20 Volt Cordless Jig Saw
241-0429
OPERATOR'S MANUAL
CAUTION:
To Reduce The Risk Of Injury, User Must Read And
Understand The Operator's Manual. Save These Instructions For
Future Reference.
For questions / comments, technical assistance or repair parts –
Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 241-0429 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MasterForce 241-0429

Summary of Contents for MasterForce 241-0429

  • Page 1 20 Volt Cordless Jig Saw 241-0429 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand The Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374. (M-F 8am – 6pm EST.)

  • Page 2: Table Of Contents

    TAbLE Of CONTENTS Safety Symbols ............Page 2 Safety Instructions .

  • Page 3: Safety Symbols

    SAfETy SyMbOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely. Symbol Designation / Explanation Name Volts Voltage...

  • Page 4: Safety Instructions

    SAfETy INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.

  • Page 5: Work Area Safety

    SAfETy INSTRUCTIONS 3. Do not expose power tools to WARNING: Read all safety rain or wet conditions. Water entering warnings and instructions.Failure to a power tool will increase the risk of follow the warnings and instructions electric shock. may result in electric shock, fire and / or 4.
  • Page 6 SAfETy INSTRUCTIONS 4. Remove any adjusting key or wrench 5. Maintain power tools. Check before turning the power tool on. A wrench misalignment or binding of moving parts, or a key left attached to a rotating part of the breakage of parts and any other condition power tool may result in personal injury.
  • Page 7 SAfETy INSTRUCTIONS SERVICE 8. Do not put pressure on the saw, such that it slows the motor down. Allow the saw blade to cut without pressure. You will 1. Have your power tool serviced by a get better results and you will be taking qualified repair person using only identical better care of your tool.

  • Page 8: Overview / Specifications

    OVERVIEW Lock-off Button Trigger Switch LED Worklight Blade Guard Orbital Control lever Tool-less Blade Clamp Locking Screw Cutting Angel Guide Shoe Plate Hex Key Parallel Guide Blade Clamp Lever Blade Blade Roller Guide Page 7...

  • Page 9: Assembly

    SPECIfICATIONS PRODUCT SPECIfICATIONS No load Speed 0-2200 SPM Blade stroke distance 1 in. (25 mm) Cutting angle range 0-45° Blade compatibility “ T” and “U” shank Weight (without battery) 4lbs. 3oz. 65mm on wood Max. cutting capacity 10mm on aluminum 6mm on steel ASSEMbLy UNPACkING...
  • Page 10 OPERATION TO ATTACH bATTERy SWITCHING ON AND Off (fIG. 2) PACk (fIG. 1) FIG. 2 FIG. 1 To turn the jig saw ON, keep the lock-off button depressed and squeeze the trigger switch. To Align the raised rib on the battery pack with turn it OFF, release the trigger switch.

  • Page 11: Operation

    OPERATION LED WORkLIGHT (fIG. 3) REMOVING SAW bLADE (fIG. 4) CAUTION: Allow the blade to FIG. 3 cool after use. The blade can become dangerously hot. 1. Remove the battery pack. LED Worklight 2. Press down on the blade clamp lever to remove the blade.
  • Page 12 OPERATION Set the orbit control lever to one of the CAUTION: Always ensure that the four settings according to degree of orbit jigsaw is switched off and the battery pack action required: is removed before making any adjustments. 0 No orbit action 1 Minimal orbit action 1.
  • Page 13 OPERATION PLUNGE CUTTING (fIG. 10) By changing the position of the guide and using the same straight edge as a guide, it is possible to quickly and easily make parallel FIG. 10 cuts in the workpiece. NOTICE: When adjusting the cutting angle, you can move the parallel guide locking screw to the left or right.

  • Page 14: Maintenance

    MAINTENANCE 2. Use a small brush or the air discharge WARNING: When servicing, use of a small vacuum cleaner brush to clear only identical replacement parts. Use of any dust or debris from the air vents on the other parts may create a hazard or cause motor housing.

  • Page 15: Warranty

    90-DAy MONEy bACk GUARANTEE: This MASTERFORCE brand power tool carries our 90-DAY Money Back ® Guarantee. If you are not completely satisfied with your MASTERFORCE brand ® power tool for any reason within ninety (90) days from the date of purchase, return...
  • Page 16 © 2013 Menard, Inc., Eau Claire, WI 54703 06/2013 Page 15...
