POWER REQUIREMENT CLASSIFICATION

Ref.
BS
FUSE2.3
JIS
SA
IEC
PHONIC CORPORATION
POWER REQUIREMENT CLASSIFICATION
Phonic Part No.
070-20588-800-0
280-1538B-000-0
280-20263-000-0
370-26640-432-6
527-11000-000-0
573-10032-010-0
070-20580-600-0
280-2026B-000-0
280-2538B-000-0
370-24810-602-0
527-11000-000-0
070-20588-800-0
280-1538B-000-0
280-20263-000-0
370-15020-829-0
527-11000-000-0
070-20588-800-0
280-1538B-000-0
280-20263-000-0
370-23610-902-0
527-11000-000-0
MAX860/1500/2500 SERVICE MANUAL
Specification
X'MER 115/230V MAX2500
FUSE 15A 250V UL/CSA/JIS S
FUSE T2A 250V VDE S
P/CORD 250V/15A 2.5M 3P BS
STR.REL BUSHING 6W3-4 R
(6N3-4 )
POWER LABEL (ONLY USED IN BS)
X'MER 100V JIS MAX2500
FUSE 2A 250V UL/CSA/JIS S
FUSE 25A 250V S UL/CSA/JIS
P/CORD 125V/15A 2.0MM/2P 2.5M
JIS
STR.REL BUSHING 6W3-4 R (6N3-4)
X'MER 115/230V MAX2500
FUSE 15A 250V UL/CSA/JIS S
FUSE T2A 250V VDE S
P/CORD 15A/250V 1.0MM*3 6F 3P
STR.REL BUSHING 6W3-4 R (6N3-4)
X'MER 115/230V MAX2500
FUSE 15A 250V UL/CSA/JIS S
FUSE T2A 250V VDE S
P/CORD 230V 15A 2.5M3P
STR.REL BUSHING 6W3-4 R (6N3-4)
Page 24
