Chapter
2
System Components
Back
Figure 2-3 shows the back of the Vision MINI Smart Camera.
FIGURE 2–3.
USB / I/O cable
(attached)
2-4
Back
Status Indicators (TRIG, PASS,
FAIL, MODE, LINK/ACT, PWR)
AutoVISION
Button
Vision MINI Smart Camera Guide
