- Page 1 A L U M I N I U M GREENHOUSE Riga S/Riga Subject to technical changes! Current as of 09/203 Basic kit assembly instructions model Riga system width 2,96 m model Riga S system width 2,32 m...
- Page 2 (gable/eaves) profiles doors Riga S/II/III/IV Riga III/IV/V Start with the basic kit. Please do not open all the boxes at the same time. Let's not get confused by the variety of items. Before you begin assembly, check on the parts lists, if all parts are present. Each box goes through a quality check before it is closed, thus missing parts are almost excluded.
- Page 3 3 - 5 mm 3 - 5 mm 6 - 8 mm length length 72 mm 768 mm 030 mm 768 mm 030 mm 030 mm model model Riga S II Riga III Riga S III Riga IV Riga S IV Riga V...
- Page 4 !!!Note: Important information for glazing!!! The ISO-Cellular sheets, speak glazing, always install the UV coated side out. The plates have on the protective film has a hint. The protective film, first loosen the edges and only after the complete assembly pull it off immediately.
- Page 5 Expedient is also the creation of garden slaps or stone pavement, so the greenhouse at eg heavy rain is not covered by mud splashes is. In addition, the work made easier around the greenhouse, such as mowing the lawn. Riga S : Profiles and accessoires for foundation frame number/length in mm overview pos.
- Page 6 Assembly foundation frame The foundation frame profiles separately in the soil profiles rotate and center align. Note: The foundation frame profiles are shorter than soil profiles! Note: The founda- tion frame profiles To stabilisize the house, are shorter than the mounting bracket soil profiles! (V27) using bolts M6 x 2 (S2) retracted bolted to...
- Page 8 Content main box - basic kit Riga S/Riga Please check in the tables list the completeness of the components. Profiles for both gables: number/length in mm overview pos. description Riga S Riga soil profile/gable 2238 2238 2238 2874 2874 2874 .5.4 rand rung left - curved...
- Page 9 Accessories bag basic kit Riga S/Riga num- num- description/ overview pos. item number Ri g a S Riga corner soil profile item no 9999 0003 connecting plate Ortgangprofil/Türzarge item no 9999 0028 connecting plate 90 x 35 mm mounting cross bar/rear...
- Page 10 2 to step 2: Even now you need the small side windows. Dimensions are listed in the table. Riga S Riga With bar direction - vertical - in the 730 x 728 048 x 728 soil profile and sideways while in the door frame.
- Page 11 Assembly procedure gable view from inside ATTENTION! When using a foundation frame assemble in advance on this soil profile (see page 5, 6) step 5 to step 5: holes for door lock The square peg of the corner con- nector is plugged in the rand rung (pos..5.4/.5.6).
- Page 12 You should be careful: T-seals (V25) for all doors and windows (total: 5 meters) Attention! When the roof window for pushing into the ridge the T-seal at this side omit!!! In the door area the hose section(V4) is pressed into the soil profile. (As a Attention! In the bottom door is stop/seal to protect from dirt into the first pressed the seal, and only...
- Page 13 Assembly roof window corner with grub corner bracket/roof window (V24) screw (V3) window profil (pos.4.2) (Pull in this profile no seal!) First you screw three profiles, then use the glazing and finally attach the fourth profile. Recommendation! It is advisable to seal up around the window and the corner bracket, thus no moisture can occur.
- Page 14 Insertion of the seal in the roof window area pos. 4. Please insert all the 4 plastic corner connectors with sili- cone and seal the transitions cleanly ( cross-section of the seal pos. 4. pos. 3.2 length: 2,3 m The seal is inserted as the sketch above. Attention: Seal does not cut into the corners! Important! The transitions of the glazing and the corner bracket/roof window to roof →...
- Page 15 Parts window opener window opener pressure cylinder cotter pin mounting plate window profile mounting plate cross bar User guide - window opener - Assembly instructions: . Check whether the greenhouse window can open and close freely and unhinderedly. Please remove from other manufacturers in advance the existing hand openers. 2.
- Page 16 Profiles for divided revolving door - bottom - num- overview pos. description length in mm 5.3. door profile bottom door profile left with hole for sash lock door profile right with hinge hole door profile top with transverse hole square tube with transverse hole Content accessories bag divided revolving door - bottom - num-...
- Page 17 Assembly - divided revolving door - bottom - view from outside Place the profile like the image on a flat underground (possibly on cardboard or something similar). Square tube and door corner bracket door profile profile top screw with (V30/V3) self-tapping screw pan head 3,5 x 38 (S6).
- Page 18 Profiles for divided revolving door - top - number/length in mm overview pos. description Riga S Riga door profile left 08 264 door profile right with hinge hole 08 264 door profile top with hole for lockable door 5.4. cross bar...
- Page 19 Assembly - divided revolving door - top - view from outside Place the profiles like the image on a flat underground (possibly on cardboard or something similar). corner bracket door profile (V30/V3) door profile top (pos. 5.3) glazing block with sili- cone fix in position cross bar (pos.5.4.) self-tapping screw countersunk...
- Page 20 Profiles for rear window number/length in mm overview pos. description Riga S Riga 5..2 door profile left with hole for sash lock 08 264 door profile right with hinge hole 08 264 5.3. door profile top 5.4.2 door profile bottom...
- Page 21 Assembly - rear window - view from outside door profile top (pos. 5.3.1) sash lock, small (V28) with self-tapping screw glazing block with silico- countersunk 3,5 x 22 ne fix in position (S9) screws self-tapping screw countersunk head 4,2 x 45 (S7) cross bar (pos.
- Page 22 Assembly procedure - eaves - ATTENTION! When using a foundation frame assemble in advance on this soil profile (see page 5, 6) step 8 to step 8: First, the lateral soil profiles on the corner bracket on the gable attach. corner bracket (V2) screwed with self-tapping screw pan head 4,2 x 3 (S9).
- Page 23 Assembly procedure - eaves - ATTENTION! When using a foundation frame assemble in advance on this soil profile (see page 5, 6) step to step : The side rung (pos. 2.3) above into the ridge profile and below into the soil profile to glazing insert it.
- Page 24 Assembly procedure - eaves - ATTENTION! When using a foundation frame assemble advance on this soil profile (see page 5, 6) to step 4: step 4 The door gable is pre-mounted and screwed. For added stability must now mounting inside corner (V) be attached.
