Page 1: User Manual
The ENDAT-7100M System Board ENDAT-7100M User Manual PCB version: A5 or later May.16.2013... -
Page 2: Copyright Notice
User Manual Copyright Notice The content of this manual has been checked for accuracy. The manufacturer assumes no responsibility for any inaccuracies that may be contained in this manual. The manufacturer reserves the right to make improvements or modification to this document and/or the product at any time without prior notice. -
Page 3: System Chipset
The ENDAT-7100M System Board Specification: Model ENDAT-7100M Form Factor Mini-ITX 170 mm x 170 mm (6.69”x6.69”) with 6 layers PCB System Chipset VIA CN700(NB/2.5W)+ VIA VT8237R Plus (SB/1.8W) VIA Eden ULV 500MHz (1W) CPU Support VIA Eden 1.0GHz (5W) VIA C7-D 1.5GHz (20W) -
Page 4: Table Of Contents
User Manual TABLE OF CONTENTS CHAPTER 1. INTRODUCTION ............1 1-1. FEATURES ....................2 1-2. UNPACKING .................... 3 1-3. ELECTROSTATIC DISCHARGE PRECAUTIONS ........3 1-4. MOTHERBOARD LAYOUT ..............4 CHAPTER 2. SETTING UP THE MOTHERBOARD....... 5 2-1. JUMPERS AND CONNECTORS.............. 5 2-2. - Page 5 The ENDAT-7100M System Board CHPATER 4. VGA, LCD, FEATURE..........30 4-1. VGA FEATURE..................30 4-2. LVDS PANEL FEATURE................. 31 4-3. DRIVER UTILITY INSTALLATION GUIDE..........32 CHPATER 5. LAN ADAPTER ............34 5-1. FEATURES .................... 34 5-2. UTP CABLE/RJ-45 JACK DEFINITION..........35 5-3.
-
Page 7: Chapter 1. Introduction
The user-friendly V-RAID software interface enables easy disk array configuration and management. ENDAT-7100M supports IEEE 802.3 compliant 10 / 100 Mbps PCI bus master Ethernet MAC with standard MII interface to external PHYceiver. The ideal solution of ENDAT-7100M... -
Page 8: Features
User Manual 1-1. Features Basic Feature: Board format: Mini-ITX (170mm x 170 mm) Supports 400/533 MHz FSB by VIA C7® Digital I/O: 8 bits input and 8 bits output (5V) Supports DDRII 400/533 MHz SDRAM up to 1GB ... -
Page 9: Unpacking
The ENDAT-7100M System Board 1-2. Unpacking The motherboard comes securely packaged in a sturdy cardboard shipping carton. In addition to the User's Manual, the motherboard package includes the following items: ENDAT-7100M System Board SATA / IO Cables / DC Power Cable CDROM Driver includes: Drivers for Windows 2000, XP and AMI/AWARD FLASH ROM utilities. -
Page 10: Motherboard Layout
User Manual 1-4. Motherboard Layout... -
Page 11: Chapter 2. Setting Up The Motherboard
The ENDAT-7100M System Board Chapter 2. Setting up the Motherboard 2-1. Jumpers and Connectors Jumpers/Connectors Overview: Function Jumpers/Connectors Power Supply Connector 2 pin wafer Output Power for Hard Disk HDDPWR Cooling Fan Connector FAN1, FAN2 Buzzer BUZZ1 Battery BAT1 Clear CMOS... - Page 12 User Manual Function Jumpers/Connectors RS232 / 422/ 485 Selector for COM2 JP3 & JP4 SMBus PCI SLOT PCI1 DIGITAL I/O Pin Header LPT1, LPT2 LPT1, LPT2 SATA 1, SATA 2 SATA1, SATA2 40-Pin IDE Connector IDE1 44-Pin IDE Connector IDE2 LINE OUT / CD IN Pin Header MIC IN / LINE IN Pin Header LINE OUT Connector...
- Page 13 The ENDAT-7100M System Board JP10: Pin Header for Case Panel (2.54mm) Pin No. Function 1(-), 2(+) HDD active LED External Speaker Buzzer On/Off Hardware Reset Switch 9,10 ATX Power On/Off 11(-),12(+) Power LED 13,14 Close: Enable WDT function JP3, JP4: RS232 / 422 / 485 Selector for COM2 (2.0mm)
- Page 14 User Manual JP7: DIGITAL I/O Pin Header Connector (2.0mm) Pin No. Function Pin No. Function DIO-O0 DIO-I0 DIO-O1 DIO-I1 DIO-O2 DIO-I2 DIO-O3 DIO-I3 DIO-O4 DIO-I4 DIO-O5 DIO-I5 DIO-O6 DIO-I6 DIO-O7 DIO-I7 +3.3V +3.3V JP8: LINE OUT & CD IN Pin Header Connector (2.54mm) Pin No.
