- Page 1 MoniQ-1500/1700/1900 15"/17"/19" OPS-module-pluggable Multi-touch Bezel-Free Flat Panel Monitor User’s Guide QTM-1500/1700/1900 User’s Manual...
- Page 2 © 2016 Quanmax Inc. All rights reserved. The information in this user’s guide is provided for reference only. Quanmax does not assume any liability arising out of the application or use of the information or products described herein. This user’s guide may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of Quanmax, nor the rights of others.
-
Page 3: Table Of Contents
Content Content Content........................3 Figures ........................4 Tables......................... 5 Safety Instructions...................... 6 Before You Begin..................6 When Working Inside a Computer............... 6 Preventing Electrostatic Discharge.............. 7 Preface........................9 How to Use This Guide................9 Unpacking ....................9 Regulatory Compliance Statements ............9 Warranty Policy .................. -
Page 4: Figures
Figure 1 I/Os ....................17 Figure 2 Control Panel Keypad ..............19 Figure 3 OPS Module Slot ................. 20 Figure 4 Mechanical Dimensions of MoniQ-1500 ........21 Figure 5 Mechanical Dimensions of MoniQ-1700 ........21 Figure 6 Mechanical Dimensions of MoniQ-1900 ........22 Figure 7 OPS Module Slot ................. -
Page 5: Tables
Tables Tables Table 1 QTM-1500/1700/1900 product specifications ........ 16 Table 2 OPS Docking Pin Assignment ............24 Table 3 OSD Control Button............... 32 Table 4 “Picture” Menu................34 Table 5 “Image Setting” Menu ..............34 Table 6 “Color” Menu ................. 34 Table 7 “Signal Source”... -
Page 6: Safety Instructions
Use extreme caution when installing or removing components. Refer to the installation instructions in this user’s guide for precautions and procedures. If you have any questions, please contact Quanmax Post-Sales Technical Support. WARNING High voltages are present inside the chassis when the unit’s power cord is... -
Page 7: Preventing Electrostatic Discharge
Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. Quanmax strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment. - Page 8 Safety Instructions When transporting a sensitive component, first place it in an antistatic container or packaging. Handle all sensitive components at an ESD workstation. If possible, use antistatic floor pads and workbench pads. Handle components and boards with care. Don’t touch the components or contacts on a board.
-
Page 9: Preface
Remove all items from the box. If any items listed on the purchase order are missing, notify Quanmax customer service immediately. Inspect the product for damage. If there is damage, notify Quanmax customer service immediately. Refer to “Warranty Policy” for the return procedure. -
Page 10: Warranty Policy
Quanmax or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of Quanmax or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s guide. -
Page 11: Maintaining Your Computer
Quanmax. Limitation of Liability In no event shall Quanmax be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder. - Page 12 Preface properties as electrical resistance and thermal conductivity. Extreme moisture buildup inside the system can result in electrical shorts, which can cause serious damage to the system. Buildings in which climate is controlled usually maintain an acceptable level of humidity for system equipment. However, if a system is located in an unusually humid location, a dehumidifier can be used to maintain the humidity within an acceptable range.
- Page 13 Preface Uninterruptible Power Supply Uninterruptible power supply (UPS) systems offer the most complete protection against variations on power because they use battery power to keep the server running when AC power is lost. The battery is charged by the AC power while it is available, so when AC power is lost, the battery can provide power to the system for a limited amount of time, depending on the UPS system.
