HOKLARTHERM Livingten L5 Assembly Instruction Manual

Hide thumbs

Advertisement

Table of Contents

Commission:
Order no..:
Made in Germany
Greenhouse „Livingten"
Type L5
Assembly Instruction
Montageanleitung
Status:2024/02
Subject to technical changes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Livingten L5 and is the answer not in the manual?

Questions and answers

Related Manuals for HOKLARTHERM Livingten L5

Summary of Contents for HOKLARTHERM Livingten L5

  • Page 1 Commission: Order no..: Made in Germany Greenhouse „Livingten“ Type L5 Assembly Instruction Montageanleitung Status:2024/02 Subject to technical changes...
  • Page 2 Dear gardening friend, HOKLARTHERM®. Congratulations on your purchase of a quality product from Assembly is relatively simple. First read the assembly instructions and follow them step by step! Before assembly, the completeness of the parts should be checked against the parts lists. The boxes containing the parts undergo a quality check to ensure that there are no missing parts.

  • Page 3: Parts List

    Parts list Quantity Position Illustration Designation AG* foundation frame gable roof 1.4/2.1 Length 3439mm (from bore center pipe to bore center pipe) Top view (interrupted) *AG: Assembly group floor profile (front of/rear) (K10 glued-in glass modules) L.3354mm foundation frame (side part) 1.15 L.
  • Page 4 spacer bushing Ø16 L. 40mm downpipe holder Ø32 blanking plug Ø20 blanking plug Ø5 sliding door track in the gable (front) glued-in glass modules with reinforcement profile and A13 screwed) L. 3400mm sliding door track in the gable (rear) 8.41 glued-in glass modules (K10 L.
  • Page 5 eaves corner connector inside (right-hand) roof, front, rear and side glazing G/S/D 1997x829 roof glazing, short 1097x829 gable glazing front and rear GoA2 1003x829 gable glazing front and rear GoA1 1003x829 replacement glazing-bar TH as side glazing-bar 11.1 Lg:1976mm cover strip for replacement glazing-bar 13.6 (rear wall + side wall)
  • Page 6 rain gutter profile Type 5 Lg:4326mm round downpipe socket Ø28 L:30mm plastic rain gutter end cap (left-hand) K3.1 plastic rain gutter end cap (right-hand) gutter end plates (left-hand) gutter end plates (right-hand) end stop bar(glass)for the eaves profile TH 22.1 L:805mm silicone lip seal profile (white) L:805mm...
  • Page 7 alu-roof ridge end profile verge profile right-hand (hexagon head screw M6x50 + Hexagon nut M6 + washer mounted) L:1983mm verge profile left-hand (hexagon head screw M6x50 + Hexagon nut M6 + washer mounted) L:1983mm roof glazing-bar 14.5 Lg:1987mm end cap for roof glazing-bar AG-drawstring 21.1...
  • Page 8 plastic rectangular profile 25x15x1,5 18.6 Cross bar Lg:833mm AG-sliding door (main door leaf) (SHF) with glazing, seals, door handles and push lock, track roller profile and door guide rail mounted 869x2035 AG-sliding door (opposite door leaf) (SGF) with glazing, seals, door handles and push lock, track roller profile and door guide rail mounted 869x2035 plastic rectangular profile 25x15x1,5...
  • Page 9 Accessories* Item Designation Contents Quantity S1 hexagon head screw M6x12 Bag 1 S6 washer M6 foundation S4 hexagon nut M6 frame S1 hexagon head screw M6x12 S6 washer M6 Bag 3 S4 hexagon nut M6 foundation S2 hexagon head screw M6x50 frame S5.1 drilling screw countersunk head 4,2x22 S7 cap nut M6...
  • Page 10 Building the foundation (optional) Description Illustration oundation I.I. F Livingten TypL5 3500 outer foundation edge Foundation data • only have the structural analysis of foundation carried specialist company! • always observe the locally applicable building regulations. • get detailed advice on the foundation from your professional.
  • Page 11 II. Foundation frame II.I. Assembly of the foundation frame Description Illustration • slide the floor profile (item 4.4) 1.4/2.1 with the pre-assembled inner corner connectors (item 1.4/2.1) onto the outer raised groove of the gable-side AG foundation frame. • center the floor profile. fig.3 •...
  • Page 12 • align one of the AG side parts exactly with the edge of the concrete slab. • dimension X should be the same everywhere! (fig.9) fig.9 • a PVC pipe (item K2) is inserted into the pipe of the inner corner connector (item 2.1) as a drilling aid K2.1 (fig.10)
  • Page 13 Optional: Mounting directly on the base plate II.II. Installation without foundation frame • slide the PVC RKT 35x30x3.2 (item 3.4) into the groove of the floor profile (item 4.4). (fig.3a/fig.4a) • center the floor profile. • applies to front and rear gables. Schnitt A-A fig.3a fig.4a...
  • Page 14 • align one of the BG side parts exactly with the edge of the concrete slab. • dimension X should be the same everywhere! (fig.9a) fig.9a • the drilling aid (PVC pipe) (item K2.1 K2.1) is inserted into the hole in the corner connector (item K1).