- Page 15 The ENDAT-7100M System Board CN5: CRT Box Header Connector (2.0mm) Pin No. Description Pin No. Description n/c / +5V GREEN BLUE DDC DAT H-Sync V-Sync DDC CLK CN8: Box Header Type Connector for COM4 port (RS-232) (2.54mm) Pin No. Function Pin No.
- Page 16 User Manual D-SUB Type Connector for COM2 port (RS-485 2 Wire) Pin No. Function Pin No. Function Data – Data + SPDIF: SPDIF Pin Header Connector (2.0mm) Pin No. Function SPDIFOUT SPDIFIN JP5: SM Bus Pin Header Connector (2.0mm) Pin No. Function SMBCK SMBDT...
- Page 17 The ENDAT-7100M System Board J1: Power Supply Connector 2 pin wafer (3.96mm) Pin No. Function Pin No. Function +12V HDDPWR: Output Power for Hard Disk (3.96mm) Pin No. Function Pin No. Function +5V(Red) +12V(Yellow) IDE1: IDE1 Connector (40Pins) Pin No.
- Page 18 User Manual LPT2: Printer (LPT2) Port Box Header (2.0mm) Pin No. Description Pin No. Description STB# ACK# BUSY SLCT AFD# ERR# INIT# SLIN# 18-25 IDE2: Slim IDE2 Connector (44Pins2.0mm) Pin No. Description Pin No. Description IDE Reset# IDE data7 IDE data8 IDE data6 IDE data9 IDE data5...
- Page 19 The ENDAT-7100M System Board LVDS1: (1.25mm) Dual LVDS Channel Pin No. Signal Pin No. Signal VBL (+12V) VBL (+12V) DISP.ON/OFF LCD Power LCD Power TxO0+ TxO0- TxO1+ TxO1- TxO2+ TxO2- TxO3+ TxO3- TxOC+ TxOC- TxE0+ TxE0- TxE1+ TxE1- TxE2+ TxE2-...
-
Page 20: Installing Memory
User Manual 2-2. Installing Memory ENDAT-7100M system board offers one 240 pin DDRII SDRAM socket supports up to 1GB memory and the speed can be 400 and 533 MHz. Note: For DIMM compatibility, please refer to page 40. 2-3. Shared VGA Memory ENDAT-7100M is using built-in AGP VGA controller with S3 Graphics UniChrome Pro IGP graphics core up to 64MB of system memory. -
Page 21: Watch Dog Timer
The ENDAT-7100M System Board Status Assignment Used Timer Used Keyboard Used Second 8259 Used COM2 Used COM1 Used COM3 Used Floppy Disk Used LPT1 Used Used LPT2 or Audio Used COM4 Used LAN Adapter (on board) Used PS/2 Mouse Used... - Page 22 //Set active register is CRF4 outportb(0x2f,tt); //Set time out value of WDT void show_ver() unsigned char tmp0; printf("Designed by ROBERT LIOU of UNICORN computer corp. \n2005/10/07 release version:1.0a\n"); printf("This program is design for test Watch Dog Timer for ENADT-7100M(W83697HF).\n");...
-
Page 23: Digital I/O
The ENDAT-7100M System Board 2-6. Digital I/O 1) Pin out of digital I/O header (JP7): Pin No. Function Pin No. Function DIO-O0 DIO-I0 DIO-O1 DIO-I1 DIO-O2 DIO-I2 DIO-O3 DIO-I3 DIO-O4 DIO-I4 DIO-O5 DIO-I5 DIO-O6 DIO-I6 DIO-O7 DIO-I7 +3.3V +3.3V 2) Digital I/O port address: This function is support by onboard super I/O chip;... - Page 24 User Manual Sample code for Output (using Turbo C/C++ 3.0): outportb(0x4e,0x87); //Unlock register outportb(0x4e,0x87); //Unlock register outportb(0x4e,0x07); //Set Logic Device number pointer outportb(0x4f,0x09); //Set Logic Device number outportb(0x4e,0xF4); //Set active register is CRF4 outportb(0x4f,0xnn); //Write data to digital output Register configuration: Bit No Out7 Out6...
