Specifications

Monitor
Specifications
LCD Module Diagonal :
Viewable Image Size :
Native Resolution (Pixel Count) :
Input Signal Video :
Sync :
Display Colors
Maximum Left/Right :
Viewing Angles Up/Down :
Synchronization Horizontal :
Range Vertical :
Resolutions Supported
Active Display Area Horizontal :
Vertical :
USB Hub I/P
Port
Load Current
Speakers
Practical Audio Output :
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Humidity:
Feet:
Storage Temperature:
Humidity:
Feet:
* Interpolated Resolutions: When resolutions are shown that are lower than the pixel count of the LCD module, text may appear different. This is
1
normal and necessary for all current flat panel technologies when displaying non-native resolutions full screen. In flat panel technologies, each
dot on the screen is actually one pixel, so to expand resolutions to full screen, an interpolation of the resolution must be done.
NOTE: Technical specifications are subject to change without notice.
MultiSync ® LCD ™
1560M
Monitor
15.0 inch Active matrix; thin film transistor (TFT)
15.0 inch liquid crystal display (LCD); 0.297 mm dot
1024 x 768 pitch; 300cd/m
450:1 contrast ratio, typical
ANALOG 0.7 Vp-p/75 Ohms Digital Input: DVI
Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
16,777,216 Dependent on display card used.
80°/80° (CR>5)
70°/80° (CR>5)
31.5 kHz to 60.0 kHz Automatically
56.2 Hz to 75.1 Hz Automatically
720 x 400* :VGA text Some systems may not support
1
640 x 480* @ 60 Hz to 75 Hz all modes listed.
1
800 x 600* 1 @ 56 Hz to 75 Hz
832 x 624* 1 @ 75 Hz
1024 x 768 @ 60 Hz to 75 Hz ......... NEC-Mitsubishi Electronics Display cites
recommended resolution at 75 Hz for
optimal display performance.
304.1 mm/12.0 inches
228.1 mm/9.0 inches
USB Specification Revision 2.0
Upstream 1
Downstream 4
Maximum 0.5A per port
1.0W + 1.0W
100 – 240 V ~ 50/60 Hz
1.0 – 0.5A
344.8 mm (W) x 344.2 mm (H) x 166.0 mm (D)
13.6 inches (W) x 13.6 inches (H) x 6.5 inches (D)
4.4 kg
9.7 lbs
5°C to 35°C/41°F to 95°F
30% to 80%
0 to 10,000 Feet
-10°C to 60°C/14°F to 140°F
10% to 85%
0 to 31,500 Feet
13
1-15
