ENDAT-3701/3702
ENDAT-3902
All-In-One motherboard
User's Manual
Rev. 5x
For 3701 PCB ver.3A or later
For 3702 PCB ver.4A or later
For 3902 PCB ver.4A or later
6/11/2004
II
The ENDAT-3701/3702/3902 All-In-One motherboard
Copyright Notice
The content of this manual has been checked for accuracy. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
manual. The manufacturer reserves the right to make improvements or
modification to the this document and/or the product at any time without prior
notice. No part of this document may be reproduced, transmitted, photocopied or
translated into any language, in any form or by any means, electronic, mechanical,
magnetic, optical or chemical, without the prior written permission of the
manufacturer.
VIA is registered trademark of VIA Technology Incorporation
VT82C868A may only be used to identify products of VIA Technology
Realtek is registered trademark of Realtek Technologies Inc.
Multiscan is a trademark of Sony Corp of America
IBM, EGA, VGA, PC/XT, PC/AT, OS/2 and PS/2 are registered trademarks of
International Business Machines Corporation
Intel is a registered trademark of Intel Corporation
Plug and Play is registered trademarks of Intel Corporation
Microsoft, Windows and MS-DOS are trademarks of Microsoft Corporation
Award is a trademark of Award Software Inc.
PCI is a registered trademark of PCI Special Interest Group
Other product names mentioned herein are used for identification purpose only
and may be trademarks and/or registered trademarks of their respective
companies.
Installation Notice
The manufacturer recommends using a grounded plug to ensure proper
motherboard operation. Care should be used in proper conjunction with a
grounded power receptacle to avoid possible electrical shock. All integrated
circuits on this motherboard are sensitive to static electricity. To avoid damaging
components from electrostatic discharge, please do not remove the board from the
anti-static packing before discharging any static electricity to your body, by
wearing a wrist-grounding strap. The manufacturer is not responsible for any
damage to the motherboard due to improper operation.
Advertisement
Table of Contents
Related Manuals for Unicorn Computer ENDAT-3701
Summary of Contents for Unicorn Computer ENDAT-3701
-
Page 1: Copyright Notice
The ENDAT-3701/3702/3902 All-In-One motherboard ENDAT-3701/3702 Copyright Notice The content of this manual has been checked for accuracy. The manufacturer assumes no responsibility for any inaccuracies that may be contained in this manual. The manufacturer reserves the right to make improvements or... - Page 2 This manual covers three different layout model of PIII embedded motherboard. The respective board layout outlines are shown on Chapter 1-4/1-5/1-6. Please refer to the following description to make sure which model you have before using. ENDAT-3701 ENDAT-3702 ENDAT-3902 MODEL /3701-030 ®...
-
Page 3: Table Of Contents
5-5. 10M BASE/100MBASE INSTALLATION NOTICE......47 CHAPTER 2. SETTING UP THE MOTHERBOARD....7 5-6. REMOTE BOOT ROM INSTALLATION GUIDE ....... 48 2-1. JUMPERS AND CONNECTORS (ENDAT-3701) ......... 7 5-7. LED INDICATORS ................49 2-2. JUMPERS AND CONNECTORS (ENDAT-3702) ......13 5-8. SETUP PROGRAM ................49 2-3. -
Page 4: Chapter 1. Introduction
Digital TMDS adapter Kit for ENDAT-3702/3902 :Model No. UC-TT18xx • High performance SMA North Bridge: Integrated VIA Apollo Pro133 and S3 TTL Panel adapter Kit for ENDAT-3701: Model No. UC-LT1815 Savage4 in a single chip, provides superior performance between the CPU, DRAM, UC-LR1815 AGP bus, and PCI bus with pipelined, burst and concurrent operation. -
Page 5: Unpacking
1-4. Motherboard Layout (ENDAT-3701) The motherboard comes securely packaged in a sturdy cardboard shipping carton. In addition to the User's Manual, the motherboard package includes the following items: • ENDAT-3701/ 3702/ 3902 All-In-One Motherboard • HDC/FDC Cables • TV-Out adapter / cable (Optional) •... -
Page 6: Motherboard Layout (Endat-3702)
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard 1-5. Motherboard Layout (ENDAT-3702) 1-6. Motherboard Layout (ENDAT-3902) -
Page 7: Chapter 2. Setting Up The Motherboard
FDD Connector FDD1 CPU. IDE 1 (Primary IDE) IDE1 IDE 2 (Secondary IDE) IDE2 2-1. Jumpers and Connectors (ENDAT-3701) Header for Case Panel IDE 1 LED J2 Pin 1, Pin 2 Jumpers/Connectors Overview: IDE 2 LED J2 Pin 3, Pin 4... - Page 8 User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard Box Header: COM1(CN7)/COM2(CN9)/COM3(CN13)/COM4(CN14) System Clock Setting: JP18 Pin No. Description Pin No. Description JP18 (1-2) JP18 (3-4) CPU BUS CLOCK PCI CLOCK OPEN OPEN 133 MHz 33.3 MHz OPEN CLOSE 100 MHz 33.3 MHz...
