EQUIPMENT INSTALLATION continued

System Specifications

Item Number
Part Number
Recharge Style
Media Tank Size
Resin Volume
Salt Storage
Drain Water Rate
Service Connection Size
Drain Connection Size
Recharge (brine) Connection Size
Installation Space Requirements
Shipping Weight
Location Selection
Location of a water treatment system is important. The
following conditions are required:
• Level platform or floor.
• Room to access equipment for maintenance and adding
salt to tank.
• Ambient temperatures over 34°F (1°C) and below 120°F
(49°C).
• Water pressure below 125 psi (8.6 bar) and above
20 psi (1.4 bar).
• In Canada the water pressure must be below 100 psi
(6.89 bar).
• Constant electrical supply to operate the controller.
• Total minimum pipe run to water heater of ten feet (three
meters) to prevent backup of hot water into system.
• Local drain for discharge as close as possible .
• Water line connections with shutoff or bypass valves.
• Must meet any local, state and international codes for the
installation site .
• Valve is designed for minor plumbing misalignments. Do
not support weight of system on the plumbing.
• Be sure all soldered pipes are fully cooled before
attaching plastic valve to the plumbing.
Outdoor Locations
It is recommended that the OMNI system be installed indoors.
When the water conditioning system must be installed
outdoors, several items must be considered.
• Moisture — The valve and 706 controller are rated
for NEMA 3 locations . Falling water should not affect
performance .
The system is not designed to withstand extreme humidity
or water spray from below. Examples are: constant heavy
mist, near corrosive environment, upwards spray from
sprinkler.
• Direct Sunlight — The materials used will fade or discolor
over time in direct sunlight. The integrity of the materials
will not degrade to cause system failures.
4001557
OMNI OM26KCS
Meter - Demand
9" x 35"
0 .82 Cu Ft
220 lbs
2 .7 GPM
1" NPT
1/2" NPT
3/8" NPT
23" D x 13" W x 45" H
82 Lbs
4001558
OMNI OM32KCS
Meter - Demand
10" x 35"
1 .00 Cu Ft
220 lbs
3 .9 GPM
1" NPT
1/2" NPT
3/8" NPT
23" D x 13" W x 45" H
93 Lbs
• Temperature — Extreme hot or cold temperatures may
cause damage to the valve or controller.
Freezing temperatures will freeze the water in the valve.
This will cause physical damage to the internal parts as
well as the plumbing .
High temperatures will affect the controller. The display
may become unreadable but the controller should
continue to function . When the temperature drops down
into normal operating limits the display will return to
normal .
• Insects — The controller and valve have been designed
to keep all but the smallest insects out of the critical
areas. The top cover should be installed securely in
place .
Things You Need to Know
• When the controller is first plugged in, it may display
an Err 3, this means that the controller is rotating the
camshaft to the home position .
• The preset default time of recharge is 2:00 AM .
• The controller is programmed to recharge if a recharge
has not taken place in the last 15 days. This setting
cannot be changed .
• Make sure control power source is plugged in. The
transformer should be connected to a non-switched
power source .
• Unless changed, the settings for a newly installed system
are:
Hardness - 25 grains per gallon
Salt Setting - HE (High Efficiency)
Internal System clock starts at 0 hours (midnight)
The first recharge will occur when the system clock
reaches 2:00 AM
• Test your water. Take a 4-5 oz sample of your water to
someone who can test for hardness . This information will
be used to setup the control .
OM26KCS, OM32KCS, OM36KCS DE11 • 5
4001559
OMNI OM36KCS
Meter - Demand
10" x 35"
1 .09 Cu Ft
220 lbs
3 .9 GPM
1" NPT
1/2" NPT
3/8" NPT
23" D x 13" W x 45" H
100 Lbs
