ENDAT-3857 USERS MANUAL
UNICORN COMPUTER CORP.
ENDAT-3857
For ENDAT-3857 PCB ver. A2 or later
Document version: 4.1
Release Date: Jun.18.2015
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENDAT-3857 and is the answer not in the manual?

Questions and answers

Related Manuals for Unicorn Computer ENDAT-3857

Summary of Contents for Unicorn Computer ENDAT-3857

  • Page 1 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. ENDAT-3857 For ENDAT-3857 PCB ver. A2 or later Document version: 4.1 Release Date: Jun.18.2015...

  • Page 2: Copyright Notice

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Copyright Notice The content of this manual has been checked for accuracy. The manufacturer assumes no responsibility for any inaccuracies that may be contained in this manual. The manufacturer reserves the right to make improvements or modification to this document and/or the product at any time without prior notice.
  • Page 3 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Specification: Model ENDAT-3857 Intel® Atom™QC E3845 /2MB cache/1.91GHz / TDP=10W Intel® Atom™ DC E3827 /1MB cache/1.75 GHz / TDP=8W Supporting Intel® Atom™QC J1900 /2.0GHz Up to 2.4GHz /2MB cache / TDP=10W 1 x 204-Pin DDR3 SODIMM socket...
  • Page 4 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Back Panel I/O Model ENDAT-3857 1 x PS2 Keyboard & Mouse Double-decker connector 1 x VGA 1 x Mini DP Display port Back Panel I/O 2 x RJ-45 Connector 1 x USB(2.0) Connector & 1 x USB(3.0) Connector...

  • Page 5: Table Of Contents

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. TABLE OF CONTENTS CHAPTER 1. INTRODUCTION ............6 1-1. FEATURES ....................7 1-2. UNPACKING .................... 8 1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS ........8 1-4. MOTHERBOARD LAYOUT ..............10 CHAPTER 2. SETTING UP THE MOTHERBOARD..... 11 2-1.
  • Page 6 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. APPENDIX A: FLASH MEMORY UTILITY ........33 APPENDIX B: LVDS PIN ASSIGNMENT ........34 APPENDIX C: CH7511B Backlight Control ........ 35 APPENDIX D: LIMITED WARRANTY .......... 36...

  • Page 7: Chapter 1. Introduction

    Chapter 1. Introduction In order to cope with the challenges of the system performance issues and demand of much more visually embedded system in diverse application, ENDAT-3857 system board provides the ultimate solution with Intel® ATOM Bay Trail-I Intel® Atom™ QC E3845, Intel® Atom™ DC E3827 and Intel® Atom™ QC J1900 Processors.

  • Page 8: Features

     +9~24V DC input power Software Support  Drivers for major embedded operating systems: Linux, Windows 8, Windows7, and Windows Embedded. Ordering information: Standard edition: ENDAT-3857-19 (Intel® Atom™ QC E3845) ENDAT-3857-17 (Intel® Atom™ DC E3827) ENDAT-3857-24 (Intel® Atom™ QC J1900)

  • Page 9: Unpacking

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. 1-2. Unpacking The motherboard comes securely packaged in a sturdy cardboard shipping carton. In addition to the User's Manual, the motherboard package includes the following items:  ENDAT-3857 System Board  One SATA HDD Cable ...

  • Page 10: Motherboard Layout

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. 1-4. MOTHERBOARD LAYOUT.

