Summary of Contents for Quanmax KPC-1910 Series

  • Page 1 KPC-1910 Series Industrial Panel PC User’s Guide Rev. 2.00 May 1, 2008...
  • Page 2 © 2008 Quanmax Inc. All rights reserved. The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others.
  • Page 3: Table Of Contents

    Wi-Fi Driver and Utility Installation (optional) ........3-9 KPC-1910 Series User’s Guide...
  • Page 4 External Connectors ............5-3 KPC-1910 Series User’s Guide...
  • Page 5 Table 5-7. Audio Jack Connector pin definition ........5-5 Table 5-8. COM2 RS232/422/485 Serial Port Connector pin definition ....5-5 KPC-1910 Series User’s Guide...
  • Page 6 KPC-1910 Series User’s Guide...
  • Page 7 Figure 3-1. AC inlet location ..........3-3 KPC-1910 Series User’s Guide...
  • Page 8 KPC-1910 Series User’s Guide...
  • Page 9: Safety Instructions

    Safety Instructions Contents Before You Begin ........ix When Working Inside a Computer .
  • Page 10 This page intentionally left blank. viii KPC-1910 Series User’s Guide...
  • Page 11: Before You Begin

    Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. WARNING High voltages are present inside the chassis when the unit’s power cord is plugged into an electrical outlet.
  • Page 12: When Working Inside A Computer

    Also, before connecting a cable, make sure both connectors are correctly oriented and aligned. CAUTION Do not attempt to service the system yourself except as explained in this user’s guide. Follow installation and troubleshooting instructions closely. KPC-1910 Series User’s Guide...
  • Page 13: Preventing Electrostatic Discharge

    Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment.
  • Page 14 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 15: Preface

    Preface Contents How to Use This Guide ....... . . xv Unpacking .
  • Page 16 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 17: How To Use This Guide

    This guide is designed to be used as step-by-step instructions for installation, and as a reference for operation, troubleshooting, and upgrades. Note: Driver downloads and additional information are available under Downloads on our web site: www.quanmax.com. The following is a summary of the chapter contents: Chapter 1, Product Introduction, presents the product specifications and system architecture for the KPC-1910.
  • Page 18: Unpacking

    2) Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. 3) Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure.
  • Page 19: Regulatory Compliance Statements

    (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense. Changes or modifications not expressly approved by Quanmax could void the user's authority to operate the equipment.
  • Page 20: Warranty Policy

    Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder.
  • Page 21: Maintaining Your Computer

    This can cause electrical problems related to arcing and corona effects. This condition can also cause sealed components with internal pressure, such as electrolytic capacitors, to fail or perform at reduced efficiency. KPC-1910 Series User’s Guide Maintaining Your Computer -xix...
  • Page 22: Power Protection

    5 minutes of battery power let you conduct an orderly shutdown of the system, but are not intended to provide continued operation. Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. KPC-1910 Series User’s Guide...
  • Page 23: Product Introduction

    Chapter 1 Product Introduction Contents Overview ......... . . 1-3 Checklist .
  • Page 24 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 25: Overview

    Combined with its widescreen format, attractive exterior, and built-in 1.3MP camera module, this panel PC is ideal for interactive applications in retail and educational environments, as an information kiosk, POS, gaming, digital signage, and thin client. KPC-1910 Series User’s Guide Overview...
  • Page 26: Checklist

    Checklist 1. Take out the KPC-1910 series unit from the carton box, check if the unit is properly secure in the plastic bag. 2. Check the contents of the carton box: Panel PC AC power adapter (incl. wall socket cord)
  • Page 27: Features

    The KPC-1910 has a 80GB 2.5” Hard Disk and a CompactFlash Type II slot. Expansion The KPC-1910 has a Mini PCI slot. Power Supply The KPC-1910 is powered by an external 100V-240V AC power adapter (12VDC out). KPC-1910 Series User’s Guide Overview...
  • Page 28: Product Specifications

    AC Adapter 100-240V (12V DC out), 80W Cooling Fanless Operating: 0°C to 40°C, 5%-80%, non-condensing Temperature Storage: -20°C to 60°C, 5%-80%, non-condensing Windows 2000, XP, Linux, XP Embedded Certifications CE, FCC Class A RoHS compliant Table 1-1. KPC-1910 Specifications KPC-1910 Series User’s Guide...
  • Page 29: Mechanical Layout

    DC Power In Reset Parallel Port COM 3 COM 5 LAN Port Mic-in Speaker-out COM 2 COM 4 COM 1 USB Port Line-in PS/2 Keyboard Master On/Off Figure 1-2. KPC-1910 Mechanical Layout - I/O Panel KPC-1910 Series User’s Guide Mechanical Layout...
  • Page 30: Mechanical Dimensions

    Mechanical Dimensions Figure 1-3. KPC-1910 Mechanical Dimensions KPC-1910 Series User’s Guide...
  • Page 31: Assembly

    Chapter 2 Assembly Contents VESA Mounting ........2-3 Desktop Mounting .
  • Page 32 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 33: Vesa Mounting

    The KPC-1910 comes with VESA FDMI 100 standard mounting holes as shown below. Use M4x0.7 metric machine screws with the appropriate length for your mounting bracket. The available internal clearance for the mounting screws is 8mm. Figure 2-1. VESA 100 mounting hole locations on the KPC-1910 KPC-1910 Series User’s Guide VESA Mounting...
  • Page 34: Desktop Mounting

