Subject to technical changes!
assembly instructions
model Riga S
Width 2,32 m / 7ft 8in
www.exaco.com
877-760-8500
customerservice@exaco.com
Riga S/Riga
Basic kit
A L U M I N I U M
GREENHOUSE
Assembly Animation Video
is available on our YouTube page,
find the link at www.exaco.com or
scan the QR code below:
model Riga
Width 2,96 m / 9ft 8in
Version 4.2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Riga S and is the answer not in the manual?

Questions and answers

Related Manuals for HOKLARTHERM Riga S

Summary of Contents for HOKLARTHERM Riga S

  • Page 1 Assembly Animation Video is available on our YouTube page, find the link at www.exaco.com or scan the QR code below: model Riga Width 2,96 m / 9ft 8in model Riga S Width 2,32 m / 7ft 8in www.exaco.com 877-760-8500 customerservice@exaco.com...

  • Page 2: Table Of Contents

    Table of Contents Before You Begin……………………………………………………………………………..2-3 Polycarbonate Information………………………………………………………………………..4 Foundation Frame (optional accessory)………………………………………………………5-6 Site Planning and Preparation with Foundation Measurements………………………………7 Main Box Contents – Basic Kit………………………………………………………………...8-9 Gable Assembly……………………………………………………………………………….10-11 Roof Windows Roof Window Parts/Assembly………………………………………………………12-14 Roof Window Auto Opener………………………………………………………….15-16 Wind Restraints for High Wind (optional)………………………………………………17 Door Assembly Door Bottom Half………………………………………………………………….…..18-19 Door Top Half …………………………………………………………………………20-21...

  • Page 3: Before You Begin

    Thank you for purchasing a Riga greenhouse! Please read all the assembly instructions then follow them step by step. We also recommend following our YouTube animated assembly video. Find the link to the Exaco YouTube page on our website at www.exaco.com. If you have questions or run into any difficulty, please give us a call at 877-760-8500.
  • Page 4 72 mm 768 mm 768 mm 030 mm 030 mm 030 mm model (28.03 in) model (30.24 in) (30.24 in) (40.55 in) (40.55 in) (40.55 in) Riga S II Riga III Riga S III Riga IV Riga S IV Riga V...

  • Page 5: Polycarbonate Information

    !!!Note: Important information for glazing!!! When installing the polycarbonate glazing make sure the UV coated side faces out. Loosen the edges of the protective film for installation. After the assembly is complete pull it off immediately. Do not leave the film on for any period of time in the sunlight. Several days of sunlight can burn the film firmly on the glazing.

  • Page 6: Foundation Frame (Optional Accessory)

    It is also very practical to install tile or stone flooring, this prevents the mud from splashing on the greenhouse during heavy rain and makes work easier around the greenhouse, such as mowing the lawn. Riga S : Profiles and accessories for foundation frame number/length in mm/inches overview pos.
  • Page 7 Assembly foundation frame Self-tapping screw placement Rotate the foundation frame profile into the soil profile. Make sure it is centered in the soil profile. Note: The foundation frame profiles are shorter than soil profiles To stabilize the greenhouse, use the mounting bracket (V27) Note: The founda- with bolts M6 x 2 (S2)

  • Page 8: Site Planning And Preparation With Foundation Measurements

    Greenhouse on a Stem Wall Foundation plan Riga S/Riga (Requires optional door extension/drop door kit) Construction with a perimeter or strip foundation You must have a door extension kit to place the Riga greenhouse If you have not purchased a foundation frame secure the greenhouse by on a stem/knee wall.

  • Page 9: Main Box Contents - Basic Kit

    Main box Contents - basic kit Riga S/Riga Please check contents list to make sure all items are there Profiles for both gables: number/length in [in] overview pos. description Riga S Riga 2874 2238 2238 2238 2874 2874 soil profile/gable "...
  • Page 10 Accessories bag basic kit Riga S/Riga num- description/ overview pos. item number Riga Riga S Soil profile corner item no 9999 0003 connecting plate Edge Clamp/Door Frame item no 9999 0028 connecting plate 90 x 35 mm For mounting cross bar/rear...

  • Page 11: Gable Assembly

    2 to step 2: Now you need the small side glazing. Slide the side glazing into the door frames and soil profile. Riga S Riga The dimensions are listed in the 730 x 728 048 x 728 diagram.
  • Page 12 Assembly procedure gable ATTENTION! When using a foundation frame attach it to soil profile in advance (see pages 5, 6) step 5 to step 5: view from outside The square peg in the soil profile corner (V9) is plugged into the bottom of the Edge curve (pos.1.5.4/1.5.6).

