Wolf ICBSRT304 Installation Instructions Manual
Sealed burner rangetops
Hide thumbs
Also See for ICBSRT304:
- Installation instructions manual (74 pages) ,
- Use & care information manual (30 pages) ,
- Design manual (8 pages)
Related Manuals for Wolf ICBSRT304
Summary of Contents for Wolf ICBSRT304
- Page 1 SEALED BURNER RANGETOPS INSTALLATION INSTRUCTIONS Rangetop series ICBSRT Models ICBSRT3 04 ICBSRT364C ICBSRT364G ICBSRT486C ICBSRT486G ICBSRT484CG ICBSRT484F...
- Page 3 E N G L I S H...
- Page 4 Another footnote we would like to identify is IMPORTANT NOTE: This highlights informa- tion that is especially relevant to a problem- free installation. ® WOLF is a registered trademark of Wolf Appliance, Inc.
-
Page 5: What To Do If You Smell Gas
A ventilation range hood must be installed for use with the Wolf sealed burner rangetops. - Page 6 S E A L E D B U R N E R R A N G E TO P W O L F I N S TA L L AT I O N B E F O R E R E Q U I R E M E N T S Y O U S TA R T IMPORTANT NOTE: This installation must Proper installation is your responsibility.
- Page 7 S P E C I F I C AT I O N S Check the location where the rangetop will Wolf sealed burner rangetops come in be installed. The location should be away 762 mm, 914 mm and 1219 mm widths. Illus- from strong draft areas, such as windows, trations on pages 9–...
- Page 8 IMPORTANT NOTE: Caution must be used I S L A N D | P E N I N S U L A I N S TA L L AT I O N S in planning the proper installation of the Wolf Minimum clearances to combustible...
- Page 9 I N S TA L L AT I O N I N S T R U C T I O N S 7 6 2 m m S E A L E D B U R N E R R A N G E T O P 724 mm OVERALL DEPTH O V E R A L L D I M E N S I O N S...
- Page 10 S E A L E D B U R N E R R A N G E TO P W O L F 9 1 4 m m S E A L E D B U R N E R R A N G E T O P 724 mm OVERALL DEPTH O V E R A L L D I M E N S I O N S...
- Page 11 I N S TA L L AT I O N I N S T R U C T I O N S 1 2 1 9 m m S E A L E D B U R N E R R A N G E T O P 724 mm OVERALL DEPTH O V E R A L L D I M E N S I O N S...
-
Page 12: Explosion Hazard
Refer to the installation instructions packaged with the riser. An ISO 7-1 gas inlet thread is provided on all units. Please contact your local Wolf dealer if Position the rangetop on the platform. Gas an ISO 228-1 or other gas inlet thread is supply and electrical connections should be required. - Page 13 I N S T A L L A T I O N I N S T R U C T I O N S G A S R A T I N G GSCS20230 GSCS20230 GSCS20230 SAI GLOBAL Made in USA SAI GLOBAL SAI GLOBAL AS4551...
- Page 14 S E A L E D B U R N E R R A N G E TO P W O L F G A S S U P P LY R E Q U I R E M E N T S G A S L E A K T E S T I N G Never test for a gas leak with a match or Use a brush and liquid detergent to test all gas...
-
Page 15: Electrical Shock Hazard
I N S TA L L AT I O N I N S T R U C T I O N S E L E C T R I C A L R E Q U I R E M E N T S R E C O M M E N D E D G R O U N D M E T H O D ELECTRICAL SHOCK HAZARD —... - Page 16 Check operation If the sealed rangetop still does not work, again, if the burners do not light properly at contact a Wolf authorized service center. Do this point, contact a Wolf authorized service not attempt to repair the sealed rangetop center.
- Page 17 S E R V I C E I F Y O U N E E D For service in your area, contact either your Wolf dealer or visit the Showroom Locator section of our website, wolfappliance.com to find the regional distributor by country.
- Page 18 Wiring Diagrams ICB Sealed Burner Rangetop (ICBSRT) Series ICB Sealed Burner Rangetop (ICBSRT) Series WIRING SCHEMATIC Model: ICBSRT304 - This wiring information is provided for use by qualified service personnel only. - Disconnect appliance from electrical supply before beginning service.
- Page 19 ICB Sealed Burner Rangetop (ICBSRT) Series Wiring Diagrams ICB Sealed Burner Rangetop (ICBSRT) Series WIRING SCHEMATIC Model: ICBSRT484CG - This wiring information is provided for use by qualified service personnel only. - Disconnect appliance from electrical supply before beginning service. - Be sure all grounding devices are connected when service is complete.
- Page 20 Wiring Diagrams ICB Sealed Burner Rangetop (ICBSRT) Series ICB Sealed Burner Rangetop (ICBSRT) Series WIRING SCHEMATIC Model: ICBSRT484F - This wiring information is provided for use by qualified service personnel only. - Disconnect appliance from electrical supply before beginning service. - Be sure all grounding devices are connected when service is complete.
- Page 22 WOLF APPLIANCE, INC. P O BOX 44848 MADISON, WI 53744 USA WOLFAPPLIANCE.COM Australian Distributor of Sub-Zero & Wolf 1/151 Barkly Avenue, Burnley Victoria Australia 3121 Telephone. +61 3 9421 0232 Facsimile. +61 3 9421 0242 www.subzerowolf.com.au M F 0 5 1...