  • Page 15 • the perpendicularity of the foundation is achieved by measuring the diagonals. (fig.13) • measure from the fixed PVC pipe (item K2) diagonally to the opposite PVC pipe (item K2), do the same with the (fig.13) other two PVC pipes(item K2). •...
  • Page 16 III.II. Mounting the AG-eaves-profiles • the prefabricated AG-eaves- profiles (item 6.5) are inserted into the corner profiles (item 5.2). (fig.15) • ensure that the prefabricated BG eaves profiles (item 6.5) rest completely on the corner profiles (item 5.2)! fig.15 III.III. Mounting the gable reinforcement profile insert hexagon bolt M6x12 (item B3S1 B3S1) into the milled groove of...
  • Page 17 • the prefabricated AG-gable-door- 8.41 track (item 8.4) is screwed to the eaves corner connectors (item E2/E3)! • the gable door track (item8.41) is screwed to the eaves corner (fig.17) connectors (item E2/E3)! • Detail B: insert a hexagon head screw M6x12 (item B3S1) into the milled groove of the prefabricated BG door rail gable (item 8.4) and fix it...
  • Page 18 • the side glazing-bar (eaves profile) connectors (item A2) are inserted into the milled groove of the prefabricated AG eaves profiles (item 6.5) and roughly (fig.19) positioned! • the side part connectors (floor profile) (item A1) are inserted into the milled groove of the AG- side-parts (item 1.15/4.15) and fig.19 roughly positioned!
  • Page 19 * Optional: Installation of a pop-up window or sliding doors in the side wall. See appendix for description! fig.24a/fig.24b Installation of a fig.24a fig.24b ventilation panel in the side wall. See appendix for description! fig.24c fig.24c • the remaining side glazing (item G/S/D) is inserted as described in the previous steps.
  • Page 20 IV.II. Mounting of side-profiles • the glazing panes are first moved in the direction of arrows 1.1, (fig.25) 2.1 and 3.1. • insert the hexagon head screws M6x12 (itemB10.6/ S1) at the bottom into the hole of the first side glazing-bar (item 10.1) and press one upwards and one...
  • Page 21 IV.IV. Mounting of the gable glazing-bars • the six hexagon head screws M6x50 Sectional view (item B3.1/S2) are inserted into the milled groove of the prefabricated AG-door-track (item 8.41) and the floor profile (item 4.4) and roughly positioned! 8.41 (fig.28) B3.1 B3.1 fig.28...
  • Page 22 * Optional: Installation of a pop-up window in the rear gable wall. See description in the appendix! (fig.29a) fig.29a IV.V. rear side glazing 8.41 • 7- slide the two rear glazing panels slightly tilted upwards into the AG-door-track (item 8.41) until they can be adjusted over the edge of the floor profile (item B3.1/4.4) at the bottom!
  • Page 23 IV.VI. Mounting of the gable glazing-bar (rear side) • slide the cut-out of the gable 12.1 glazing-bars (item 12.1/12.2) into 12.2 the AG-door-rail (item B3.1/8.41). • at the same time, insert two hexagon head screws M6x50 (item B3.1/S2) into the holes of the gable glazing-bar (item 12.1/12.2).
  • Page 24 the cover strips (item 13.5) are placed on the gable glazing-bars 12.2 (item 12.1/12.2) from the outside 12.1 and screwed in place with 5x countersunk screws 4.2x22 (item (fig.35) B3.0/S5.1) Note: The cover strips (item B3.0 13.5) with the slotted holes for -S5.1 the door locks must be installed in the front side.
  • Page 25 IV.VIII. Mounting of the gable glazing  the gable glazing should be installed with at least two people and two stepladders!  reachable height 2300mm!  please ensure that the stepladders stand securely during assembly (risk of accident)! • insert the left-hand large gable 14.2 glass pane (item GoA2) in the direction of the arrow.
  • Page 26 • the work steps described in fig.38/39 are repeated for both the right rear side of the gable and for the opposite gable front. (fig.40) fig.40 V. Mounting of the roof construction V.I. Mounting the AG ridge profile type L5 ...
  • Page 27 V.II. Mounting the roof profiles 14.5 • place the roof profile (item 14.5) on the ridge profile connector, slide it into the ridge seam (item 9.5) and place it on the eaves profile (item 6.5). see details G and H. (fig.44/45) fig.44 sectional view...
  • Page 28 • as described in fig. 44 to 46, the work steps are repeated for the 14.5 (fig.47) remaining roof profiles fig.47 V.III. Mounting of the AG-drawstring • the position of the AG drawstring (item 21.1) is mounted between the third and fourth field, as in fig.48.
  • Page 29 V.IV. Mounting of the verge profile • place the verge profile (item 5.4/5.5) on the connector of the ridge profile and slide it over the edges of the window pane into the ridge rebate (item (fig. 50) 9.5). • (page 27 fig.45) see detail G.
  • Page 30 VI.Mounting oft the roof glazing VI.I. Mounting of the the lip seal • for sealing, the eight prefabricated lip seals (item Lpd) (820 mm) are inserted between the roof profiles in the eaves profile condensation (fig. 53) gutter. fig.53 sectional view Note: •...

