ENDAT-LX301 USERS MANUAL
ENDAT-LX301 USERS MANUAL
UNICORN COMPUTER CORP.
UNICORN COMPUTER CORP.
ENDAT-LX301

Copyright Notice

The content of this manual has been checked for accuracy. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
manual. The manufacturer reserves the right to make improvements or
modification to this document and/or the product at any time without prior
notice. No part of this document may be reproduced, transmitted, photocopied or
User's Manual
translated into any language, in any form or by any means, electronic, mechanical,
magnetic, optical or chemical, without the prior written permission of the
manufacturer.
Rev. A3
AMD is registered trademark of AMD Technology Incorporation
GEODE LX is registered trademark of AMD Technology Incorporation
Realtek is registered trademark of Realtek Technologies Inc.
Multiscan is a trademark of Sony Corp of America
IBM, EGA, VGA, PC/XT, PC/AT, OS/2 and PS/2 are registered trademarks of
International Business Machines Corporation
Intel is a registered trademark of Intel Corporation
VIA is registered trademark of VIA Technology Incorporation
Plug and Play is registered trademarks of Intel Corporation
Microsoft, Windows and MS-DOS are trademarks of Microsoft Corporation
Award is a trademark of Phoenix Software Inc.
PCI is a registered trademark of PCI Special Interest Group
Other product names mentioned herein are used for identification purpose only and
may be trademarks and/or registered trademarks of their respective companies.
Installation Notice
The manufacturer recommends using a grounded plug to ensure proper
motherboard operation. Care should be used in proper conjunction with a grounded
power receptacle to avoid possible electrical shock. All integrated circuits on this
motherboard are sensitive to static electricity. To avoid damaging components from
electrostatic discharge, please do not remove the board from the anti-static packing
before discharging any static electricity to your body, by wearing a wrist-grounding
strap. The manufacturer is not responsible for any damage to the motherboard due
For ENDAT-LX301 PCB ver. A3 or later
to improper operation.
10/29/2008
- 1 -
- 2 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENDAT-LX301 and is the answer not in the manual?

Questions and answers

Related Manuals for Unicorn Computer ENDAT-LX301

Summary of Contents for Unicorn Computer ENDAT-LX301

  • Page 1: Copyright Notice

    The manufacturer is not responsible for any damage to the motherboard due For ENDAT-LX301 PCB ver. A3 or later to improper operation. 10/29/2008...
  • Page 2 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. Specification: TABLE OF CONTENTS Model ENDAT-LX301 CHAPTER 1. INTRODUCTION............6 Form Factor Mini-ITX 170 mm x 170 mm (6.69”x6.69”) with 6 layers PCB System Chipset AMD GEODE LX + CS5536 1-1.

  • Page 3: Chapter 1. Introduction

    4-3. DRIVER UTILITY INSTALLATION GUIDE..........37 diminutive embedded system in diverse application, ENDAT-LX301 system board provides the ultimate solution by integrating with AMD GEODE LX technology CPU. ENDAT-LX301 CHPATER 5. LAN ADAPTER ............38 not only provide the ideal solution for Hi-End POS system, but also can be adapted in various applications such as kiosks, networking systems, control terminals and other embedded 5-1.

  • Page 4: Features

    Software Support Drivers for major embedded operating systems: Linux, Windows XP, Windows XP embedded and Windows CE 5.0/6.0. Ordering information: ENDAT-LX301: Standard version. (ATX and DC+12V) ENDAT-LX301W: Support Wide range.(DC+5V~+27V) ENDAT-LX301A: Support ATX Power only. - 7 - - 8 -...

  • Page 5: Motherboard Layout

    ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. 1-4. MOTHERBOARD LAYOUT. Chapter 2. Setting up the Motherboard 2-1. Jumpers and Connectors Connectors Overview: Function Jumpers/Connectors ATX Power Connector ATX1 DC Input connector DC-IN1 DC Output connector...
  • Page 6 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. Jumpers Overview: Part 1: Onboard Jumpers Function Jumpers/Connectors JBAT1: CMOS Data Clear (1x3 with 2.0mm) JBAT1 Clear CMOS Pin 1-2 * Normal COM Port Voltage Selector Close for clear CMOS...
  • Page 7 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. JP7: Box Header for Case Panel (1x17 with 2.54mm) Part 2: Onboard Connectors and Headers VGABH1: CRT Box Header Connector (2x8 with 2.0mm) Pin No. Function Pin No. Description Pin No. Description...
  • Page 8 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. IDELIM : Slim IDE Connector (Shared IDE1, 2x22 with 2.0mm) LVDS1: LVDS LCD Pin Header (2x8 with 2.54mm) Pin No. Description Pin No. Description Pin No. Description Pin No.
  • Page 9 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. FDD1: FDD Box Header (2x17 with 2.54mm) JUSB1, JUSB2: Pin Header for USB port (2x5 with 2.54mm) Pin No. Function Pin No. Function Pin No. Description Pin No.