-
Page 14: Chapter 1 Introduction
Introduction Overview MoniQ-1500/1700/1900 is an innovative 15" / 17" / 19" multi-touch bezel-free flat panel monitor with an OPS module slot reserved. Thus, it could be a monitor when you connect it to a PC and could transform into a panel PC when you insert an OPS module into it. -
Page 15: Product Specifications
/ 15.03" x 12.03" x 2.73" / 16.26" x 13.54" x 2.89" / 17.61" x 14.65" x 2.69" Weight MoniQ-1500: 4.6 kg / 10.14 lb MoniQ-1700: 5.8 kg / 12.79 lb MoniQ-1900: 6.4 kg / 14.11 lb Environment Operation Temperature: 0°C ~ 50°C / 32°F ~ 122°F Storage Temperature: -20°C ~ 70°C / -4°F ~ 158°F... -
Page 16: Table 1 Qtm-1500/1700/1900 Product Specifications
Chapter 1 Mounting VESA Mount, Panel Mount Certification CE, FCC Class A Table 1 QTM-1500/1700/1900 product specifications QTM-1500/1700/1900 User’s Manual... -
Page 17: System Tour
Chapter 1 System Tour Refer to the diagrams below to identify the components of the system. I/Os Figure 1 I/Os USB2.0 This USB (Universal Serial Bus) 2.0 port is for touch functionality only. It works only in case of no OPS module inserted into the MoniQ Series. It doesn't work either even though the screen is switched to "Monitor"... - Page 18 Chapter 1 Line-In (Blue) The Line-in jack is designed to take input from a higher-powered sound source. QTM-1500/1700/1900 User’s Manual...
-
Page 19: Figure 2 Control Panel Keypad
Chapter 1 Control Panel Keypad Figure 2 Control Panel Keypad Power Button To turn the monitor on and off Power LED To indicate the power status of the LCD panel Menu / Enter Button To turn on the OSD menu or to confirm the selection Up Button To move to the next item, to display the next setting function, or to increase the setting value... - Page 20 Chapter 1 OPS Module Slot Figure 3 OPS Module Slot OPS Module Slot A slot with a removable cover to insert an OPS module in it QTM-1500/1700/1900 User’s Manual...
-
Page 21: Mechanical Dimensions
Mechanical Dimensions unit: mm 381.7 x 305.6 x 69.3 mm (W x H x D) Figure 4 Mechanical Dimensions of MoniQ-1500 413.0 x 343.9 x 73.3 mm (W x H x D) Figure 5 Mechanical Dimensions of MoniQ-1700 QTM-1500/1700/1900 User’s Manual... -
Page 22: Figure 6 Mechanical Dimensions Of Moniq-1900
Chapter 1 447.3 x 372.1 x 68.3 mm (W x H x D) Figure 6 Mechanical Dimensions of MoniQ-1900 QTM-1500/1700/1900 User’s Manual... -
Page 23: Chapter 2 Getting Started
Chapter 2 Chapter 2 Getting Started Setting up your monitor Inserting an OPS module (Ignore this step if you don't use it as a panel PC.) 1. Unscrew the removable cover from the OPS module slot 2. Insert an OPS module into the OPS module slot 3. -
Page 24: Table 2 Ops Docking Pin Assignment
Chapter 2 UART_TXD DDP_AUXN StdA_SSRXStdA_ AAP-AUXP SSRX+ DDP_HPD StdA_SSTXStdA_ TMDS_CLKTMDS_ SSTX+ CLK+ USB_PN2 TMDS_0- USB_PP2 TMDS_0+ USB_PN1 TMDS_1- USB_PP1 TMDS_1+ USB_PN0 TMDS_2- USB_PP0 TMDS_2+ AZ_LINEOUT_L DVI_DDC_DATA AZ_LINEOUT_R DVI_DDC_CLK DVI_HPD PB_DET PS_ON# +19V PWR_STATUS +19V +19V +19V +19V +19V +19V +19V Table 2 OPS Docking Pin Assignment QTM-1500/1700/1900 User’s Manual... -
Page 25: Figure 8 Hdmi / Dvi-D / Vga
Chapter 2 Connecting the PC or external monitor Connect the HDMI / DVI-D / VGA cable from your PC or external monitor to the HDMI / DVI-D / VGA port. HDMI DVI-D Figure 8 HDMI / DVI-D / VGA Connecting touch panel Connect the USB cable of touch panel to the USB port Figure 9 Connect touch panel QTM-1500/1700/1900 User’s Manual... -
