Installing the outdoor unit
Quick coupling installation procedure continued
11
G Check for leakage using soapy water
Connect the electric wiring at the outdoor unit
12
15
Before connecting the electric wiring at the outdoor unit, make sure the power of indoor unit is unplugged.
G Remove the cable clamp
G Connect the electric wiring to outdoor unit with the wiring connector
G Tighten the cable with the cable clamp
G Please connect the Earthing to the housing as shown in
G Replace the shut-off valve protective cover
