- Page 1 OPM Series Open Frame Monitor User’s Guide...
-
Page 2: Table Of Contents
Mechanical Dimensions ............................ 14 Chapter 2 Getting Started ............................16 Setting up your PC ......................... 16 Open Frame Mounting......................... 18 VESA Mounting ..........................21 Panel Mounting..........................22 Chapter 3 OSD Functions............................24 Control Buttons ..........................24 Setting Instruction ..........................25 Function Instruction ........................26 OPM Series User’s Manual... -
Page 3: Figures & Tables
Table 2 OSD Control Button ......................24 Table 3 “Picture” Menu........................26 Table 4 “Image Setting” Menu .......................26 Table 5 “Color” Menu..........................27 Table 6 “Signal Source” Menu .......................27 Table 7 “Audio” Menu...........................28 Table 8 “OSD Menu” Menu ......................28 Table 9 “Information” Menu......................29 OPM Series User’s Manual... -
Page 4: Safety Instructions
Turning off the system power switch does not remove power to components. When Working Inside a Computer Before taking covers off a computer, perform the following steps: Turn off the computer and any peripherals. OPM Series User’s Manual... -
Page 5: Preventing Electrostatic Discharge
ESD workstation or grounded. This will discharge any static electricity that may have built up in your body. When transporting a sensitive component, first place it in an antistatic container or packaging. OPM Series User’s Manual... -
Page 6: Instructions For Lithium Battery
Do not dispose of lithium batteries in domestic waste. Dispose of the battery according to the local regulations dealing with the disposal of these special materials (e.g. to the collecting points for disposal of batteries) OPM Series User’s Manual... -
Page 7: Preface
Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment to an outlet on a circuit different from that to which the OPM Series User’s Manual... -
Page 8: Maintaining Your Computer
However, if a system is located in an unusually humid location, a dehumidifier can be used to maintain the humidity within an acceptable range. Refer to the “Specifications” section of this user’s guide for OPM Series User’s Manual... - Page 9 Surge protectors should be used with all UPS systems, and the UPS system should be Underwriters Laboratories (UL) safety approved. OPM Series User’s Manual...
-
Page 10: Chapter 1 Introduction
Introduction Overview The OPM Series is a collection of widescreen open frame monitors, facilitating multiple windows or convenient panoramic viewing experience. It comes with a variety of display ports, including 1x HDMI, 1x DVI-D and 1x VGA, for various viewing options, and optional 1x USB port for touch functionality. -
Page 11: Product Specifications
Dimensions - D 40.0 mm (1.57") 40.0 mm (1.57") Weight 3700 g (8.16 lb) Environmental Operating Temperature: 0°C ~ 50°C / 32°F ~ 122°F Storage Temperature: -20°C ~ 70°C / -4°F ~ 158°F Humidity: 0% ~ 95% OPM Series User’s Manual... -
Page 12: Table 1 Product Specifications
Chapter 2 Mounting Open Frame Mount VESA Mount Panel Mount Certification CE, FCC Class A Table 1 Product Specifications OPM Series User’s Manual... -
Page 13: System Tour
D-Sub 15 pin VGA connector for display input Line Out The stereo headphone jack is used to connect the system’s audio out signal to amplified speakers or headphones. Line-In The Line-in jack is designed to take input from a higher-powered sound source. OPM Series User’s Manual... -
Page 14: Mechanical Dimensions
Chapter 2 Mechanical Dimensions Dimension: 425.1 x 272.6 x 40.0 mm (W x H x D) Figure 2 Mechanical Dimensions (15. 6" Model) OPM Series User’s Manual... -
Page 15: Figure 3 Mechanical Dimensions (18.5" Model)
