4 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due
to battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is
necessary to fully understand the procedure required to enable your vehicle in such
situations. In addition, the chart on the last page of this manual has a section for the particular
features and options installed in your vehicle as well as the override method selected.
Valet Switch manual override is pre-selected from the factory, however, the system
can be configured for "Custom Code" operation. Confirm the override mode selected on the
last page of this manual, and familiarize yourself with the selection on it's operation.
FEATURES :
2 Five Button Programmable RF Transmitters (capable of accepting 4 transmitters)
Five Channel Receiver
Code Hopping Technology
Selectable Manual Override Mode
Remote Panic in all modes
Protected Valet
User Programmable Manual Override Code
7 Function LED (Light Emitting Diode) - Arm / Disarm / Zone 1, 2, 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone / Tamper Confirmation
Instant Siren Activation
Starter Disable
Additional Engine Immobilizer Output (optional relay required)
True Last Door Arming (hardwire only)
Defective Zone By-Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1 Second / 3.5 Seconds/1 Sec L/ Dbl. U/L
Programmable Active or Passive Door Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Transmitter
6 Tone Multi Tone Siren
RF Inhibit with ignition on
Parking Light Flash
Plug In Dual Stage Shock Sensor
OPTIONS:
Remote Trunk Release
Remote Keyless Entry
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Two Step Unlock Configurable
Headlight Illumination During Arming, Disarming, Or Both
Interior Illumination Upon Disarm
Model AX-510
Owner's Manual
128-7000
1 OF 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AX-510 and is the answer not in the manual?

Questions and answers

Related Manuals for Audiovox AX-510

Summary of Contents for Audiovox AX-510

  • Page 1 Model AX-510 Owner’s Manual 4 Button Remote Security System with Dual Stage Shock Sensor IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to manually override your security system if the transmitter becomes lost, or inoperative due to battery failure.

  • Page 2: Arming The System - Active

    YOUR “ Code Hopping “ TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your transmitter, and retransmit at a later time to disarm your system.

  • Page 3: Protection While The System Is Armed

    ARMING THE SYSTEM - PASSIVE ( AUTOMATIC ) 1. Turn off the engine, exit the vehicle, and close and lock all doors, hood and trunk. Dash mounted LED begins to flash rapidly, indicating 30 second passive arming has begun. 2. Opening any protected entry point during the 30 second passive arming cycle will immediately suspend automatic arming and the 30 second passive arming cycle will restart when all doors are closed.

  • Page 4: Disarming The System

    DISARMING THE SYSTEM 1. Press and release the Unlock button on the transmitter. Dash mounted LED turns off. If passive arming was selected during the installation, then the LED will start flashing rapidly, indicating that the system is rearming auto- matically.

  • Page 5: While The System Is Sounding

    transmitter has a separate lock/unlock buttons, pressing the unlock button anytime after the first unlock command will cause all the vehicle doors to unlock. Headlight Illumination - Optional Illuminated Entry Upon Disarm WHILE THE SYSTEM IS SOUNDING If during a triggered state, you wish to shut off the siren without disarming your security system, simply press and release any transmitter button other than the disarm button.
  • Page 6 is lost or its battery fails. If your system has been selected for Valet Switch manual override as indicated on the last page of this manual, to bypass the alarm system. 1. Open the vehicle door. The alarm will sound. 2.
  • Page 7 Custom Code Programming Example: To Change the code from the factory preassigned code of 11 to “52” you would do the following: 1. Disarm the system by use of the transmitter, or by use of the emergency override sequence. 2. Turn the ignition switch to the on position. 3.

  • Page 8: Eliminating The Normal Arm / Disarm Chirps

    ELIMINATING THE NORMAL ARM / DISARM CHIRPS As explained earlier in the manual, you can eliminate the chirps selectively any time you arm or disarm the system simply by holding the ARM / DISARM button for two seconds. ARM/DISARM chirps can be turned off permanently. To do this, 1.

  • Page 9: Telematic Upgrade

    and holding the programmed button on the transmitter for four seconds, or by pressing and releasing the programmed button on the transmitter two times in succession. Check with your installation center for more information on what accessories were installed and how they are accessed. ADDITIONAL REMOTE FUNCTION ( CHANNEL 4 ) This security system has an additional feature that can be connected to a number of different optional accessories.
  • Page 10 Auto Unlock with ignition key Passive Arming No Lock in passive mode Custom Code Override Valet Switch Override Illuminated Entry Upon Disarm (MAY REQUIRE ADDITIONAL PARTS) © 2005 Audiovox Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-7000 128-7000 10 OF 10...