  • Page 31: Sectional View

    VI.II. Mounting of the roof glazing • the ISO roof glass panes (item G/S/D) are inserted one after the other into the groove of the roof glazing-bars. (fig.55) whereby the short ISO roof glazing (item DuF) is installed in the (page 32 fig.58) second position.
  • Page 32 • the work steps from fig. 55 to 57 are repeated for the remaining glass panes and end stop bars. (fig. 58) fig.58 • install the two AG-crossbars (wall glazing-bars) (item QR) for the roof windows. (fig. 59) • Note the installation position! fig.59 •...
  • Page 33 VI.III. Mounting oft the roof windows • the two pre-assembled and glazed roof windows (item DF) are inserted into the profile holder provided at the end of the ridge profile up to the roof window opening. (fig. 61) • (fig. 62) see front view •...
  • Page 34 VI.IV. Mounting the MegaVent® window opener the room air climate is regulated automatically by the roof windows. • front view (inside) the two automatic window openers (item AFÖ) are mounted to the connecting plate of the roof window (item DF) and the crossbar (item 10.1) with four hexagon head screws M6x12 (item B30.1/ S1) each.
  • Page 35 • note the installation position of the two automatic window openers! • the dimension is 848mm from the angled ridge plate to the rear plate of the mounting bracket. • (fig. 66) turn the adjusting screw to set the parallelism of the window opener! fig.66 VII.
  • Page 36 VII.II. Mounting of the sliding doors • the sliding doors (item SHF/SGF) are placed on the left and right sides of the guide rail of the floor profile (item 4.4) and pushed parallel into the guide groove of the door track (item 8.4).