  • Page 13: Roof Windows

    Roof Windows Profiles for roof windows (per roof window) num- overview pos. description length in mm roof window side profile / 21 " 3/16 roof window top/bottom profil / 37 " Content accessories bag roof window (per roof window) num- overview pos.
  • Page 14 Assembly roof window corner with grub corner bracket/roof window (V24) screw (V3) Top window profile (pos.4.2) (This profile requires no T-seal) Attach the roof window side profiles to the bottom roof window profile using the corner brackets and the metal corners with grub screws.
  • Page 15 Sealing the roof window area pos. 4. Apply silicone to black corner connectors where they meet the profiles. Apply silicone where the polycarbonate meets the aluminum frame. ( pos. 4. pos. 3.2 ________ Also use silicone to seal between the crossbar (pos 3.2 ) and the curves of the greenhouse cross-section of the flat seal...

  • Page 16: Roof Window Auto Opener

    Automatic Window Opener opener frame pressure cylinder cotter pin mounting plate window profile mounting plate cross bar Auto Opener Installation Check whether the greenhouse window can open and close freely and unhindered. Install the opener with the mounting plate (4) in the center of the lower roof window profile (pos 4.2) Secure the cylinder by lining up the hole in the piston with the upper hole in the T-coupling, then insert the cotter pin.
  • Page 17 Riga Greenhouse Window Auto Opener Correct Installation In the correct position, the opener is sitting parallel to the window, which means that it will not demand a lot of pressure from the cylinder when the opening starts. Before fitting a new cylinder to the openers, you must check that the window can open freely right from the start.

  • Page 18: Wind Restraints For High Wind (Optional)

    Roof Vent Recommendation for High Wind Areas If you get strong wind gusts, we recommend protecting your roof vents and openers with restraint cables. Roof vent restraints can be purchased from Exaco Trading (US distributor of Rigas) or can be made, they are not a standard part from the Riga manufacturer.

  • Page 19: Door Bottom Half

    Profiles for divided revolving door - bottom - num- overview pos. description length in mm 5.3. door profile bottom " 9/16 door profile left " with hole for sash lock " door profile right with hinge hole " door profile top with transverse hole 9/16 "...
  • Page 20 Assembly - divided revolving door - bottom - view from outside Lay the profiles out like the diagram below (possibly on cardboard or something similar). First: Insert T seal in corner bracket door profil Door profile top (pos (V30/V3) 5.8) Second: Attach square tube to door profile to (pos 5.8)

  • Page 21: Door Top Half

    Profiles for divided revolving door - top - number/length in mm overview pos. description Riga S Riga 264 08 door profile left " " 9/16 08 264 door profile right with hinge hole " " 9/16 door profile top "...
  • Page 22 Assembly - divided revolving door - top - view from outside Place the profiles on the ground or a flat surface like the diagram below (possibly on cardboard or something similar). corner bracket door profile (V30/V3) door profile top (pos. 5.3 Fix glazing block in place with silicon cross bar (pos.5.4.)

  • Page 23: Door Catch Installation

    Installation of Door Catch Door Catch Placement Riga Model IIs, IIIs, IVs Edge Curve Handle with Screw Cap 3.5 x 13mm Screw Door Catch Placement Riga Model III, IV, V Crossbar Handle without Crossbar Screw Cap 3.5 x 13mm Screw...

  • Page 24: Rear Window

    Profiles for rear window number/length in mm overview pos. description Riga S Riga 08 264 5..2 door profile left with hole for sash lock " " 9/16 08  264 door profile right with hinge hole " " 9/16 5.3. door profile top "...
  • Page 25 Assembly - rear window - view from outside door profile top (pos. 5.3.1 In this position on the INSIDE install sash fix glazing block in place lock, small (V28) with with silicone screw countersunk 3,5 x 22 (S19) screws Screw countersunk head 4,2 x 45 (S7)

  • Page 26: Assembling The Eaves/Sidewalls

    Assembly procedure - eaves - ATTENTION! When using a foundation frame attach it to the soil profile before these steps (see pages 5, 6) step 8 to step 8: Note: If you have purchased a foundation frame attach it to the soil profiles before you attempt this step.
  • Page 27 Assembly procedure - eaves - ATTENTION! When using a foundation frame assemble in advance on this soil profile (see pag s 5, step  to step : First place a side curve up against the edge curve installed on the gable end. You want to match curvature of the edge curve with the side curve.

