Page 1
(This ozone generator operates at 4,200-5,000 volts) HOW OZONE WORKS: Ozone Solutions air purifiers use ozone to clean the air the same way nature uses lightning to create ozone to clean the air naturally. Ozone is very unstable and attaches to contaminants, mold, odors, etc.
Page 2
2 a. The OMZ-2500 controls feature an on/off switch powering the unit and fan and a variable ozone dial. Ozone production begins when both the variable ozone dial and main switch is turned ON.
Page 3
Figure 3 Figure 2 Figure 4 3. Locate and remove the 11/32 nut from the high voltage towers, and remove holding clip (Figure 4). 4. Use a Phillips screwdriver to remove the plate bracket that holds the plates in the clip rings. There is one screw on each side (Figure 5).
B: Are the plates clean and dry? (refer to maintenance section) if unit does not work after cleaning it will probably need to be sent in for service work. C: A hole has formed in the corona plate causing a direct short. – Contact Ozone Solutions at 888-892- 0303 if this is suspected.
