Summary of Contents for ZMODO ZMD-DR-SFN6
- Page 1 16 Channel DVR Quick Manual 0 ...
- Page 2 16 Channel DVR Quick Manual Notes: The power supply of this DVR is provided through DC12V3A adapter, please check the power outlet before installation and ensure it can meet the requirements of the adapter; Do not place the DVR at a place subject to rain and moisture; Do not install the DVR at a place subject to violent vibration; Do not install the DVR at a place subject to direct sunlight, and be far away from high temperature environment; The DVR’s back panel should be placed 15cm or more away from other objects or wall for cooling; The DVR should work under temperature, humidity and voltage according to its technical specifications; The space where DVR is installed should not be stored with corrosive chemicals that may produce volatile gases to avoid affecting the DVR’s life. The ...
-
Page 3: Table Of Contents
16 Channel DVR Quick Manual Contents Chapter 1 Open‐case inspection and quick installation ........ 3 1.1 Open‐case inspection ................ 3 1.2 Product appearance and port .............. 3 1.3 Quick Installation .................. 4 1.3.1 HDD installation ................ 4 1.3.2 Power on ................... 4 Chapter 2 Software interface basic operation ........... 5 2.1 Power on and login ................ 5 2.2 Main menu ................... 5 2.3 Recording mode ................... 5 2.4 Recording Search and Playback ............ 6 2.4.1 Search and playback .............. 6 2.4.2 Recording backup .............. 6 2.5 Alarm Setup .................. 7 2.5.1 Alarm basic setup .............. 7 2.5.2 E‐mail alarm setup .............. 8 2.6 PTZ Control ................... 8 2.7 Motion Detection ................. 9 2.8 Network setup .................. 10 2.9 Port mapping .................. 11 2.10 Mobile phone surveillance ... -
Page 4: Chapter 1 Open-Case Inspection And Quick Installation
16 Channel DVR Quick Manual Chapter 1 Open-case inspection and quick installation 1.1 Opencase inspection ◆ When you receive the products, please check if the DVR is complete or make sure if there is any accidental damage during transportation. ◆ Then, please open the package and check if the accessories are complete. You can remove the protective film of the DVR package. ... -
Page 5: Quick Installation
16 Channel DVR Quick Manual Back panel: (7、 8、 9、 10) 1. Video in 2. Video out (BNC port) 3. Audio out 4. Audio in 5. VGA output port 6.Network port 7.RS485 8.Public terminal 9. Alarm output 10. Alarm input 11. Power input 12.Grounding terminal 1.3 Quick Installation ... -
Page 6: Chapter 2 Software Interface Basic Operation
16 Channel DVR Quick Manual Chapter 2 Software interface basic operation 2.1 Power on and login The DVR’s initial device ID is 000000 without any password, the user can enter main menu directly. Users can set ordinary password and administrator password. The administrator has all the operating privileges, while ordinary users can only carry out monitor and video search/ playback operations. (The mainframe will match automatically when you enter password, and different permissions will be given according to different passwords). If you want to operate in main menu after the password is set, the system will display “user login” interface: Device ID: It is just okay to enter device ID displayed on ... -
Page 7: Recording Search And Playback
16 Channel DVR Quick Manual Frame rate: Adjust video frame rate Note: The total frame rate for 4 channels DVR is 100 fps, for 8 channels is 275 fps, and for 16 channels is 400 fps. Audio: Set the record switch. File length: There are four options ‐15 minutes, 30 minutes, 45 minutes and 60 minutes. REC mode: Startup recording and Timing recording When powered on: starting recording when the DVR is energized (It works only if the corresponding channel is enabled in the “Channel” option.) ... -
Page 8: Alarm Setup
16 Channel DVR Quick Manual down in the interface of detailed file list and select "Backup". The file is undergoing backup and the backup progress is displayed on the screen. Note: 1. When the space of the backup device is smaller than the recording file capacity, the system will remind the user of insufficient space. 2. -
Page 9: E-Mail Alarm Setup
16 Channel DVR Quick Manual Note: When an alarm is valid, a red letter "I" will display on the corresponding screen. HDD LOSS: On: When the system cannot recognize the HDD, a red logo “H” will display on the channel. HDD SPACE: On: When the remaining space of the HDD is less than 500M, the DVR will have alarm indication. VIDEO LOSS: On: When the video of a certain channel is lost, this channel will display in the lower part of the Video Preview screen: “Video Loss”. ALARM MANAGEMENT OUTPUT: including alarm output, buzzer and post alarm recording. 2.5.2 E‐mail alarm setup Email setup Prerequisite: The mainframe must be connected to the WAN. Please refer to the Chapter Network for network connection. ... -
Page 10: Motion Detection
16 Channel DVR Quick Manual dome, with the 4 options of 1200, 2400, 4800 and 9600 DATA BIT: with the options of 5, 6, 7 and 8, 8 by default STOP BIT: with the options of 1 and 2, 1 by default VERIFY: with the 5 options of None/Odd/Even/Mark/Space, None by default ADDRESS: Complete the PTZ code of the corresponding channel. Just set “protocol”, “baud rate” and “address code” in order to set the PTZ. Click "PTZ control" in the main interface, the following screen will pop up (left picture): Operate the PTZ with mouse through the keypad on the interface. Set the cruise point in the cruise setup, as shown on the right picture above. 2.7 Motion Detection Enter the Motion Detection screen from “Main Menu” →“Advanced” to “Motion Detection”, as shown below: STATUS: Each channel has a corresponding switch. Select “On” or “Off”. SENSITIVITY: Each channel has a corresponding sensitivity setting, with the 4 levels of 1, 2, 3 and 4, in which 4 is the highest. Select sensitivity for confirmation. MD AREA: Each channel has a corresponding motion detection area setting. Move the cursor to “Setup” of the corresponding channel, ... -