Page 26: Figure 10 Turning On The System
Chapter 2 Turning on the monitor 1. Connect the power adapter cable to the DC jack (DC In) of MoniQ-1500/1700/1900 2. Connect the power cable to the power adapter 3. Connect the power cable to a power outlet 4. Press the power button on the control panel keypad (turning on your PC... -
Page 27: Vesa Mounting
Chapter 2 VESA Mounting The product comes with VESA FDMI 75/100 standard mounting holes as shown below. Use 4 screws with the appropriate length for your mounting bracket. Figure 11 VESA Mounting Hole Locations NOTE To fasten the metal shelf, your monitor must comply with VESA75 or VESA100 standard. -
Page 28: Panel Mounting
The Panel PC can be panel mounted and comes with brackets and screws for this purpose. The required cutout for panel mounting and maximum panel thickness is shown below. Figure 12 Panel Mount Cut-out hole and maximum panel thickness (MoniQ-1500) Figure 13 Panel Mount Cut-out hole and maximum panel thickness (MoniQ-1700) -
Page 29: Figure 14 Panel Mount Cut-Out Hole And Maximum Panel Thickness
Chapter 2 Figure 14 Panel Mount Cut-out hole and maximum panel thickness (MoniQ-1900) QTM-1500/1700/1900 User’s Manual... -
Page 30: Figure 15 Panel Mounting (Moniq-1500)
Bracket into each by tightening the screws Bracket Openings with Bracket Opening Phillips Screwdriver (2 on top edge, 2 on each side) Figure 15 Panel Mounting (MoniQ-1500) Step 1 Step 2 Step 3 Remove 10 Bracket Insert a Panel Mount... -
Page 31: Figure 16 Panel Mounting (Moniq-1700/1900)
Chapter 2 Figure 16 Panel Mounting (MoniQ-1700/1900) QTM-1500/1700/1900 User’s Manual... -
Page 32: Chapter 3 Osd Functions
Chapter 3 Chapter 3 OSD Functions Control Buttons Button Name Image Functions 1. To turn on the OSD menu <Menu / Enter> 2. To confirm the selection 1. To move to the next functional icon 2. To move to the next setting item <Up>... -
Page 33: Setting Instruction
Chapter 3 Setting Instruction Main Menu Cursor Sub-menu Figure 17 OSD Main Menu and Sub-menu There are in total 8 functional icons in the main menu. One of the 8 icons will be displayed in colors to indicate the relationship with the setting items or information in the sub-menu below (as shown in the left figure above). -
Page 34: Function Instruction
Chapter 3 Function Instruction Table 4 “Picture” Menu Picture Back Light Options: 0 ~ 100 Brightness Options: 0 ~ 100 Contrast Options: 0 ~ 100 Sharpness Options: 0 ~ 4 Table 5 “Image Setting” Menu Image Setting Auto Adjust Options: N/A H.Position Options: 0 ~ 100 V.Position... -
Page 35: Table 7 "Signal Source" Menu
Chapter 3 Table 7 “Signal Source” Menu Signal Source Options: Auto Search, VGA 1, VGA 2, HDMI, DVI Table 8 “Audio” Menu Audio Volume Options: 0 ~ 100 Mute Options: Off, On Table 9 “OSD Menu” Menu OSD Menu OSD Timer Options: 5 ~ 60 OSD H.Position Options: 0 ~ 100... -
Page 36: Table 10 "Information" Menu
Chapter 3 Table 10 “Information” Menu Information Options: N/A QTM-1500/1700/1900 User’s Manual... -
Page 37: Chapter 4 Driver Installation
Chapter 4 Chapter 4 Driver Installation You can download the Touch-Screen drivers for the MoniQ-1500/1700/1900 from our website and install as instructed there. QTM-1500/1700/1900 User’s Manual...
