CARE & MAINTENANCE
Maximum Cleaning - (As Needed)
Turn Gear of the Antibacterial Disc
counterclockwise, and pull the front of
the Disc out, and separate axis from the
rear Gear Disc, by turning it
counterclockwise.
Rinse Antibacterial Disc with warm tap
water and a mild detergent.
Disassembled Antibacterial Discs are dish
washer safe and can be washed in
temperatures no greater than 176 F.
Clean the inside of water tank with a soft
cloth and mild detergent.
After cleaning, assemble the parts
(Gear Disc, Discs, and Saw Tooth Gear
Disc) in the opposite order.
Saw Tooth
Gear Disc
Gear Disc
Disc Plate Disc Plate
Axis(inside) Disc
Cleaning Water Tank
Clean the inside of the water tank with
a soft cloth and mild detergent.
Place CleanCel Antibacterial Discs
back into the water tank aligning with
grooves and with handle laid flat.
Replace the Water Tank with a snap.
Gently slide down the front panel to
close the unit. Make sure that it is
seated properly and lines up correctly.
