3 Button Remote Security System
with Dual Stage Shock Sensor
IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this
system is equipped with selectable manual override circuitry. It is possible that you will need
to manually override your security system if the transmitter becomes lost, or inoperative due to
battery failure. Reading the sections on "MANUALLY OVERRIDING YOUR SYSTEM" is nec-
essary to fully understand the procedure required to enable your vehicle in such situations.
In addition, the chart on the last page of this manual has a section for the particular features
and options installed in your vehicle as well as the override method selected. Valet Switch
manual override is pre-selected from the factory, however, the system can be config-
ured for "Custom Code" operation. Confirm the override mode selected on the last page of this
manual, and familiarize yourself with the selection on it's operation.
FEATURES:
2 Three Button Programmable RF Trans-
mitters
Five Channel Receiver
(capable of accepting 4 transmitters)
Code Hopping Technology
Selectable Manual Override Mode
Remote Panic in all modes
Protected Valet
User Programmable Manual Override
Code
7 Function LED - Arm / Disarm / Zone 1
/ Zone 2 / Zone 3 / Valet / Arming
Intrusion Alert with Memory
Audible Arm / Disarm / Defective Zone /
Tamper Confirmation
Starter Disable
True Last Door Arming (hardwire only)
Defective Zone By-Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
Programmable Auto Lock On / Off
OPTIONS:
6 Tone Multi Tone Siren
Remote Trunk Release (must have electronic trunk release)
Remote Keyless Entry (must have power door locks)
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up
Remote Garage Door Interface
Headlight Illumination During Arming/Disarming, Or Both
Model: PRO-9649N
Owner's Manual
Programmable Auto Unlock On / Off
Programmable Door Lock Pulse Duration 1
Second/3.5 Seconds/1 Sec L/Dbl. U/L
Programmable Active or Passive Door
Locks
User Programmable Permanent Chirp Delete
On Command RF Chirp Delete from Trans-
mitter Or Selectable Through Software
Car Horn Activation for alarm response
Additional Negative Trigger Input
RF Inhibit with ignition on
Parking Light Flasher
Remote Trunk Release (must have
electronic trunk release)
Remote Keyless Entry With Optional
Access Guard (must have power door
locks)
Illuminated Entry
Plug In Dual Stage Shock Sensor
128-8498
1 of 8
Advertisement
Table of Contents
Related Manuals for Audiovox Pursuit PRO-9649N
Summary of Contents for Audiovox Pursuit PRO-9649N
- Page 1 Model: PRO-9649N Owner’s Manual 3 Button Remote Security System with Dual Stage Shock Sensor IMPORTANT ! In order to provide the highest possible level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to manually override your security system if the transmitter becomes lost, or inoperative due to battery failure.
- Page 2 YOUR "Code Hopping" TRANSMITTERS The transmitters included with your new security system use the most advanced and secure form of radio frequency transmission available on any current automotive security system. Some of today’s sophisticated auto thieves use a device known as a code grabber, which will receive and store the signal from your keychain transmitter, and re transmit at a later time to disarm your system.
- Page 3 Red dash mounted LED begins to flash slowly. Parking Lights flash one time. Siren sounds one chirp If the siren did not sound when arming, then the chirps have been turned off and you should refer to the section titled “ELIMINATING THE ARM / DISARM CHIRPS “...
- Page 4 unlock buttons, pressing the unlock button anytime after the first unlock command will cause all the vehicle doors to unlock. Headlight Illumination - Optional SILENT DISARMING 1. As you approach the vehicle, press and hold the Unlock button on the keychain transmitter for 2 seconds.
- Page 5 door locks will remain operational. To use the valet mode, the system must first be disarmed either by using your keychain transmitter, or by activating your personalized manual override code. 1. Enter the vehicle, and turn the ignition key to the on position. 2.
- Page 6 4. Within 10 seconds turn the ignition switch off, on, off, on, off, on. (The siren or horn will beep and the lights will flash one time.) 5. Within 10 seconds, begin to press and release the PBLED switch to set the tenths digit. (As per the example, press and release 5 times to set the tenths digit to 5) 6.
- Page 7 Note: While in the Panic mode, pressing and releasing the ARM or DISARM buttons will, if the option is installed, lock and unlock the doors respectively. While in the panic mode, anytime the DISARM button is pressed, the panic feature will continue for the allotted 30 seconds, however, the security system will be disarmed allowing the vehicle to start.
- Page 8 Auto Lock with ignition key Auto Unlock with ignition key Passive Arming No Lock in passive mode Hardwire doors, hood, and trunk Custom Code Override Valet Switch Override © 2009 Audiovox Electronics Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-8498 128-8498 8 of 8...
