Wolf ICBSRT304 Installation Instructions Manual page 13

I N S T A L L A T I O N I N S T R U C T I O N S
G A S R A T I N G
GSCS20230
SAI GLOBAL
Made in USA
AS4551
Model No: ICBSRT364C
Serial No:
Gas type NG
Test point press. (kPa) 1.0
Injector sizes (mm)
RHF 1.80
RHR 1.80
Grill 1.78
LHF 1.80
LHR 1.35
Total Consumption (MJ/h) 66.0
Electrical compliance: in accordance with
AS/NZS3100 240 V AC, 10 amps, 50 Hz
Imported & Distributed by
Suite 1/151 Barkley Ave. Burnley VIC 3121
t: +61 3 9421 0232
GSCS20230
SAI GLOBAL
AS4551 Made in USA
Model No: ICBSRT486C
Serial No:
Gas type NG
Test point press. (kPa) 1.0
Injector sizes (mm)
RHF 1.80
RHR 1.80
Grill 1.78
LHF/CF/CR 1.80
LHR 1.35
Total Consumption (MJ/h) 94.0
Electrical compliance: in accordance with
AS/NZS3100 240 V AC, 10 amps, 50 Hz
Imported & Distributed by
Suite 1/151 Barkley Ave. Burnley VIC 3121
t: +61 3 9421 0232
GSCS20230
SAI GLOBAL
Made in USA
AS4551
Model No: ICBSRT364G
Serial No:
LPG Gas type
2.75 Test point press. (kPa)
Injector sizes (mm)
1.09 RHF
1.09 RHR
1.09 Griddle
1.09 LHF
0.89 LHR
66.1 Total Consumption (MJ/h)
Electrical compliance: in accordance with
AS/NZS3100 240 V AC, 10 amps, 50 Hz
Imported & Distributed by
Suite 1/151 Barkley Ave. Burnley VIC 3121
t: +61 3 9421 0232
GSCS20230
SAI GLOBAL
AS4551 Made in USA
Model No: ICBSRT486G
Serial No:
LPG Gas type
2.75 Test point press. (kPa)
Injector sizes (mm)
1.09 RHF/CF
1.09 RHR/CR
1.09 Griddle
1.09 LHF
0.89 LHR
94.1 Total Consumption (MJ/h)
Electrical compliance: in accordance with
AS/NZS3100 240 V AC, 10 amps, 50 Hz
Imported & Distributed by
Suite 1/151 Barkley Ave. Burnley VIC 3121
t: +61 3 9421 0232
GSCS20230
SAI GLOBAL
AS4551
Model No: ICBSRT484CG
Serial No:
Gas type
NG LPG
Test point press. (kPa)
1.0 2.75 Injector sizes (mm)
RHF
RHR
1.80 1.09
Grill
1.80 1.09
Griddle
1.70 1.09
LHF
1.80 1.09
LHR
1.35 0.89
Total Consumption (MJ/h)
66.0 66.1
Electrical compliance: in accordance with
AS/NZS3100 240 V AC, 10 amps, 50 Hz
Imported & Distributed by
Suite 1/151 Barkley Ave. Burnley VIC 3121
t: +61 3 9421 0232
GSCS20230
SAI GLOBAL
AS4551
Model No: ICBSRT484F
Serial No:
NG LPG Gas type
1.0 2.75 Test point press. (kPa)
Injector sizes (mm)
RHF
1.80 1.09
1.80 1.09 RHR
1.70 1.09 French Top
1.80 1.09 LHF
LHR
1.35 0.89
94.0 94.1 Total Consumption (MJ/h)
Electrical compliance: in accordance with
AS/NZS3100 240 V AC, 10 amps, 50 Hz
Imported & Distributed by
Suite 1/151 Barkley Ave. Burnley VIC 3121
t: +61 3 9421 0232
Made in USA
NG LPG
1.0 2.75
1.80 1.09
1.80 1.09
1.78 1.09
1.70 1.09
1.80 1.09
1.35 0.89
81.0 81.1
Made in USA
NG LPG
1.0 2.75
1.80 1.09
1.80 1.09
1.80 1.09
1.80 1.09
1.35 0.89
65.0 65.1
