INFLATABLE CANOES
Sit On Top, Tahiti™, Rio™, Fastback™, Colorado™, Pointer™,
READ THE FOLLOWING
INSTRUCTIONS AND WARNINGS TO AVOID
DROWNING OR SERIOUS INJURY
Paddle sports can be very dangerous and physically demanding. The user
of this product should understand that participating in paddle sports may
involve serious injury or death. Observe the following safety standards
whenever using this product.
• It is the owner's responsibility to carefully read the manual and instruct all
users in safe operation of this product.
• Not a life saving device.
• Get paddle sport instruction specific to this type of craft.
• Obtain certified first aid training and carry first aid and
safety/rescue equipment.
• Always wear an approved Personal Flotation Device (Life Preserver).
• Wear a helmet when appropriate.
• Dress appropriately for weather conditions; cold water and/or cold
weather can result in hypothermia.
• Never paddle alone.
• Do not paddle in flood conditions.
• Be aware of river water levels, tidal changes, dangerous currents and
weather changes.
• Do not use in high wind, strong currents, open water or dangerous tides.
• Scout unfamiliar waters; portage when appropriate.
• Do not exceed your paddling ability; be honest with yourself.
• Consult a physician prior to beginning your paddle sport training.
• Do not use this product under the influence of alcohol or drugs.
• Do not make any alterations to this product.
• Do not overload or over inflate.
• Never tow from another boat or vehicle.
• Know and follow local water safety rules and boating regulations.
& KAYAKS
Including the following Model Series:
Hui Sport and Fiji™.
CAUTION:
Safety Warning

Advertisement

   Summary of Contents for Sevylor Sit On Top, Tahiti

  • Page 1 INFLATABLE CANOES & KAYAKS Including the following Model Series: Sit On Top, Tahiti™, Rio™, Fastback™, Colorado™, Pointer™, Hui Sport and Fiji™. READ THE FOLLOWING INSTRUCTIONS AND WARNINGS TO AVOID DROWNING OR SERIOUS INJURY CAUTION: Safety Warning Paddle sports can be very dangerous and physically demanding. The user of this product should understand that participating in paddle sports may involve serious injury or death.
  • Page 2: Important Information

    IMPORTANT INFORMATION The warnings below relate to various situations. Please observe them. CAUTION! Denotes an imminent hazard which will result in severe injury if you do not comply with the instructions. WARNING! Reminds you of safety measures which must be observed. Also denotes unsafe practices which could result in personal injury or damage to the product or property, if you do not comply with the instructions.
  • Page 3 INFLATION INSTRUCTIONS To inflate using any Sevylor QuickPump™ unit: ® 1. To begin inflation, open external cap and pull 2. Attach adapter nozzle to inflation end of firmly on the lanyard to extend out. This will pump. Insert pump and turn on.
  • Page 4 Double Lock™ valve adapter. The mini Double Lock™ valve adapter is included with all Sevylor pumps. The adapter can be ® purchased from Sevylor Customer Service by calling 1-800-835-3278 (Part Number 5010000707). CAUTION! Water temperature and weather does affect the pressure in inflatable products.
  • Page 5 Your product is NMMA certified using the ABYC standard. WARNING! Do not exceed the certified maximum capacities under any circumstances! NMMA (ABYC Persons Maximum Inflation Inflation Standard) Capacity Payload Capacity Pressure Pressure Model # Persons Only Persons, Gear Main Chamber(s) Floor Chamber(s) 1 Person Sit On Top 1 Pers.
  • Page 6 WARNING! Do not exceed the certified maximum capacities under any circumstances! Maximum NMMA (ABYC Persons Inflation Inflation Payload Standard) Capacity Pressure Pressure Capacity Model # Persons Only Persons, Gear Main Chamber(s) Floor Chamber(s) Fastback™ 1 1 Pers. or 400 lbs. 0.5 PSI 0.5 PSI Person Kayak...
  • Page 7 WARNING! Do not exceed the certified maximum capacities under any circumstances! Maximum NMMA (ABYC Persons Inflation Inflation Payload Standard) Capacity Pressure Pressure Capacity Model # Persons Only Persons, Gear Main Chamber(s) Floor Chamber(s) Fiji™ Travel Pack 2 Pers. or 400 lbs. 0.9 PSI 0.9 PSI Kayak...
  • Page 8 SEVYTEST™ GAUGE Some of the Sevylor products are equipped with a Sevytest™ ® gauge. The Sevytest™ device is a pressure gauge, not an infl ation gauge. The Sevytest™ gauge is found on the side wall, inside the main chamber(s). The purpose is to show you when to let some air out after the pressure has increased due to temperature change.
  • Page 9: Operating Instructions

