLS1513GC 1130 Safety Chain PCLS1513GC 82507 Screw, Oil Level Bolt, 1/2-13 x 3.5 PCLS1513GC 82490 Fitting, Street PCLS1513GC inch long BR001098 Elbow PCLS1513GC...
- Page 40 Parts Brave 800-350-8739...
- Page 41 PCLS1513GC Item Unit Part No. Description PCLS1513GC 82085 Washer, 1/4 inch PCLS1513GC BR004101A Handle Assembly Kit Square Key, 3/16 x 1 PCLS1513GC PCLS1513GC BR004100 Control Valve 82522 inch PCLS1513GC BR001052 Fitting, Straight PCLS1513GC BR006002E Engine Coupling Fitting, 90 Degree PCLS1513GC 778705 PCLS1513GC BR006002B...
-
Page 42: Warranty
Warranty For one year from the date of purchase, Brave will replace for the original purchaser, or repair free of charge, all parts of the Brave Hydraulic Log Splitter, returned to our factory PREPAID and found upon inspection by us to be faulty, due to defects in materials or workmanship. -
Page 43: Warranty Card
Important Warranty Information To activate your Brave log splitter warranty, please Brave fill out the information in the form below and mail 20195 S. Diamond Lk. Rd. STE 100 in an envelope to the address listed on the right or Rogers, MN 55374 go online to www.braveproducts.com... - Page 45 Notes 800-350-8739 Brave...
- Page 46 Notes 800-350-8739 Brave...
- Page 48 Brave 20195 S. Diamond Lake Rd. STE 100 Rogers, MN 55374 Phone: 800-350-8739 (Toll Free) Fax: 866-779-9963 E-mail: sales@braveproducts.com Website: www.braveproducts.com PCLS1513-00 11/13...