Chapter 2 Dimension: 491.6 x 312.5 x 40.0 mm (W x H x D) Figure 3 Mechanical Dimensions (18. 5" Model) OPM Series User’s Manual... -
Page 16: Chapter 2 Getting Started
Setting up your PC Connecting the monitor Connect the HDMI / VGA/ DVI-D cable from your display to the HDMI / VGA/ DVI-D port. VGA DVI-D HDMI Figure 4 VGA / DVI-D / HDMI OPM Series User’s Manual... -
Page 17: Figure 5 Turning On The System
Chapter 3 Turning on the system Connect the power adapter cable to the DC IN of the OPM Series Connect the power cable to the power adapter Connect the power cable to a power outlet Press the power button to turn on the monitor... -
Page 18: Open Frame Mounting
Step 3: Fasten 14 screws from the front side. (4 on top / bottom, 3 on right / left edges respectively) 18.5" Model Step 1: Make a cutout on the fixture, eg. wall. (Cutout: 463.6 x 284.5 mm) OPM Series User’s Manual... -
Page 19: Figure 6 Open Frame Mount (Front Mount) And Cut-Out Hole
Step 2: Align the active area of the panel with the cutout of the fixture from the rear side. Step 3: Fasten 14 screws from the rear side. (4 on top / bottom, 3 on right / left edges respectively) 18.5" Model OPM Series User’s Manual... -
Page 20: Figure 7 Open Frame Mount (Rear Mount) And Cut-Out Hole
Step 2: Align the active area of the panel with the cutout of the fixture from the rear side. Step 3: Fasten 14 screws from the rear side. (4 on top / bottom, 3 on right / left edges respectively) Figure 7 Open frame mount (rear mount) and cut-out hole OPM Series User’s Manual... -
Page 21: Vesa Mounting
Use 4 screws with the appropriate length for your mounting bracket. Figure 8 VESA Mounting Hole Locations NOTE To fasten the metal shelf, your monitor must comply with VESA100 standard. The VESA mounting kit is optional. OPM Series User’s Manual... -
Page 22: Panel Mounting
The required cutout for panel mounting and maximum panel thickness is shown below. Figure 9 Panel Mount Cut-out hole and maximum panel thickness (15.6" Model) Figure 10 Panel Mount Cut-out hole and maximum panel thickness (18.5" Model) OPM Series User’s Manual... -
Page 23: Figure 11 Panel Mounting (15.6" Model)
Secure Chassis to Panel Opening Covers from Bracket into each by tightening the screws Bracket Openings with Bracket Opening Phillips Screwdriver (2 on each top / bottom / side edge) Figure 12 Panel Mounting (18.5" Model) OPM Series User’s Manual... -
Page 24: Chapter 3 Osd Functions
4. To decrease the setting 1. To turn off the OSD menu 2. To move from a sub-menu to the main <Exit> menu and save the changes made in the sub-menu Table 2 OS D Control Button OPM Series User’s Manual... -
Page 25: Setting Instruction
Use <Up> and / or <Down> button to display the next or previous setting option or increase or decrease the setting value and then press <Menu / Enter> or <Exit> button to confirm the selection and save the setting. The frame will disappear when OPM Series User’s Manual... -
Page 26: Function Instruction
Table 4 “Image Setting” Menu Image Setting Auto Adjust Options: N/A H.Position Options: 0 ~ 100 V.Position Options: 0 ~ 100 Clock Options: 0 ~ 100 Phrase Options: 0 ~ 100 OPM Series User’s Manual... -
Page 27: Table 5 "Color" Menu
Color Effect Options: Standard, Game, Movie, Photo, Vivid, User Options: 0 ~ 100 Saturation Options: 0 ~ 100 Table 6 “Signal Source” Menu Signal Source Options: Auto Search, VGA 1, VGA 2, HDMI, DVI OPM Series User’s Manual... -
Page 28: Table 7 "Audio" Menu
OSD H.Position Options: 0 ~ 100 OSD V.Position Options: 0 ~ 100 OSD Transparency Options: 0 ~ 7 Language Options: English, Français (French), Deutsch (German), Español (Spanish), 中文(Chinese) Reset Options: N/A OPM Series User’s Manual... -
Page 29: Table 9 "Information" Menu
Chapter 3 Table 9 “Information” Menu Information Options: N/A OPM Series User’s Manual...