  • Page 37: Inside View

    VII.III. Inserting the locking pin • slide the ring hook (item RH) with hexagon nut M6 and lock nut M6 (item KM) from the inside right upwards into the lower fastening hole of the repair glazing-bars (item 12.1) until you can 12.1 insert the locking pin (item E6) into the hole of the repair glazing-bars...
  • Page 38 VIII.II. Mounting of the rainwater pipes • screw the two downpipe holders (item B6/ K9) and spacer sleeves (item B6/ K6) to the corner profile (item 1.17) using one pan-head screw (item B6/ S8) (fig. 77) 3.5x50 each. • see detail N. (fig.
  • Page 39 VIII.III. Mounting of the blanking plugs • fit a Ø20 blanking plug (item K18) in the holes for the rain gutter (item 7.5) on the left and right-hand side. (fig. 81) • Seal both blanking plugs (item K18) from above in the rain gutters with silicone! (fig.
  • Page 40 VIII.V. Mounting of the the gutter end plates • attach the four left and right gutter end plates (item B4.5/ A4/A5) to the verge profiles (item 5.4/5.5) and A4/A5 screw them to the front and rear with 5.4/5.5 five pan-head screws Ø4.2x16 each (item B4.5 S4) with the fitted plastic gutter end caps (item B4.5/ K3/K3.1).
  • Page 41 IX.II. Mounting of the decorativ sheet metal elements • first insert an decorative edge element (item RZ) into the groove of the ridge profile. • insert three decorative middle elements (item MZ). • finally, insert a decorative edge (fig.89) element (item RZ). fig.89 •...
  • Page 42 IX.III. Mounting of the plastic roof end ridge cap • fill the cut-out in the two plastic ridge end caps (item B5.5/ K5) with (fig. 91/92) silicone. Silicone fig.91 fig.92 • press the two plastic ridge end caps (item B5.5/item K5) onto the front and rear of the ridge profile (item 9.5).
  • Page 43 IX.IV. Mounting of the Alu-roof ridge end caps • screw the two alu-roof ridge end caps (item B5.5/ item A6) with the mounted plastic roof ridge end caps (item B5.5/ item K5) to the ridge profile (item 9.5) at the front and rear using six pan-head screws Ø4.2x16 (item B4.5 S4) each.
  • Page 44 X.III. Sectional views of seals • section view roof ridge profile. (fig.100) • section view side glazing (horizontal) (fig.101) • section view roof glazing (vertical) (fig.102) • section view top side glazing (vertical) fig.103 (fig.103) fig.100 • section view Bottom side glazing (vertical) (fig.104) •...
  • Page 45 X.V. Installation of the plastic rectangular tubes in the area of the double sliding door Section through the front interior • insert the PVC-RKT 25x15x1.5x1682 sectional view (item 18.1) with silicone into the glass groove of the floor profile (fig.107) (item 4.4).

  • Page 46: Detailed View

    X.VI. Installation of the plastic rectangular pipes in the roof window area • insert the two PVC RKTs 25x15x1.5x833 (item 18.6) with silicone into the glass groove of the crossbars (item 10.1). (fig.113/115) • for installation position, see section- (fig. 114) and detailed view (fig. 115) view from below sectional view 10.1...
  • Page 47 Appendix for optional built-in parts Parts list Item Illustration Designation Quantity AG sliding door side main leaf (SsHF) with glazing, seals, door handles and push lock, track roller profile and SsHF door guide rail mounted 869x2005 AG sliding door side opposite leaf (SsGF) with glazing, seals, door handles and push lock, track roller profile and SsGF door guide rail mounted...