  • Page 28: Installing Roof Windows/Doors

    Assembly procedure -eaves- ATTENTION! When using a foundation frame attach it to soil profile in advance (see pages 5, 6) to step 4: step 4 Attach the preassembled door gable. Refer to steps 8-9 for attachment procedures. For added stability install the inside corner (V).

  • Page 30: Riga Top Shelf

    Riga Assembly Instructions Top Shelf Parts list Top shelf: Riga Riga Riga Riga Riga Description pos. overview III/IIIS IV/IVS V/VS longitudinal profile strut (Ø20 x 1,5) - 32 inches angle-end tail (narrow) cross-brace V161 connector with grub screw S12/ hexagonal screw M6 x 12 with nut M6 hexagonal screw M6 x 16 with nut M6 T-head bolt M6 x 16 with nut M6 S15/...
  • Page 31 Before beginning step 1 of assembly, take time to prepare your longitudinal profile: Connect your longitudinal profiles using connectors with grub screws (may be preinserted into your longitudinal profile). The sections of longitudinal profiles (pos 1) are connected with connectors with grub screws (V161) as shown to the left. Tighten the set screws/grub screws with included Allen wrench.
  • Page 32 Riga Table Shelf Assembly Step 1 Attach an angle-end tail (V36) to each end of the struts (pos. 3). Push in as far as it will possibly go - it is okay if it does not fully insert. Step 2 In the lower cannel on the outside of the stabilization angle (pos.
  • Page 33 Attach the cross-braces (pos. 5) to the greenhouse lateral support with inserted bolt and nut and let them hang. Rest ends of assembled longitudinal profile (pos 1) on the greenhouse gable crossbar. Then, starting at centermost curve, attach crossbrace to bolt in longitudinal profile (pos 1), then install strut assembly beneath and tighten with nut.

  • Page 34: Riga Bottom Table Shelf

    Riga S/Riga Assembly Instructions Table Shelf Parts list table shelf: Riga Riga Riga Riga Riga Description pos. overview III/IIIS IV/IVS V/VS longitudinal profile cross-profile strut (Ø20 x 1,5) - 18 inches angle-end tail (narrow) cross-brace angle connector with grub screw...
  • Page 35 Before beginning step 1 of assembly, take time to prepare your longitudinal profile: Connect your longitudinal profiles using connectors with grub screws (may be pre-inserted into your longitudinal profile). The sections of longitudinal profiles (pos 1) are connected with connectors with grub screws (V161) as shown to the left. Tighten the set screws/grub screws with included Allen wrench.
  • Page 36 Riga Table Shelf Assembly Step 1 Attach an angle-end tail (V36) to each end of the struts (pos. 3). Push in as far as it will possibly go - it is okay if it does not fully insert. Step 2 Insert one M6x12 (pos S12) bolt at each end of the the greenhouse lateral support.
  • Page 37 Step 6 Attach the cross-braces (pos. 5) to the greenhouse lateral support with inserted bolt and nut and let them hang. Rest ends of assembled longitudinal profile (pos 1) on the greenhouse gable crossbar. Then, starting at centermost curve, attach crossbrace to bolt in longitudinal profile (pos 1), then install strut assembly beneath and tighten with nut.

  • Page 38: Exhaust Fan Installation

    Exhaust Fan installation for RIGA XL, RIGA 4 & RIGA 5 If you have both an intake shutter vent and exhaust fan, you will want them to be opposite/diagonal from each other to get the best cross-breeze. Plug the fan into the thermostat (optional) to control when it turns on.

  • Page 39: Intake Vent Installation

    Intake Shutter Vent Installation for RIGA XL, RIGA 4 & RIGA 5 You will want your intake shutter vent to be opposite from your exhaust fan (i.e. opposite wall and lower part of the greenhouse) to get the best cross-breeze. They should both be plugged into the thermostat with a plug splitter to engage them simultaneously.
  • Page 40 Customer Service or Assembly Questions? Give us a call Toll free: 1-877-760-8500 customerservice@exaco.com Exaco Trading www.EXACO.com Please watch our animated assembly video on our Exaco Trading Co YouTube Channel. Find the link at www.exaco.com...