  • Page 10: Installing Memory

    2-2. Installing Memory +TXD –RXD The ENDAT-LX301 CPU board offers one 184pin DDR DIMM socket supporting up to 1GB of memory. The speed of DDR memory can be DDR200, DDR266, DDR333 or DDR400. D-SUB Type Connector for COM2 port (RS-485 2 Wire) 2-3.

  • Page 11: Irqs Mapping

    Occupied Coprocessor Free When IDE device absent unsigned char tmp0; printf("Designed by ROBERT LIOU of UNICORN computer corp. \n2008/05/12 release Occupied Reserved version:1.0a\n"); printf("This program is design for test Watch Dog Timer for ENADT-LX301(W83627).\n"); 2-5. Watch Dog Timer Watchdog Timer (WDT) is a special design for system monitoring to secure the system work normally.

  • Page 12: Digital I/O

    ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. 2-6. Digital I/O Sample code for output (using Turbo C/C++ 3.0): Pin definition: GPIO1: DIGITAL I/O Pin Header (2x9 with 2.0mm) outportb(0x2e,0x87); //Unlock register outportb(0x2e,0x87); //Unlock register Pin No.

  • Page 13: Chapter 3. Award Bios Setup

    ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. 3-1. Standard CMOS Features Chapter 3. AWARD BIOS SETUP The Standard Setup is used for the basic hardware system configuration. The main function is for Data/Time and Hard Disk Drive settings.

  • Page 14: Advanced Bios Features

    ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. Item Optimized defaults 3-2. Advanced BIOS Features XOR BA1 Disable This section allows you configuring your system for basic operation. You have the XOR MB0 Disable opportunity to select the system’s default speed, boot-up priority, keyboard XOR Bit Select operation and security.

  • Page 15: Integrated Peripherals

    ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. ˙HSYNC Polarity UART Mode Select Normal RxD , TxD Active Hi,Lo This field is used to select the polarity of HSYNC for LCD. Default is “Normal IR Transmission Enable Low”.

  • Page 16: Power Management Setup

    ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. 3-5. Power Management Setup Item Optimized defaults IRQ12 (PS/2 Mouse) The Power Management Setup allows users configuring the system to save energy IRQ13 (Coprocessor) in a most effective way while operating in a manner consistent with their own style IRQ14 (Hard Disk) of computer use.

  • Page 17: Pc Health Status

    4-1. Graphic controller Feature CPU Warning Temperature Disable Current System Temp The ENDAT-LX301 integrated a high performance with low power consumption 2D Current CPU Temperature graphics engine. The graphics controller is full compliance and compatibility with Fan1 Speed IBM® VGA and VESA™ extended VGA.
  • Page 18 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. ˙Refresh Rate 4-2. LCD Flat Panel This field is used to select the refresh rate (VSYNC frequency) to LCD panel. Default is “60 Hz”. <Choice: 60/65/70/72/75/85> Flat Panel Interface The on-board graphics controller also supports industry standard LVDS TFT LCD: ˙HSYNC Polarity...
  • Page 19 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. Chapter 5. LAN Adapter 4-3. Driver Utility Installation Guide When finishing the installation of Windows XP, please install the relative AMD display and AUDIO driver manually for compliance compatibility of hardware environment.
  • Page 20 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. 5-2. UTP Cable / RJ-45 Jack Definition 5-3. Connecting 100Base-TX Fast Ethernet Network Straight through twisted pair cable is typically used to connect a hub to a server or To connect the adapter to 100Base-TX Fast Ethernet Network, you need a twisted-pair workstation.
  • Page 21 At the DOS prompt, type A:>AWDFLASH and press <Enter> physical stress. Unicorn Computer Corp is not liable to repair or replace defective goods caused by improper using or use of unauthorized parts. The following AwardBIOS FLASH Utility V8.24G...
  • Page 22 ENDAT-LX301 USERS MANUAL ENDAT-LX301 USERS MANUAL UNICORN COMPUTER CORP. UNICORN COMPUTER CORP. RMA SERVICE REQUEST FORM Issue Code of defect. When requesting RMA service, please fill out this “RMA Service Request Form”. 01 Second Times R.M.A. 11 Memory Socket Bad This form needs to be shipped with your returns.
