1:12 SCALE OVAL KIT
INSTRUCTION MANUAL FOR THE
#4016 RC12L3 OVAL KIT
SAVE THIS MANUAL!
Use with current catalog for future,
hassle-free re-ordering of parts.
©1999 Associated Electrics, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RC12 L3 Oval and is the answer not in the manual?

Questions and answers

Summary of Contents for Associated Electrics RC12 L3 Oval

  • Page 1 1:12 SCALE OVAL KIT INSTRUCTION MANUAL FOR THE #4016 RC12L3 OVAL KIT SAVE THIS MANUAL! Use with current catalog for future, hassle-free re-ordering of parts. ©1999 Associated Electrics, Inc.
  • Page 2 #4016 HELPFUL TOOLS (NOT REQUIRED) Allen drivers (straight Allen wrenches with hex shaped handles) such as the following made by Associated: KIT TOOLS SUPPLIED #6957 .050" Allen wrench Allen wrenches, .050", 1/16", 3/32" #6958 1/16" Allen wrench shock tools #6960 3/32"...
  • Page 3 3585 Cadillac Ave. web site: http://www.teamassociated.com Costa Mesa, CA 92626 ©1999 Associated Electrics, Inc. OPEN THE BAGS IN ORDER The assembly is arranged so that you will open and finish that 5 The instructions in each step are ordered in the order you complete them, so read the words AND follow the pictures.
  • Page 4 REMOVE THESE 8413, qty 4 PARTS FOR: 8439, qty 4 4403, qty 2 4187, qty 4 3323, qty 4 caster shim 8-32 x 5/8 kingpin spacer #8 thick washer TEAM: steps 2-3 blue aluminum 6299, qty 6 4448, qty 2 4449, qty 2 4114, qty 2 8425, qty 8...
  • Page 5 REMOVE THESE PARTS FOR: 4335, qty 2 ea 4336, qty 2 6292, qty 2 4526, qty 2 4449, qty 3 6922, qty 1 4334, qty 8 pivot socket, pivot ball 2-56 x 5/16 4-40 x 3/8 T-bar spacer 4-40 locknut 4-40 x 1/2 upper and lower TEAM: steps 1-3...
  • Page 6 REMOVE THESE PARTS FOR: 7673, qty 2 4442, qty 2 4449, qty 5 6919, qty 5 6917, qty 3 4448, qty 5 4441, qty 1 1/16" 4-40 x 5/16 4-40 locknut 4-40 x 5/16 4-40 x 3/8 4-40 ball end dampener brace dampener center post TEAM: steps 4-6...
  • Page 7 REMOVE THESE 3/32" PARTS FOR: TEAM: steps 1-4 4552, qty 1 4553, qty 1 4349, qty 2 6636, qty 1 4551, qty 1 ride height left wheel hub right hand rear wheel/ silicone grease graphite axle dif spacer adjuster, #1 down 6579, qty 2 4460, qty 1 diff drive ring...
  • Page 8 REMOVE THESE PARTS FOR: 4473, qty 3 4473, qty 3 4472, qty 3 4473, qty 3 4473, qty 3 4473, qty 3 TEAM: steps 1-5 large washer black VC foam VC housing shock shaft and piston red O-ring small washer 4473, qty 1 assembly tool 4473, qty 3...
  • Page 9 REMOVE THESE PARTS FOR: .050" 4473, qty 3 6274, qty 6 4474, qty 3 6951, qty 3 8451, qty 3 TEAM: steps 6-8 spring ball cup shock shaft end set screw silver spring adjusting nut disassembly rod Remove the assembly tool and screw on the #6274 ball cup Slide the #8451 spring over the body and up against the where shown.
  • Page 10: Tools Used

    MISC. BAG TOOLS USED REMOVE THESE PARTS FOR: 3/32" 3656, qty 4 6285, qty 6 6299, qty 2 1/8 x 5/16 4-40 x1/4 E-clip TEAM: step 1 unflanged ball bearing steel 3627, qty 2 3673, qty 2 rear wheel/tire front wheel/tire step 1 MOUNTING FRONT TIRES Put a # 3656 unflanged ball bearing into each side of the front wheels.
  • Page 11 step 2 3760 3760 DRILL SERVO SAVER MOUNTING THE SERVO Use your #34 or 3/32" drill bit Secure the servo to the 4145 to carefully drill the two 7337 #8435 blocks with four mounting holes for the #4448 #4145 screws and four 4448 4449 ball ends.
  • Page 12 TOOLS USED REMOVE THESE PARTS FOR: 7320, qty 2 6332, qty 4 9269, qty 2 4535, qty 2 4508, qty 2 large body washer body clip 5-40 x 1/2 front body mount chassis protector TEAM: steps 3-4 step 4 7320 6332 FRONT BODY MOUNTS Place the #4508 chassis protector on the...
  • Page 13 FINAL ADJUSTMENTS MAKE THESE ADJUSTMENTS BEFORE RACING SETTING THE TWEAK 3 To tweak the car, place the tip of a hobby knife We set the “tweak” after everything except the on the center mark as shown. body is installed on the car, including batteries, mo- 4 Lift the front of the car slowly.
  • Page 14: Toe-In And Toe-Out

    CAMBER Excessive negative camber will is a word describing the angle at decrease traction but increase sta- which the tire and wheel rides relative to the ground bility. Positive camber will do the when looked at from the front or back. This is one same.
  • Page 15: Team Associated Online

    FRONT RIDE HEIGHT To obtain your desired ride height, you can place a thick #3323 aluminum spacer under the lower suspension arm. To raise the car, take away spacers, and to lower the car, add spacers. SAVE THIS BOOKLET! SETUP SHEET More than an instruction manual, The next page shows Team Associated’s setup sheet for your car.