    OPERATING INSTRUCTIONS: • Follow all local boating regulations and navigation rules. Familiarize yourself with boating conditions where you plan to use the boat. Use common sense and caution when operating in unfamiliar places. • Observe the maximum weight the product can carry and do not overload past this limit.
  • Page 10 REPAIRING SMALL PUNCTURES Inadvertent punctures can be repaired using 3 different methods described below. (included with select models Included “Sticky Back Repair Patch” only) 1. Thoroughly clean and dry the damaged area. Completely deflate the product. 2. Cut a portion of the patch to cover the puncture and allow an additional ¼”...
  • Page 11 The Sevylor AirSeal is another repair option for repairing small punctures, in inflatable products such as pool floats, small boats, air mattresses and rainwear. The Sevylor AirSeal can also be used as the vinyl glue, for the vinyl patch noted in the above section. Refer to the repair instructions included with the Sevylor AirSeal.
  • Page 12 Tahiti™ Optional directional skeg for below 3 models 2 PERSON FISH/HUNT 2 Spray Covers Two Main Chambers with Tubular I-beam Floor Two Seats 2 PERSON CLASSIC 2 Spray Covers Two Main Chambers with Two Seats with Tubular I-beam Floor Back Support 2 PERSON PRO SELF BAILER 2 Spray Covers...
  • Page 13 Pointer™ Water bottle holder on below 2 models (not shown) 1 PERSON Four Tie Downs to Secure Padded Seat with backrest Topside Cargo or Spare Durable Fabric Reinforced goes here (not shown) Paddle Bottom & Sides Pointed/Rigid Bow & Stern Carry Handle Carry Handle...
  • Page 14 Colorado™ 2 PERSON Multiple D-rings Removable Stern and Tie Downs Storage Compartment Raised Stern Carry Handles Directional Strakes Raised Bow (not shown) Durable Reinforced Two Elevated Bucket Seats Paddle/Oar Fabric Material on with Storage Holders Bottom Compartments in Back 2 PERSON FISH/HUNT Multiple D-rings Removable Stern...
  • Page 15 Rio™ 1 PERSON Elevated Bucket Seat with Storage Compartment in Back Removable Raised Stern Storage Compartment Raised Stern Carry Handles Multiple D-rings Paddle/Oar Durable Reinforced and Tie Downs Holders Fabric Material on Bottom Directional Strakes (not shown) 1 PERSON FISH /HUNT Elevated Bucket Seat with Storage Removable Compartment in Back...
  • Page 16 Sit On Top - Non Covered 2 PERSON Paddle Locks Grab Handle Front Cargo Rear Cargo Storage Storage Drink Holders (2 Person Model Only) 1 PERSON Not shown. Has the same features as the 2 person except where noted and only has 1 seat. Sit On Top - Covered 2 PERSON Handles for Easy...
  • Page 17 Fastback™ 1 PERSON Storage Compartments Multiple D-ring Hooks Carry Handle Carry Neoprene Padding Handle Guards Hui Sport Kayak 1 PERSON Paddle Locks Cargo Net Stringer Attachment Rod Holder Drink Holder...
  • Page 18: Paddle Assembly, Guidelines For Usage

    PADDLE ASSEMBLY: SELECT MODELS ONLY. Join the three shafts together by screwing them together with the two couplers. Attach the blade to the shafts by screwing onto the end of the shaft. Coupler Coupler Shaft Shaft Shaft Blade Blade GUIDELINES FOR USAGE: These kayaks may be wider than a typical kayak, which means they may feel more stable.
  • Page 19 What This Warranty Does Not Cover This warranty does not cover normal wear of parts, parts that are not genuine Sevylor parts, or ®...
  • Page 20 What This Warranty Does Not Cover This warranty does not cover normal wear of parts, parts that are not genuine Sevylor parts, or ®...
