Figure A-2 shows the pinout of the 15-pin D-sub Socket.
FIGURE A–2.
TABLE A–2.
Pin
1
2
3
4
Figure A-3 shows the pinout of the USB Type B Socket.
FIGURE A–3.
Vision MINI Smart Camera Guide
15-pin D-sub Socket
USB and I/O Cable Pin Assignments (USB Type B Socket)
Function
Vbus (5V)
D–
D+
Ground
USB Type B Socket
Vision MINI Smart Camera Connectors