    Secure the bracket to the VESA mounting holes on back of of the KPC-1910 using the 4 M4x0.7 screws provided and a Phillips screwdriver as shown. Figure 2-3. Attach the base to the desktop mounting bracket. KPC-1910 Series User’s Guide...
  • Page 35: Wi-Fi Antenna Installation (Optional)

    To install the antenna for the optional Wi-Fi card on the KPC-1910, remove the cap covering the antenna mount as indicated below and screw the supplied antenna into the mount. Wi-Fi Antenna Antenna Mount Figure 2-4. Installing the antenna for the optional Wi-Fi card on the KPC-1910 KPC-1910 Series User’s Guide Wi-FI Antenna Installation (optional)
  • Page 36 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 37: Getting Started

    Chapter 3 Getting Started Contents Power Connection ........3-3 Operating System and Drivers.
  • Page 38 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 39: Power Connection

    Use the power cord suitable for the power supply in your country. Do not remove or alter the grounding prong on the power cord. In situations where a two-slot receptacle is present, have it replaced with a properly grounded three-prong grounding type receptacle. KPC-1910 Series User’s Guide...
  • Page 40: Operating System And Drivers

    Operating System and Drivers The KPC-1910 Series of Panel PC does not come with operating system and drivers pre-installed. After you have finished assembling your system and connected the appropriate power source, power it up using the ATX Power Switch and install the required operating system.
  • Page 41: Lan Driver Installation

    LAN Driver Installation To install the LAN Driver, extract the contents of LAN_KPC-1910.zip, run the file “e100exp.exe”, accept the license agreement, and save the files to the desired folder. KPC-1910 Series User’s Guide...
  • Page 42 Windows Update, select No. Select Install from a list or specific location and include the folder you saved the installation files to above. Click Finish and repeat the procedure for the other Ethernet Controller. KPC-1910 Series User’s Guide...
  • Page 43: Touch-Screen Driver Installation

    Touch-Screen Driver Installation To install the Touch-Screen driver, extract the contents of Touchscreen_KPC-1910.zip and run Setup.exe from the folder Win2000_XP_4.3.7.3321. Click through the menus, leaving “Install PS/2 interface driver” unchecked, and choose “None” for the calibration check. KPC-1910 Series User’s Guide...
  • Page 44 Click “Yes” when asked to perform the 4 point calibration, then touch and hold down on each flashing X until it stops flashing and a beep is heard. Click “OK” to exit the Touchkit USB Controller. To access the Touch-Screen Utility Help Documentation, to go Start > Programs > Touchkit > Document. KPC-1910 Series User’s Guide...
  • Page 45: Wi-Fi Driver And Utility Installation (Optional)

    Wi-Fi Driver and Utility Installation (optional) To install the optional Wi-Fi card driver, extract the contents of Wi-Fi_KPC-1910.zip and run Setup.exe from the folder GM100(3.2.3.2-Logo)-az(6.01.11). Click through the menus as shown. KPC-1910 Series User’s Guide Operating System and Drivers...
  • Page 46 The Wirless Client Card Configuration Utility installation will begin immediately. Click through the menus as shown. To configure Wi-Fi card, open the Marvell Libertas Client Configuration Manager from the Desktop, System Tray, or Start Menu. 3-10 KPC-1910 Series User’s Guide...
  • Page 47 Chapter 4 Maintenance Contents Maintenance and Prevention ......4-3...
  • Page 48 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 49: Maintenance And Prevention

    Occasionally wipe the system with a soft dry cloth. You should only remove persistent dirt by use of a soft, slightly damp cloth (use only a mild detergent). Make sure the ventilation holes are clear of debris. KPC-1910 Series User’s Guide Maintenance and Prevention...
  • Page 50 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 51 Chapter 5 Interfaces Contents External Connectors ........5-3...
  • Page 52 This page intentionally left blank. KPC-1910 Series User’s Guide...
  • Page 53: Table 5-1. Ps/2 Mouse Connector Pin Definition

    DSR (Data Set Ready) RXD (Receive Data) RTS (Request to Send) TXD (Transmit Data) CTS (Clear to Send) DTR (Data Terminal Ready) RI (Ring Indicator) Ground Table 5-3. COM1 RS-232 Serial Port Connector pin definition KPC-1910 Series User’s Guide External Connectors...
  • Page 54: Table 5-4. Parallel Port Connector Pin Definition

    Receive input (-) Receive input (+) LAN LED Function Yellow LINK / ACTIVE OFF / Green / Orange Speed 10 / Speed 100 / Speed 1000 Table 5-6. Fast Ethernet + 2 USB 2.0 Connector pin definition KPC-1910 Series User’s Guide...
  • Page 55: Table 5-7. Audio Jack Connector Pin Definition

    RS-422 : RX+ RS-485 : RTX+ RS-485 : N/A RS-232 : TXD RS-232 : DTR RS-422 : TX- RS-422 : RX- RS-485 : RTX- RS-485 : N/A Table 5-8. COM2 RS232/422/485 Serial Port Connector pin definition KPC-1910 Series User’s Guide External Connectors...