  • Page 11: Chapter 2. Setting Up The Motherboard

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Chapter 2. Setting up the Motherboard 2-1. Connectors / Headers and Jumpers Connectors Overview: Function Connectors Cooling Fan Connector FAN1 DC Power Supply Connector HDD Power Connector HDDPWR1 USB3.0 Port0 Connector USB 2.0 Port1 Connector USB 2.0 Port2...
  • Page 12 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Jumpers Overview: Function Connectors LCD Voltage Select (LCD-PWR) LVDS1 LCD Backlight Voltage Select (VBL) LCD Backlight Active Voltage Select JP3 (BLEN) Clear CMOS JBAT1 COM1/2 Voltage Selector JP5, SATA Port Pin7 Select (for +5V/GND)
  • Page 13 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. J1: PS/2 Keyboard / Mouse Header (2x5 with 2.0mm) Pin No. Signal (KB) Pin No. Signal (MS) KB Data MS Data +5V(DC) +5V(DC) KB_CLK MS_CLK J4: USB Port3 Pin Header (1x5 with 2.54mm) Pin No.
  • Page 14 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. CN1(COM2),CN2(COM1): Serial port Box Headers (2x5 with 2.0mm) Pin No. Function Pin No. Function N.C. Serial Cable D-SUB Type Connector Pin Mapping Pin No. Function Pin No. Function COM2 port (RS-485 2 Wire) Pin No.
  • Page 15 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. JP5: COM Port Voltage Selector (2x6 with 2.0mm) Voltage +12V(DC) R.I. * +5V(DC) JP5 (COM1) JP5 (COM2) 9-10 11-12...
  • Page 16 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. J6: LINE-IN & MIC-IN Header (2 x 4 with 2.0mm) Pin No. Signal (KB) Pin No. Signal (MS) LINE_IN_R MIC_ R JACK_DETECT JACK_DETECT GND_AUD GND_AUD LINE_IN_L MIC_ L Notice: Please connect the jack detect pin to “GND_AUD” if the actual...
  • Page 17 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. SATA Connector : JP6: SATA Port Pin7 Select +5V/GND (1x3 with 2.0mm) SATA Port GND * SATA1...
  • Page 18 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. LVDS1: Single/Dual Channel LVDS(18/24/36/48 bit only, 1.25mm) MB: DF-13A-40DP-1.25V / Map: DF13-40DS-1.25C Pin No. Signal Pin No. Signal BLEN LCD-PWR LCD-PWR Odd 0+ Odd 0- Odd 1+ Odd 1- Odd 2+ Odd 2- Odd 3+...
  • Page 19 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. JP2: LCD Voltage Select (2x3 with 2.0mm) Voltage +3.3V * +12V JP2 (LVDS1) JP4: LCD Backlight Voltage Select (1x3 with 2.0mm) Voltage +5V * +12V JP4 (LVDS1) JP3: LCD Backlight Control Voltage Select (1x3 with 2.0mm) Voltage +3.3V *...
  • Page 20 The Pin2_ LVDS_BKLT_CTRL connect to LCD Panel Backlight Dimming Pin (Sample: AUO G190EG02_V1) CN8: Mini DP Connector Notice: DP dongle converter The ENDAT-3857 supports DP port for digital display output, please note the dongle should connect either passive(recommend) or active type .
  • Page 21 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. J3: Digital I/O Header (2x7 with 2.0mm) Pin No. Function Pin No. Function DIO-OUT0 DIO-IN0 DIO-OUT1 DIO-IN1 DIO GND DIO GND DIO-OUT2 DIO-IN2 DIO-OUT3 DIO-IN3 +3.3V +3.3V SMB1: SM BUS Header (1 x 5 with 2.0mm) Pin No.
  • Page 22 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. J5: Battery connector (1x2 1.25mm) Pin No. Signal CN7: Power input 9KD-014A-L (2.5mm DC JACK) HDDPWR1: DC Output connector (1x4 with 3.96mm) Pin No. Signal +12V...

  • Page 23: Installing Memory

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. 2-2. Installing Memory The DDR3L SO-DIMM socket of ENDAT-3857 supports up to 8GB memory. The speed of DDR3L memory can be DDR3-1333. 2-3. Shared VGA Memory The ENDAT-3857 built-in Intel® Atom™ SoC integrated Gen7 4EUs Gfx graphic engine with DVMT 4.0 up system memory.
  • Page 24 // (bit3=1: minute. =0: second) outportb(0x2e,0xf1); //set WDT Counter outportb(0x2f,tt); //set time out value of WDT void show_ver() unsigned char tmp0; printf("Designed by attila of UNICORN computer corp. \n2014/10/10 release version:1.0a\n"); printf("This program is design for test Watch Dog Timer for ENADT-3857 (NCT6106D).\n");...