- Page 9 User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard FAN1, FAN2: CPU / 2nd Cooling Fan Connector LCD_CON1 / LCD_CON2: LCD PANEL OUTPUT Connector. Pin No. Function LCD_CON1: LCD Control signal & Data Bit 0 – Bit23 Pin 1 Sensor Pin. Pin No. Description Pin No.
-
Page 10: Jumpers And Connectors (Endat-3702)
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard Header for Case Panel 2-2. Jumpers and Connectors (ENDAT-3702) IDE 1 LED J2 Pin 1, Pin 2 Jumpers/Connectors Overview: IDE 2 LED J2 Pin 3, Pin 4 External Speaker J2 Pin 5, Pin 8... - Page 11 User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard JP7: CMOS Data Clear: JP10, JP12, JP6: RS232 / 485 Selector for COM2 Pin 1-2 * Normal TYPE JP10 JP12 Pin 2-3 Clear CMOS Data RS-232 * Open 1-2, 4-5, 7-8, 10-11 RS-485 Close...
-
Page 12: Jumpers And Connectors (Endat-3902)
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard CN6: Audio Output Port connector via AV Card Kit 2-3. Jumpers and Connectors (ENDAT-3902) (Optional) The AV Card Kit Adapter supports Sound and Game Port. Please close pin13-14 to disable onboard Audio features if the AV Card Kit Jumpers/Connectors Overview (ENDAT-3902): is not inserted onto the CN6 connector. - Page 13 User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard Header for Case Panel JP10: CMOS Data Clear: IDE 1 LED J2 Pin 1, Pin 2 Pin 1-2 * Normal IDE 2 LED J2 Pin 3, Pin 4 Pin 2-3 Clear CMOS Data External Speaker...
- Page 14 User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard JP13: Voltage selector for COM3, COM4 CN6: Audio Output Port connector via AV Card Kit (Optional) COM3 COM4 Description The AV Card Kit Adapter supports Sound, Game Port. Please close JP13 Close 1-2 Close 7-8...
-
Page 15: Installing Memory
(MSD.EXE) utility included in the Windows directory can be used to see their map. There are two different riser cards that can be fitted to ENDAT-3701/3702/3902 Make sure that there are no two devices using the same IRQ in the system. -
Page 16: Assigning Dma Channels For Isa Cards
User’s Manual An IRQ number is automatically assigned to PCI expansion cards after those used by Legacy and PnP ISA cards. In the PCI Bus design, the BIOS is automatically assigned an IRQ to a PCI slot that has a card in it which requires an IRQ. To install a PCI card, you need to set the correct "ADSEL"... -
Page 17: Chapter 3. Award Bios Setup
The ENDAT-3701/3702/3902 All-In-One motherboard 3-2. Description of the BIOS Setup Option Chapter 3. AWARD BIOS SETUP Please make clear the means of those option parameters. Improper settings will cause the system to hang up or perform poorly. Most items are clearly understood from the screen prompt or “Help”... -
Page 18: Advanced Chipset Features
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard AGP Aperture Size 3-4. Details of the Advanced Chipset Features Setup Selecting the size of Accelerated Graphics Port (AGP) aperture. The Aperture is a Advanced Chipset Feature portion of the PCI memory address range dedicated for graphics memory address space. -
Page 19: Integrated Peripherals
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard IDE Primary/Secondary Master/Slave PIO 3-5. Integrated Peripherals The four IDE IPO (Programmed Input/Output) fields allow setting a PIO mode (0-4) for each of the four IDE devices which the onboard IDE interface supports. Integrated Peripherals Modes 0 through 4 provide successively increased performance. -
Page 20: Power Management Setup
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard 3-6. Power Management Setup PM Control by APM When enabled, an Advanced Power Management device will be activated to Power Management Setup enhance the Maximum Power saving mode and to stop the CPU internal clock. If... -
Page 21: Pnp/Pci Configurations Setup
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard device and the system configuration has caused a serious conflict that the operating 3-7. PnP/PCI Configurations Setup system cannot boot, then, select enabled to reset Extended System Configuration Data (ESCD) when exit setup. This section describes the configuration of the PCI bus system. PCI is a system that allows I/O device to operate at speeds nearing the speed of the CPU itself, when communicating with its own special components. -
Page 22: Agp-Bus Vga Feature
• Support 3D rendering with specula lighting and disuse shading and MPEG-2 video textures features. Note: The standard for default BIOS setting for model 4-2-2. The solution for ENDAT-3701 ENDAT-3702/3902: Support CRT/TMDS The ENADT-3701 built-in C&T 69000 Chipset supports High Performance ENDAT-3701: Support CRT/LCD Flat Panel / CRT HiQVideo with Integrated 2MB Memory. -
Page 23: Pci Bus Audio Adapter Feature
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard Single-Drive (SS) and Dual-Panel, Dual Drive (DD), standard and 4-3. PCI Bus Audio Adapter Features high-resolution, passive STN and active matrix TFT/MIM LCD, and EL The Chipset built-in SoundBlaster Pro Hardware and Direct Sound Ready AC97’... -
Page 24: Diskonchip Feature
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard 4-4. DiskOnChip Feature 4-5. Driver Utility Installation Guide When finishing the installation of Windows platform (95/98/2000/NT), On board reserved is a 32-pin Socket for DiskOnChip 2000, it is a unique data please install the relative VIA driver (4in1) utilities for compliance storage solution to offer a better, faster and more cost effective Flash Disk for compatibility of hardware environment. - Page 25 User’s Manual The Screen will appear VIA 4in1 driver setup screen, please press “NEXT” to continue. Please follow the steps instructed by each screen for the installation of the VIA 4in1 driver. Restart the system after the completion of the installation. After installing the VIA 4in1 driver, please select VGA driver for install.