Page 11: Network Setup
16 Channel DVR Quick Manual In the “Recording Mode” screen, select “Timing Recording” in the “Recording Mode” option, also click “Record Time Configuration” to enter the Record Time Configuration screen and set the corresponding time to alarm recording (see timing recording in “Recording Mode” for the setup method). After the setup has been done and motion detection is triggered, a red letter “M” will appear in the screen of this channel. See “Alarm processes” in Section 2.5.1 for alarm processing. ... -
Page 12: Port Mapping
16 Channel DVR Quick Manual WEB port to any other port, such as 88, you have to postfix the IP with the port number, and enter “http://192.168.1.223:88” in the address bar when accessing the DVR via the IE. IP ADDRESS: allocating an IP address according to the network environment of the DVR SUBNET MASK: filling in a subnet mask according to the network environment of the DVR GATEWAY: Setting the gateway according to the network environment of the DVR. If there is no router device in the network, please allocate an IP address on the same network. If there is a router device, you have to set the corresponding gateway. DNS1 and DNS2: setting the IP address of the domain name server (DNS varies from city to city); you can refer to the domain name server configurations of the PC. UPNP: When the UPNP function is on (UPNP function on the router end is also on), then the DVR will map the port and IP into the router automatically. DDNS SETUP Click “DDNS Setup” to enter the screen (picture below): DDNS (Dynamic Domain Name Server): with the two options of “ON” and “OFF”; when a dynamic domain name server is available, please select DDNS "ON"; SERVICE: The user may select his/her desired DDNS server, with the 6 options of 3322; dyndns;change ip;no‐ip;leadingdvr and oray. HOST NAME: Enter the host name registered on the dynamic domain name resolution server; ... -
Page 13: Mobile Phone Surveillance
16 Channel DVR Quick Manual Click OK to enter the router main interface, click the 【Applications & Gaming】as shown below: Put the DVR's IP and port (WEB port, media port, phone port) to fill in the corresponding location, the protocol is “Both”, and the state is “Enable” or Reboot. Then click “Save Settings”, add other ports in the same way. 15961 ... -
Page 14: Mobile Phone End Login
16 Channel DVR Quick Manual 2.10.2 Mobile Phone end login Taking the iPhone for example, run the iPhone’s APP Store program and search KMEye, find the installation package of application program, and click to install. Open the mobile phone software kMEye. For the first‐time use, modify the parameters. Click 【Settings】 to enter the parameter setting interface (left picture below), and the default port number is 15961. The user can set other port number on the DVR end. The default password is empty. Set the parameters well and connect the server, mobile phone ... -
Page 15: Player
16 Channel DVR Quick Manual same LAN, choose “LAN” mode. In this mode, the image video transmission format is CIF and frame rate is 25fps. Internet: If the computer and DVR are in different LAN, choose “Internet”. In this mode, the image video transmission format is CIF and the frame rate is 6fps. Language: Chinese and English are optional. OFFLINE: open the attached player and play local backup video file. Note: After successful login, the interface is the same as IE end. Please refer to the manual in the CD for detailed operation. 2.11.2 Player H.264 format video compression is adopted, and a special player is needed. Open the player’s installation program “PlaybackSetup.exe” in the CD. ... -
Page 16: Ie Login
16 Channel DVR Quick Manual Enter URL : Click“install” http://192.168.1.223:88 2.12.2 IE login After finishing the plug‐in units installation and then login. For example, the DVR’s domain name is dvrtest001.3322.org and the port is 88, enter the domain name http://dvrtest001.3322.org:88 in the IE address bar, as shown below: Password: Enter the IE password of DVR. This password is set at the Internet end. Please refer to the manual in the CD for details. Network: LAN: If the computer and DVR are in the same LAN, choose “LAN” mode .In this mode, the ... -
Page 17: Central Management Software (Cms)
16 Channel DVR Quick Manual end and perform the functions of video playback, video setup, alarming setup, etc. Please refer to the manual in the CD for detailed operation. 2.13 Central Management Software (CMS) This system supports connection to DVR through Internet, not through the support of intermediate server. It is convenient for user’s management. Software installation: Double click to run CD file “DVRCMS.msi”，finish as prompted. After successful installation, double click desktop icon and run software. Display as the following picture: 【user name】: Create the initial user name for login 【password】: Create the initial password 【Re‐enter】: Confirm the initial password 【Language】 : Chinese and English are optional. Note: If the earlier version of this software has ... - Page 18 16 Channel DVR Quick Manual System configuration Lock Add DVR Del DVR Playback configuration DVR list PTZ control Recording Screen split Capture Stop video Volume In the management software, there are adding device, live preview, video playback, system setup, advanced setting, PTZ control and so on. Please refer to the detailed instruction of CMS in the CD for specific operation. ...
-
Page 19: Appendix: System Connection Picture
16 Channel DVR Quick Manual Appendix: System Connection Picture 18 ...
