Miscellaneous Items - Phonic MAX 860 Service Manual

Ref.
POWER SW
SPK-L
E-444
E-444
VAC
P_GND
V+
L-
L+
H-
H+
SPK_L
SPK_R
SPK_GND_L
SPK_GND_R
PHONIC CORPORATION
Phonic Part No.
210-03101-070-0
211-17000-410-0
212-10010-650-0
212-10010-750-6
212-10010-760-6
212-10010-770-0
212-10010-780-0
212-10010-790-0
212-10010-800-0
212-10010-810-0
212-10010-820-0
212-10010-830-0
212-10010-840-0
212-10010-850-0
212-10010-860-0
212-10010-870-0
307-00000-070-0
315-00000-000-0
321-00000-070-0
347-00000-201-0
510-21000-902-0
511-20680-101-0
516-20440-100-0
517-20600-100-0
518-20270-100-0
525-00009-100-0
526-10056-110-0
528-00000-000-0
528-60012-000-0
540-20390-120-0
551-20074-200-0
551-60055-200-0
552-20048-420-0
560-21070-100-0
MAX860/1500/2500 SERVICE MANUAL
Specification
SSA/SW
BINDING POST BP-47-2P
1P WAFER/P 100MM UL1015#14
RED
1P WAFER/P 1617#14 AWG 370MM
BLUE
1P WAFER/P 1617#14 AWG 320MM
RED
1P WAFER/P 220MM BLK
1P WAFER/P 240MM BWN
1P WAFER/P 260MM RED
1P WAFER/P 280MM ORANGE
1P WAFER/P 300MM YLW
1P WAFER/P 320MM BLUE
1P WAFER/P 340MM WHT
1P WAFER/P 320MM RED
1P WAFER/P 160MM ORANGE
1P WAFER/PP 150MM BLK
1P WAFER/P 150MM BWN
CORD CONNECTOR C5
LUG D4 GROUND
CABLE TIE HW-100MM
FAN JF0825S2H-419
PANEL MAX2500
BACK PANEL MAX2500
TOP COV. MAX SERIES PHONIC
BOT COV. MAX SERIES PHONIC
FAN COV. MAX SERIES PHONIC
FEET D26.5*11 BLK
LINK HEAT SINK
FAN NET WHT PWA2200 8"
NET MAX860/1500/2500
R/KNOB D18*18MM BLK
FIXED SECC T=1.5MM BRKT/R MAX
FIXED SECC T=1.5MM BRKT/L MAX
ADHESIVE FIXED FW-5D-3M
CARTON MAX2500 570*540*100
Page 21
