Summary of Contents for Symbol CRG 1100
- Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
-
Page 3: Table Of Contents
Q u i c k R e f e r e n c e Introduction The CRG 1100 Battery Charger enables four PDT 1100 terminal NiMH battery packs to be charged simultaneously. One slot has discharge capability. Before operating the charger, read these instructions thoroughly. -
Page 4: Parts Of The Crg 1100
Parts of the CRG 1100 Battery Pack Slot Slot 4 (Discharge/Charge Slot) Discharge Light Power Light Charging Lights 35864032.eps Power Switch 35864034.eps AC Power Port... -
Page 5: Description Of Parts
DIS CHG 35864037.eps Connecting the AC Power Supply The CRG 1100 is powered by an AC input 100-240VAC/DC output 12V 1.5A power supply (p/n 50-14000-103), and a DC inter- connect cable. 1. Connect the DC inter-connect cable to the CRG 1100 and then to the power supply. -
Page 6: Charging A Battery Pack
Charging a Battery Pack 1. Turn the power switch to ON. The power light illuminates. 2. Insert the battery pack in any slot of the charger. Battery pack 35864036.eps 3. The trickle charging (CHG/TRK) light illuminates for that slot to indicate charging. 4. -
Page 7: Troubleshooting
Q u i c k R e f e r e n c e 4. The DIS CHG light illuminates to indicate the battery pack is being discharged. 5. When the battery pack is fully discharged, charging begins au- tomatically. Discharging and charging completes after about 10 hours and 20 minutes. - Page 9 Q u i c k R e f e r e n c e Warranty (A) Seller’s hardware Products are warranted against defects in workmanship and materials for a period of three (3) months from the date of shipment, provided the Product remains unmodified and is operated under normal and proper conditions.
-
Page 10: Regulatory Information
Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user’s authority to operate the equipment. - Page 11 Q u i c k R e f e r e n c e...
-
Page 12: Service Information
+44 118 945 7360 tions Customer support is available 24 hours a day, 7 days a week. For the latest version of this guide go to: http://www.symbol.com/manuals. 70-35863-02 Revision B — August 2002 Symbol Technologies, Inc. One Symbol Plaza Holtsville, NY 11742-1300...