  • Page 48: Mounting Accessories

    side glazing, short 1084x829 hand opener PVC RKT 25x15x1,5 18.5 Roof glazing-bars Lg:862mm PVC RKT 25x15x1,5 18.6 crossbar Lg:833mm sliding block KuSt 40x12x4 profile of the side window LG:890mm PE-spacer LG:890mm connecting plate gable aluminum composite panel AVPG 1003x534x829x21 side wall aluminum composite panel AVGS 900x829x21 Mounting accessories*...
  • Page 49 XI.Mounting of the side sliding doors XI.I. Installing the wall glazing-bars in the side part (from page 19) • the glazing is inserted as described in the previous steps on pages 18/19 (fig. 21/22). The positions for the sliding doors remain free.
  • Page 50 • insert the hexagon head screws B10.6 B10.6 M6x12 (item B10.6/ S1) at the Passage sliding doors bottom into the hole of the 1st side glazing-bar (item 10.1) and pull one upwards and one downwards into the groove of the connector. (fig.124) •...
  • Page 51 • sectional view of the sliding door (fig.127) fig.127 • sectional view of sliding door (fig.128) • detail P: eaves profile groove (fig.129) • detail Q: floor profile guide rail (fig.130) fig.129 fig.128 fig.130 XI.IV. Mounting of the the locking pin •...
  • Page 52 XII.Mounting of the side-window in the side wall XII.I. Glazing installation (from page 19) • the glazing is inserted as described in the previous steps on pages 18/19 (fig. 21/22). • side glazing (item SuF) should be secured with an aid to prevent it from tipping over or held by a second fig.131 person!
  • Page 53 XII.II.Installation of the side-glazing-bars and cross struts • the small glazing pane (item SuF) is first moved in the direction of arrow 1. (fig.134) • the crossbar (item 10.3) is placed on the small glazing pane (item (fig.134) SuF). • then the small glazing pane (item SuF) is pushed with the crossbar (item 10.3) in the opposite...
  • Page 54 • slide the side window (item DF) into the profile of the side window (AFP) until the end position is reached. (fig.137) • see detail S (fig.138) fig.137 fig.138 Detail S • mount the side window (itemDF) on both sides in the groove of the profile of the side window (AFP)using 2x washers (item S23) and 2x pan-head screws (item S24).
  • Page 55 • attach the hand-opener (item HAS) 10.3 to the crossbar (item 10.3) using a sliding block (item KuSt) and 2x countersunk screws (item S20). (fig.141) • Mount the hand opener (item HAS) with 2x countersunk screws (item S20) and 2x hexagon nuts (item S22) on the connecting plate (item ABB).
  • Page 56 • insert PE spacer (item ASH) with profile of the side window (item AFP) into the door track groove (fig.144) (item 8.41). • see detail T (fig.145) 8.41 fig.144 -S26 Detail T fig.145 • the PE spacer (item ASH) with the profile of the side-window (item AFP) must be flush with the outer edge of the side-glazing-bar and...
  • Page 57 • slide the side window (item DF) into the profile of the side window (AFP) until the end position is reached. (fig.147) • see detail U (fig.148) fig.147 fig.148 Detail U • mount the side window (item DF) on both sides in the groove of the profile of the side window (AFP)using 2x washers (item S23) and 2x pan-head screws (item S24).
  • Page 58 • attach the hand-opener (item HAS) 10.3 to the crossbar (item 10.3) using a sliding block (item KuSt) and 2x countersunk screws (item S20). (fig.151) • mount the hand opener (item HAS) with 2x countersunk screws (item S20) and 2x hexagon nuts (item S22) on the connecting plate (item ABB).
  • Page 59 XIV.II. Mounting of the gable aluminum composite panel • Insert the gable aluminum composite panel (item AVPG). • i.e. adjacent in the gable center glazing-bar groove (item 14.2) and resting in the BG door track groove (item 8.41). • the cover strip for gable glazing-bar AVPG (item 13.1) is placed on the gable 14.2...
  • Page 60 Have fun with our product, your company Hoklartherm® Status 2024/02...