-
Page 25: Chapter 3. Award Bios Setup
The ENDAT-7100M System Board Chapter 3. AWARD BIOS SETUP Phoenix – Award BIOS CMOS Setup Utility > Standard CMOS Features > Frequency/Voltage Control > Advanced BIOS Features Load Optimized Defaults > Advanced Chipset Features Set Supervisor Password > Integrated Peripherals Set User Password >... -
Page 26: Standard Cmos Features
User Manual 3-1. Standard CMOS Features The Standard Setup is used for the basic hardware system configuration. The main function is for Data/Time and Hard Disk Drive settings. Item Available Options: Date (mm:dd:yy) Time (hh:mm:ss) IDE Channel 0 Master: Auto Auto IDE Channel 0 Slave : IDE Channel 1 Master:... -
Page 27: Advanced Bios Features
The ENDAT-7100M System Board 3-2. Advanced BIOS Features This section allows you configuring your system for basic operation. You have the opportunity to select the system’s default speed, boot-up priority, keyboard operation and security. Item Available Options: Hard Disk Boot Priority... -
Page 28: Dram Clock
User Manual DRAM Clock/Drive Control Item Available Options: Current FSB Frequency Current DRAM Frequency DRAM Clock By SPD DRAM Timing Auto By SPD ․ DRAM Clock This item allows you to set the speed of Direct Memory Access (DMA) at either equal to or one-half of the SYSCLK (system clock signal) speed. -
Page 29: Select Display Device
The ENDAT-7100M System Board ․ Select Display Device This field is used to select the type of display to use when the system boots. <Choice: CRT, LCD, CRT + LCD> ․Panel Type Resolution & Channel Resolution & Channel Resolution & Channel... -
Page 30: Sata Mode
User Manual VIA OnChip IDE Device Item Available Options: OnChip SATA Enabled SATA Mode OnChip IDE Channel0 Enabled OnChip IDE Channel1 Enabled IDE Prefetch Mode Enabled Primary Master Auto Primary Slave Auto Secondary Master Auto Secondary Slave Auto Primary Master UDMA Auto Primary Slave... -
Page 31: Via Onchip Lan
The ENDAT-7100M System Board VIA OnChip PCI Device Item Available Options: VIA AC97 Audio Enabled VIA OnChip LAN Enabled Onboard LAN Boot ROM Disabled OnChip USB Controller All Enabled OnChip EHCI Controller Enabled USB Emulation USB Keyboard Support Enabled ․VIA AC97 Audio Allow the motherboard's BIOS to detect whether you are using any audio device. -
Page 32: Uart Mode Select
User Manual SuperIO Device Item Available Options: Onboard Serial Port 1 3F8/IRQ4 Onboard Serial Port 2 2F8/IRQ3 UART Mode Select Normal RxD, TxD Active Hi,Lo IR Transmission Delay Enabled UR2 Duplex Mode Half Use IR Pins IR-Rx2Tx2 Onboard Parallel Port 378/IRQ7 Parallel Port Mode Normal... -
Page 33: Acpi Function
The ENDAT-7100M System Board IRQ/Event Activity Detect Press Enter ․ ACPI Function This function should be enabled only in operating systems that support ACPI. Currently, only Windows® 98SE/2000/ME/XP supports this function. When this field is enabled, the system will ignore the settings in the “Suspend Mode”... -
Page 34: Reset Configuration Data
User Manual and “PS2MS Wakeup from S3/S4/S5” will be disabled while changing the password. <Choice: Hot Key, Password> 3-6. PnP/PCI Configurations This section describes the configuration of the PCI bus system. PCI is a system that allows I/O device to operate at speeds nearing the speed of the CPU itself, when communicating with its own special components. -
Page 35: Pc Health Status
The ENDAT-7100M System Board 3-7. PC Health Status This screen shows the information of temperature, Fan speed and Vcore etc. It also can set CPU warning temperature to protect CPU. PC Health Status Item Available Options: Current System Temp. Current CPU1 Temperature... -
Page 36: Chpater 4. Vga, Lcd, Feature
However, since the engine is integrated, it enjoys a higher bandwidth and lower latency than is possible with discrete solutions. The controller of ENDAT-7100M supports 2 types of display: CRT and LVDS panel. Support CRT resolutions up to 1600x1200... -
Page 37: Lvds Panel Feature
The ENDAT-7100M System Board 4-2. LVDS Panel Feature The on-board graphic controller supports industry standard LCD panel, LVDS interface only, with 1 channel (18 or 24) and 2 channels (36 or 48bit) data width. LVDS interface provides low voltage, high speed and low EMI serial DC-balanced differential data via optional onboard LVDS. -
Page 38: Driver Utility Installation Guide
User Manual 4-3. Driver Utility Installation Guide 1. When finishing the installation of Windows platform (2000/XP), please install the relative VIA driver (4in1) utilities for compliance compatibility of hardware environment. 2. Insert the support CD that supplied with motherboard into CD-ROM driver which enable the access with auto-run mode;... - Page 39 The ENDAT-7100M System Board 5. The Screen will appear VIA 4in1 driver setup screen, please press “NEXT” to continue. Please follow the steps instructed by each screen for the installation of the VIA 4in1 driver. Restart the system after completed the installation.
