  • Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
  • Page 3 Introduction This guide describes how to install and use a VCD 8800 vehicle cradle with a Symbol PPT 8800 Series terminal. The VCD 8800 should be installed into the cab of your vehicle. Once installed, the cradle holds a terminal securely in place. It also: •...
  • Page 4 V C D 8 8 0 0 For detailed information on PPT 8800 Series terminals, refer to the PPT 8800 with Windows Mobile 2003 Software for Pocket PCs Quick Reference Guide (p/n 72-63153-xx), PPT 8800 with Windows Mobile 2003 Software for Pocket PCs Product Reference Guide (p/n 72-63154-xx), PPT 8800 Series with Windows Embedded CE .NET Quick Reference Guide (p/n 72- 58093-xx), or PPT 8800 Series with Windows Embedded CE .NET...
  • Page 5 Q u i c k R e f e r e n c e Parts FRONT Spare Battery battery slot release lever Standard capacity battery Terminal insert release button Terminal slot Terminal battery Spare battery charging LED charging LED BOTTOM Power Serial port...
  • Page 6 Lack of proper insertion may result in property damage or personal injury. Symbol Technologies, Inc. is not re- sponsible for any loss resulting from the use of the products while driving. Remember: Safety comes first.

  • Page 7: Mounting The Cradle

    Q u i c k R e f e r e n c e Mounting the Cradle 1. Select a mounting location for the cradle. It should be flat, and must provide adequate support for the unit. 2. Prepare the mounting surface to accept four #8-32 studs, using the mounting template below.

  • Page 8: Power Connection

    V C D 8 8 0 0 Power Connection Please read all of these instructions before you begin. ARNING A properly trained technician must perform the power con- nection. Improper connection can damage your vehicle or the cradle. To connect the cradle to power: Caution: When setting up connection for this cradle, only use the power input cable provided with this cradle.
  • Page 9 Q u i c k R e f e r e n c e proper wiring can be severe. To avoid unintentional contact between the wire and any sharp edges, provide the cable with proper bushings and clamping where it passes through openings.
  • Page 10 V C D 8 8 0 0 Shield Wire (bare wire) Ground Wire (black) V+ Power (red) 10A Fuse and Fuse Holder 3. When using the supplied in-line fuse holder (which must be used if not connecting to vehicle’s fuse panel): a.

  • Page 11: Serial Device Connection

    Q u i c k R e f e r e n c e a. Red wire: connect to a +12/24 V vehicle power source. b. Black wire and Shield wire: connect to vehicle ground wire or chassis ground. Note: How the cable terminates depends on your vehicle.

  • Page 12: Terminal Insertion And Removal

    V C D 8 8 0 0 on your cradle, and the other end into the serial port on your serial device. Note: Some devices may require a null modem serial cable. To begin communication: 1. Insert the terminal into the cradle. 2.
  • Page 13 Caution: Ensure that the terminal is fully inserted into the cradle. Lack of proper insertion may result in property damage or personal injury. Symbol Technologies, Inc. is not re- sponsible for any loss resulting from the use of the products while driving.

  • Page 14: Terminal Battery Charging

    V C D 8 8 0 0 Terminal Battery Charging 1. Ensure the cradle is connected to a power source. See Power Connection on page 2. Insert the terminal into the cradle. See Terminal Insertion and Removal on page The terminal starts to charge through the cradle as soon as you insert it.
  • Page 15 Q u i c k R e f e r e n c e 2. Position the spare battery in the spare battery charging slot in the cradle with the charging contacts facing down and to the rear of the cradle. Slide the battery into the spare battery slot Battery release...

  • Page 16: Spare Battery Charging

    Avoid getting oils, grease or gasoline on the cradle, and do not let debris gather in the bottom of the cradle slot. When necessary, clean the cradle with a mild cleaner. If you are not sure whether or not to use a particular cleaner, contact Symbol for advice.

  • Page 17: Troubleshooting

    Q u i c k R e f e r e n c e Troubleshooting Symptom Possible Cause Action Terminal battery Cradle is not re- Make sure the Power Input cable is se- charging LED does ceiving power. curely connected to the cradle’s Power not light up.

  • Page 18: Regulatory Information

    V C D 8 8 0 0 Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment.

  • Page 19: Warranty

    Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which...

  • Page 20: Service Information

    +1-954-255-2610 Outside US Europe/Mid-East Contact local distributor or call Distributor Operations +44 118 945 7360 For the latest version of this guide go to: http://www.symbol.com/manuals. 72-65241-02 Revision A — January 2004 Symbol Technologies, Inc. One Symbol Plaza Holtsville, NY 11742-1300...
