Summary of Contents for Sangean BLUEBOX BB-100
- Page 1 BLUEBOX BB-100 中文 Version 1...
- Page 2 The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by SANGEAN ELECTRONICS INC. is under license.
-
Page 3: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings Follow all instructions Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings. Install in accordance with the instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. - Page 4 For United States: Cautions to the user The changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. RF exposure statements IMPORTANT NOTE: To comply with the FCC RF exposure compliance requirements, the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm (8 inches) from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
-
Page 6: Lcd Display
Controls Volume Control knob Tuning Control knob FM antenna Charge LED indicator Bluetooth status indicator LCD display Preset 1/Rewind button Preset 2/Play/Pause button Preset 3/Fast-forward button Power button Band/Step button Preset 5 Preset 4/Bluetooth pairing button Speaker Battery Compartment AC power cord storage AC power cord Rechargeable battery (Charger)/Normal battery (Batteries) Switch Aux In socket... -
Page 7: Power The Radio
Power the radio 1. Installing the batteries, first turn the battery cover knob anti-clockwise to loosen and open the battery cover. Note: Before you insert the batteries, if you use non-rechargeable batteries, make sure the Charger/Batteries switch which is located inside the battery compartment is switched to the Battery position. If you use rechargeable batteries, make sure to switch Charger/Batteries switch to Charger position. - Page 8 IMPORTANT INFORMATION ON CHARGING AND USING RECHARGEABLE BATTERIES Recharge the batteries in any case at least every 2 months. Make sure the Battery Select switch inside the battery compartment is set to the “CHARGER” position. Put the batteries in the compartment while paying attention to the correct polarity of the batteries (+ and -).
-
Page 9: Manual Tuning
Manual Tuning 1. Press the Power button to turn on the radio. 2. Select the required frequency band by pressing the Band/Step button. 3. Be sure to screw in the rubber FM antenna properly to get best reception. For the AM band, rotate the radio to get best signal as the AM antenna is built into the radio. - Page 10 Software version/Setting tuning step Software version The software display cannot be altered and is just for your reference. 1. When the radio is switched off, press and hold the Band/Step button for 3 seconds until software version 'PXX' is shown on the display. Setting tuning step The Tuning steps in some countries maybe different from where you purchased the radio.
- Page 11 4. Use the controls on your Bluetooth-enabled device or on the radio to play/pause and navigate tracks. Note: 1) If 2 Bluetooth devices are pairing for the first time, both must search for your radio, it will show its availability on both devices. However, if one device links with this unit first, then the other Bluetooth device will not be found on the list.
-
Page 12: Reset The Radio
Disconnecting your Bluetooth device 1. Press and hold the Bluetooth pairing button for 2 seconds on the radio to disconnect with your Bluetooth device or turn off the Bluetooth function on your Bluetooth device to disable the connection. You will hear a beep and the Bluetooth status indicator on the radio will flash a fast blue to show the radio is discoverable again for pairing. -
Page 13: Specifications
Line of sight range 10 meters/30 feet Sangean reserves the right to amend the specification without notice. If at any time in the future you should need to dispose of this product please note that: Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