  • Page 25: Digital I/O

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. 2-5. Digital I/O Pin define: J2: Digital I/O Header (2x7 with 2.0mm) Pin No. Function Pin No. Function DIO-OUT0 DIO-IN0 DIO-OUT1 DIO-IN1 DIO GND DIO GND DIO-OUT2 DIO-IN2 DIO-OUT3 DIO-IN3 +3.3V +3.3V Digital I/O port address: This function is support by onboard super I/O chip;...
  • Page 26 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Sample code for output (using Turbo C/C++ 3.0): bit No DIO-O3 DIO-O2 DIO-O1 DIO-O0 Sample code for output (using Turbo C/C++ 3.0) outportb(0x2e,0x87); //Unlock register outportb(0x2e,0x87); //Unlock register outportb(0x2e,0x07); //set Logic Device number pointer outportb(0x2f,0x07);...

  • Page 27: Chapter 3. Phoenix Uefibios Setup

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Chapter 3. Phoenix UEFI BIOS SETUP BIOS menu screen Setup Menu The menu bar on top of the screen has the following main items: > Main For changing the basic system configuration. > Advanced For changing the advanced system setting.

  • Page 28: Main Menu

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. All of the above CMOS BIOS items require board knowledge on PC/AT system architecture. Incorrect setup could cause system malfunctions. Navigating Setup Menus and Fields Navigation (moving your cursor around, selecting items, and changing them) is easy in Setup.

  • Page 29: Advanced Menu

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Advanced Menu The following table describes the settings associated with the CPU Configuration menu. Intel SpeedStep technology is Intel’s new power saving technology. Processors can switch between multiple frequencies and voltage points to enable power saving.

  • Page 30: Security Menu

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. The following table describes the settings associated with the South Cluster Configuation menu. PCI Express Configuration PCIe 0 ~ 3 Speed Configuration PCIe Speed Type PCI Express Root Port 0 , 3 , 4...
  • Page 31 Chapter 4. VGA, DP Port and drivers 4-1. Graphic controller Feature The ENDAT-3857 integrated a high performance Intel® Atom™ SoC integrated Gen7 4EUs Gfx engine. Support Microsoft DirectX11, OpenGL3.2, OpenCL1.1, OpenCL2.0 on Windows, and Full HW acceleration, decode: H.264, MPEG2/4, VC-1, WMV9.

  • Page 32: Driver Utility Installation Guide

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. 4-2. Driver Utility Installation Guide When finishing the installation of Microsoft Windows System, please install the relative Intel® chipsets (INF), display and AUDIO driver manually for compliance compatibility of hardware environment. Please contact sales department of UNICORN for Embedded OS user driver (Linux, Windows CE and Windows Embedded).

  • Page 33: Appendix A: Flash Memory Utility

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Appendix A: FLASH MEMORY UTILITY Using this package to update the system BIOS from a disk file to the on board Flash memory. Be aware any improper update of the system BIOS will cause the malfunction of the system.

  • Page 34: Appendix B: Lvds Pin Assignment

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Appendix B: LVDS PIN ASSIGNMENT LVDS1: Single/Dual Channel LVDS(18/24/36/48 bit only, 1.25mm) MB: DF-13A-40DP-1.25V / Map: DF13-40DS-1.25C Pin No. Signal Pin No. Signal BLEN LCD-PWR LCD-PWR Odd 0+ Odd 0- Odd 1+ Odd 1-...

  • Page 35: Appendix C: Ch7511B Backlight Control

    ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. Appendix C: CH7511B Backlight Control CN3:LCD Backlight Control Connector (Map: PHR-6) Pin No. Signal LVDS_BKLT_CTRL PWRDN BLUP BLDN Notice: PWRDN for Backlight On/Off Control: When receiving active low pulse (0V) from this pin3 (PWRDN).

  • Page 36: Appendix D: Limited Warranty

    The limited warranty applies to normal proper usage of the hardware and does not cover products that have been modified or subjected to unusual electrical or physical stress. Unicorn Computer Corp is not liable to repair or replace defective goods caused by improper using or use of unauthorized parts. The following situations will be charged: 1.
  • Page 37 ENDAT-3857 USERS MANUAL UNICORN COMPUTER CORP. RMA SERVICE REQUEST FORM When requesting RMA service, please fill out this “RMA Service Request Form”. This form needs to be shipped with your returns. Service cannot begin until we have this information. RMA NO.:...