-
Page 26: Features
100Base-TX Fast Ethernet or 10Base-T Ethernet network, and automatically senses the connection type. This model ENDAT-3701 not only provides a standard LAN solution of Realtek, RJ-45 Connector Pin Assignments but also provides the optional choice of Intel LAN solution for specific use. -
Page 27: Connecting 100Base-Tx Fast Ethernet Network
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard 1. Solid copper 5-3. Connecting 100Base-TX Fast Ethernet Network 2. Nominal capacitance: less than 16pF/ft 3. Nominal impedance: 100 ohms The system board provides an RJ-45 port for connection to 100Base-TX Fast Ethernet or 10Base-T Ethernet Network with a single connection over unshielded 4. -
Page 28: Led Indicators
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard 5-7. LED Indicators Note: Before running the setup program, make sure the adapter’s driver is not loaded, otherwise unpredictable results may arise! The system board comes with two LED indicators on the edge of the motherboard that indicates the network system status. -
Page 29: Lan Driver Installation Procedure
User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard • Diagnostics On Network: To run this test on the network, you will need 5-9. The Realtek 8139 LAN Driver Installation Procedure: another computer set up as a Responder to receive packets from the adapter Please note: The LAN Driver installation has to be done after completing Win being tested and echo them back to the adapter. -
Page 30: Appendix A: Flash Memory Utility
Appendix A: FLASH Memory Utility Using this utility to update the system BIOS from a disk file to the on board Flash memory. Be aware the improper change of the system BIOS will cause the system to malfunction. Using utility as follows: 1. -
Page 31: Appendix B: Connector Pin Assignment
The ENDAT-3701/3702/3902 All-In-One motherboard Printer (LPT1/LPT2) Port Appendix B: Connector Pin Assignment Pin No. Description Pin No. Description STB# ACK# BUSY PS/2 Keyboard / Mouse Pin Header Connector (CN4) Pin No. PS/2 Keyboard Pin No PS/2 Mouse SLCT K/B_Data Mouse_Data... - Page 32 User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard –PCIRST2 USBDR3– FDD Connector +12V +12V Pin No. Description Pin No. Description 1,3,5,7 DSA# 9,11,13 MOB# USB PORT (JUSB1;JUSB2) 15,17,19 Pin No. Description 21,23,25 STEP# USB VCC 27,29,31 USB DATA–(0,1/2,3) USB DATA+(0,1/2,3) RWC# TRAK0...
- Page 33 User’s Manual The ENDAT-3701/3702/3902 All-In-One motherboard Expansion Slot to PCI/ISA Pin Assignment Power – LED (J2) Pin No. Description A Description B Description E Description F Pin No. Description –IOCHK Power LED RSTDRV Power LED –PCINT2 –PCINT4 IRQ9 –PCINT3 –PCINT1 IR Connector (J1) –5V...
- Page 34 User’s Manual Pin No. Description C Description D Description G Description H –SBHE –MEMCS16 –SERR LA23 –IOSC16 AD15 LA22 IRQ10 –CBE1 AD14 LA21 IRQ11 AD12 LA20 IRQ12 LA19 IRQ13 LA18 IRQ14 LA17 –DACK0 AD13 AD10 –MEMR DRQ0 AD11 –MEMW –DACK5 DRQ5 –CBE0 –DACK6...
-
Page 35: Appendix C: Limited Warranty
Company: Person to Contact: the hardware and does not cover products that have been modified or subjected to unusual electrical or physical stress. Unicorn Computer Corp Phone No: Purchase Date : is not liable to repair or replace defective goods caused by improper using Fax No. - Page 36 User’s Manual Issue Code of defect. Second Times R.M.A. 11 Memory Socket Bad No Screen (No Boot) 12 Hang Up Hardware VGA (Display) Fail 13 Hang Up Software CMOS Data Lost 14 PCB Problem FDC Fail 15 CPU Socket Bad HDC Fail 16 LAN Fail Bad Slot...
