Summary of Contents for Sangean H200
- Page 1 H200 Version 1...
- Page 2 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by SANGEAN ELECTRONICS INC. is under license.
-
Page 4: Charging The Unit
USB charging port or from a USB power adaptor (not included) with a rated output of DC 5V, 1000mA. The first time using your H200 speaker, connect it to DC (mains) power and fully charge the battery. When the battery is in charging mode, the battery charging indicator light will be in solid red. -
Page 5: Power On The Speaker
Pairing and connecting a device to the speaker Pairing and playing your Bluetooth device for the first time You need to pair your Bluetooth device with your H200 before you can auto-link to play/ stream Bluetooth music through your Bluetooth speaker. Paring creates a `bond' so the two devices can recognize each other. - Page 6 4. Use the controls on your device to play/pause and navigate tracks. Note: 1. If 2 Bluetooth devices are pairing for the first time, both will search for the H200, it will show its available on both devices. However, if one device links with the speaker first, then the other Bluetooth device will not find the speaker on its list.
-
Page 7: Pairing Additional Devices
Speaker memory and reconnecting a device The H200 can memorize up to 2 paired devices. When the memory exceeds this amount, the earliest paired device will be erased from the speaker. If your Bluetooth device was already paired with the speaker previously, the unit will memorize your Bluetooth device and will attempt to reconnect with a device that is in the memory that was last connected. - Page 8 Your speaker is equipped with wireless NFC (Near Field Communication) feature, allowing NFC-enabled devices to pair and play the music with your H200. For non-NFC devices, please refer to the above sections for standard Bluetooth pairing. 1. Turn on the NFC feature on your device.
- Page 9 Disconnecting your NFC-enabled device To disconnect your device, simply touch your device directly against the speaker’s tag again on the front panel. There will be a confirmation tone sound and the Bluetooth status indicator ( ) on the speaker will flash a fast blue to show the speaker is discoverable.
-
Page 10: Battery Management
The H200 can be used as a hands-free accessory for your phone. When music is playing through your H200 and you receive a call on your phone it can pause the music automatically to allow you to answer your phone. -
Page 11: User Safety Precautions
If the battery does not recharge after several attempts, it may be drained (has a low charge), please contact info@sangean.com.tw for repair information. However, if you do not want us to replace the battery, you will need to dispose of used batteries/device in accordance to the laws and regulations in your area. - Page 12 For United States: Cautions to the user The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF exposure statements IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm (8 inches) from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 13: Specifications
Specifications Amplifier Output power 1.5W Frequency response 100Hz~20kHz Aux In Input sensitivity 250mVrms @100Hz Speaker Speaker 57mm 4 ohm 3W Full range Passive speaker 93x93mm Bluetooth Bluetooth specification Bluetooth® Ver 4.1 Profile Support A2DP, HFP,HSP Bluetooth Audio CODEC SBC, MP3 Transmitting Power Specification Power Class 2 Line of sight range... - Page 14 Sangean reserves the right to amend the specification without notice. If at any time in the future you should need to dispose of this product please note that: Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