-
Page 40: Chpater 5. Lan Adapter
User Manual Chapter 5. LAN Adapter The on-board LAN adapter integrated of Single Chip Fast Ethernet Controller with options of one or dual LAN solution, and also the LAN chip option of VIA VT6103 solution. It is highly integrated and requires no “glue” logic external memory on board. -
Page 41: Utp Cable/Rj-45 Jack Definition
The ENDAT-7100M System Board 5-2. UTP Cable / RJ-45 Jack Definition Straight through twisted pair cable is typically used to connect a hub to a server or workstation. In a straight through connection, Pin 1 at the server, Pin 2 at the hub connects to Pin 2 at the server, and so on. -
Page 42: Connecting 100Base-Tx Fast Ethernet Network
User Manual 5-3. Connecting 100Base-TX Fast Ethernet Network The system board provides an RJ-45 port for connection to 100Base-TX Fast Ethernet or 10Base-T Ethernet Network with a single connection over unshielded twisted-pair (UTP). The adapter automatically operates at 10Mbps or 100Mbps when the appropriate 10/100Base hub is connected. To connect the adapter to 100Base-TX Fast Ethernet Network, you need a twisted-pair Category 5 cable with RJ-45 modular jacks at both ends. -
Page 43: Remote Boot Rom Function
The ENDAT-7100M System Board Automatic Selection of the Media Type While the driver installs, it automatically detects the media type based on the type of cable connected. Once you change the cable type, you must reinstall the driver to execute auto-detect again. -
Page 44: Appendix A: Flash Memory Utility
User Manual Appendix A: FLASH Memory Utility Using this utility to update the system BIOS from a disk file to the on board Flash memory. Be aware the improper change of the system BIOS will cause the system to malfunction. Using utility as follows: 1. -
Page 45: Appendix B: Lcd Pin Assignment
The ENDAT-7100M System Board Appendix B: LCD Pin Assignment LVDS1: LVDS (1.25mm) Dual Channel Pin No. Signal Pin No. Signal VBL (+12V) VBL (+12V) DISP.ON/OFF LCD POWER LCD POWER TxO0+ TxO0- TxO1+ TxO1- TxO2+ TxO2- TxO3+ TxO3- TxOC+ TxOC- TxE0+... -
Page 46: Appendix C: Dimm Compatibility
User Manual Appendix C: DIMM COMPATIBILITY In order to clear the memory recognize half of size to VIA CN700/CX700 platform, the following information is the description of chipset structure respect to memory’s design affect to system board. ‧ Advanced High-Performance DDR2 SDRAM Controller –... -
Page 47: Appendix D: Limited Warranty
The limited warranty applies to normal proper usage of the hardware and does not cover products that have been modified or subjected to unusual electrical or physical stress. Unicorn Computer Corp is not liable to repair or replace defective goods caused by improper using or use of unauthorized parts. -
Page 48: Rma Service Request Form
User Manual RMA SERVICE REQUEST FORM When requesting RMA service, please fill out this “RMA Service Request Form”. This form needs to be shipped with your returns. Service cannot begin until we have this information. RMA NO.: Company: Person to Contact: Phone No: Purchase Date : Fax No. - Page 49 The ENDAT-7100M System Board Issue Code of defect. 01 Second Times R.M.A. 11 Memory Socket Bad 02 No Screen (No Boot) 12 Hang Up Hardware 03 VGA (Display) Fail 13 Hang Up Software 04 CMOS Data Lost 14 PCB Problem...
