Summary of Contents for Sangean BTS-101
- Page 1 BTS-101 中文 Version 1...
- Page 2 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by SANGEAN ELECTRONICS INC. is under license. © 203 CSR plc and its group companies. The aptX® mark and the aptX logo are trademarks of CSR plc or one of...
- Page 3 Control Strap holder Bluetooth status indicator Speaker Max volume indicator Battery charging indicator Microphone Power button Power lock Battery status indicator Aux in socket Volume up button DC In Volume down button NFC detection tag Bluetooth/Call answer-hangup button/Play and Pause button...
-
Page 4: Charging The Unit
Charging the unit This unit operates on a built-in Li-on battery that can be recharged either using the USB charging port or from a USB power adaptor (not included) with a rated output of DC 5V, 000mA. The first time using your BluTab (BTS-0) speaker, connect it to DC (mains) power and fully charge the battery. -
Page 5: Pairing And Connecting A Device To The Speaker
2. Activate Bluetooth on your device according to the device's user manual to link to the speaker. Locate the Bluetooth device list and select the device named ‘SANGEAN BLUTAB.’ With some mobiles (which are equipped with earlier versions than BT2. Bluetooth device), you may need to input the pass code “0000”. - Page 6 Be aware that during the period of disconnection, no other Bluetooth device can pair or link with your radio. 3) If ‘SANGEAN BLUTAB’ shows in your Bluetooth device list but your device cannot connect with it, please delete the Sangean BluTab item from your list and pair the device with the speaker again following the steps described previously.
- Page 7 3. Once connected, there will be a beep sound and the Bluetooth icon will remain in solid blue. You can simply select and play any music from your source device. Speaker memory and reconnecting a device BluTab can memorize up to 8 sets of paired device, when the memory exceed this amount, the least-recently-paired device will be erased from the radio.
- Page 8 3. Touch the NFC area of your playing device directly against the NFC tag marked on the rear panel of your BluTab. The unit then automatically connected with your NFC-enabled device. (If you pair with BluTab for the first time, some NFC-enabled device will be asked the permission to link with the speaker).
- Page 9 Playing music via auxiliary input socket A 3.5mm Auxiliary input socket is provided on the right hand side of the unit to permit an audio signal to be fed into the unit from any devices that features a headphone or audio output, such as an iPod, MP3 or CD player. .
-
Page 10: Power Lock
If the battery does not recharge after several attempts, it may be drained (has a low charge), please contact info@sangean.com.tw for repair information. However, if you do not want us to replace the battery, you will need to dispose of used batteries/device in accordance to the laws and regulations in your area. - Page 11 User Safety Precautions ● Check the room temperature range is 0°C–45°C (32°-113°Fahrenheit) before charging the battery. ● Do not attempt to disassemble the plastic covering or any parts of the device, as the materials inside may be toxic and may damage skin and clothes.
-
Page 12: Specifications
Specifications Amplifier Output power .5W+.5W Frequency response 50Hz~20kHz Aux In Input sensitivity 250mVrms @00Hz Speaker Stereo speaker 28mm 4 ohm 3W Full range Bluetooth Bluetooth specification Bluetooth® Ver 4.0 Profile Support A2DP, AVRCP(Only Play&Pause), HFP V.6, HSP V.2 Bluetooth Audio CODEC aptX, SBC, MP3 Transmitting Power Specification Power Class 2... - Page 13 General DC-IN Micro USB jack 5V A Power consumption 5V 0.5A (Charging in power OFF mode) 5V A (Charging in power ON mode) Charging current 0.5A Charging time 5 hours Storage temperature -20°C~ 60°C Operating temperature -10°C ~ 45°C Weight 330g The company reserves the right to amend the specification without notice.
